Summit ZTL053S 30" Wide 4-Burner Gas Cooktop Stainless Steel Look

Quick Specification More details

Width:
29.75"
Depth:
20"
Height:
4"
Type:
Gas Cooktops

About this product

Fits common cutouts
Cast iron grates
Recessed top
Simmer burner

Summer Sale

Clearance

SKU: ZTL053S | UPC: 761101061641

Summit ZTL053S 30" Wide 4-Burner Gas Cooktop Stainless Steel Look

$564.96 ~~$719.97~~ Save $155.01 / 21% OFF

Out of stock

Active Rebates

We’ll confirm fit, specs & delivery before you order.

• Chat • Email • Call Us

Quick Specification More details

Width:
29.75"
Depth:
20"
Height:
4"
Type:
Gas Cooktops

About this product

Fits common cutouts
Cast iron grates
Recessed top
Simmer burner

Product Details
Manuals & Guides
From The Manufacturer
Reviews

$564.96 ~~$719.97~~ Save $155.01 / 21% OFF

Product Details for SUMMIT ZTL053S

Technical Details

Warranty

Parts	1 Year
Labor	1 Year

Dimensions & weight

Width	29.75 in.
Height	4 in.
Length	20 in.
Weight	27 lbs.

Cubic feet measurement & dimensional weight

Cubic Feet Measurement	1.38 ft³
Dimensional Weight	17.12 lbs.
Total of Cubes	1.38 ft³
Total of Dimensional Weight	17.12 lbs.

Overview gas cooktop

Nominal Height	4.0" (10 cm)
Height of Cabinet	4.0" (10 cm)
Nominal Width	30.0" (76 cm)
Width	29.75" (76 cm)
Nominal Depth	20.0" (51 cm)
Depth	20.0" (51 cm)
Cabinet	Chrome
US Electrical Safety	CSA
Canadian Electrical Safety	CSA-C
Weight	27.0 lbs. (12 kg)
Parts & Labor Warranty	1 Year
UPC	761101061641
Ignition	Spark
LP Convertible	With Kit LP S2 Accessory
Number of Burners	4
Controls	Dial
Surface	Painted
Grate Material	Cast Iron
Cutout Width	28.38" (72 cm)
Cutout Depth	18.63" (47 cm)
Burner #1 BTU	12000.0
Burner #2 BTU	9100.0
Burner #3 BTU	9100.0
Burner #4 BTU	5000.0
Power Cord Included	Yes

Description

Made in the U.S.A., Summit's gas cooktops offer lasting quality and reliable cooking. The ZTL053S is a 30" wide 4-burner cooktop designed for 28 3/8" W x 18 5/8" D cutouts. The brushed chrome surface features a recessed design to better contain spills. The side-located push-to-turn dial knobs offer easy use. Two sets of continuous cast iron grates are designed to hold up to heavy pots and pans. Four sealed Sabaf burners with removable burner caps ensure safer and cleaner cooking. The ZTL053S includes a high output 12000 BTU burner for powerful heating, conveniently located in front for easy access. The rear 5000 BTU burner is ideal for simmering at lower power or keeping food warm without overcooking. Two standard 9100 BTU burners meet most cooking needs. This unit utilizes electronic spark ignition and includes a pre-installed 3-pronged cord. The ZTL053S is set for natural gas and can be converted to propane connections with the purchase of our Kit LP S2. Additional choices are available in black and white, as well as in 24" and 27" wide fits. Browse our site for more.

Product Features

Fits common cutouts
Designed for 28 3/8" W x 18 5/8" D cutouts for an easy fit in smaller kitchens
Cast iron grates
Two sets of continuous grates in heavy duty cast iron hold up to large cookware
Recessed top
Curved design helps to contain spills on the surface for easier cleanup
Simmer burner
Rear burner on right side reaches maximum of 5,000 BTUs to allow more precise heating of sensitive items
Power burner
Front left burner features 12,000 BTU output for powerful cooking
Push-to-turn knobs
To prevent accidents, knobs require a small amount of force when turning
Removable burner caps
Burners include a removable cap for easy cleaning
Brushed chrome surface
Striking look with easy cleanability
Cord included
Pre-installed 115V 3-pronged power cord
Electronic/gas spark ignition
Gas spark ignition for automatic lighting of burners
Made in the USA
Designed and constructed domestically
Sealed Sabaf® burners
Quality burners with cast iron tops ensure lasting durability and easier cleanup
Two standard burners
Front right and rear left burners offer 9100 BTUs of cooking power to accommodate most dishes
Designed for natural gas
Set for use with natural gas connection. To convert for propane use, add Kit LP S2
Side controls
Cooktop knobs are located on the right side of the cooktop, clearing up space in the front for easier cooking
