Summit FFRF3070BIF 30" Wide Built-In Refrigerator-Freezer (Panels Not Included) Panel-Ready

Quick Specification More details

Width:
29.5"
Depth:
22" - 25"
Height:
34"
Type:
Side-By-Side Refrigerators

About this product

All-in-one design
Built-in capable
Panel-ready doors
Frost-free operation

Summer Sale

Clearance

SKU: FFRF3070BIF | UPC: 761101054179

Summit FFRF3070BIF 30" Wide Built-In Refrigerator-Freezer (Panels Not Included) Panel-Ready

Active Rebates

We’ll confirm fit, specs & delivery before you order.

• Chat • Email • Call Us

Quick Specification More details

Width:
29.5"
Depth:
22" - 25"
Height:
34"
Type:
Side-By-Side Refrigerators

About this product

All-in-one design
Built-in capable
Panel-ready doors
Frost-free operation

Product Details
Manuals & Guides
From The Manufacturer
Reviews

Product Details for SUMMIT FFRF3070BIF

Technical Details

Warranty

Parts	1 Year
Labor	1 Year

Dimensions & weight

Width	29.5 in.
Height	34 in.
Length	24.13 in.
Weight	125 lbs.

Cubic feet measurement & dimensional weight

Cubic Feet Measurement	14.01 ft³
Dimensional Weight	174.12 lbs.
Total of Cubes	14.01 ft³
Total of Dimensional Weight	174.12 lbs.

Overview refrigerator-freezer

Nominal Height	34.0" (86 cm)
Height of Cabinet	34.0" (86 cm)
Nominal Width	30.0" (76 cm)
Width	29.5" (75 cm)
Nominal Depth	25.0" (64 cm)
Depth	24.13" (61 cm)
Capacity	5.4 cu.ft. (153 L)
Defrost Type	Frost-Free
Door	Panel-Ready
Cabinet	Black
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Energy Usage/Year	440.0kWh/year
Amps	1.5
Voltage/Frequency	115 V AC/60 Hz
Weight	125.0 lbs. (57 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
UPC	761101054179
Door Swing	French
Adjustable Shelves	Yes
Interior Light	Yes
Refrigerator - Interior Height	26.63" (68 cm)
Refrigerator - Interior Width	12.0" (30 cm)
Refrigerator - Interior Depth	17.63" (45 cm)
Refrigerator - Capacity	3.0 cu.ft
Refrigerator - Shelf Type	Glass
Refrigerator - Shelf Qty	3
Refrigerator - Full Door Shelves	2
Refrigerator - Temperature Range	36°F to 43°F
Freezer - Interior Height	25.38" (64 cm)
Freezer - Interior Width	10.38" (26 cm)
Freezer - Interior Depth	16.5" (42 cm)
Freezer - Capacity	2.4 cu.ft
Freezer - Shelf Type	Wire
Freezer - Shelf Qty	3
Thermostat Type	Digital
Fan Type	Interior and Exterior
Refrigerant Type	R600a
Refrigerant Amount	1.45 oz.
High Side PSI	270.0
Low Side PSI	105.0
Level Legs	2
Freezer - Temperature Range	-4º to 4ºF
Compressor Step Height	5.5" (14 cm)
Compressor Step Width	21.0" (53 cm)
Compressor Step Depth	6.0" (15 cm)
Sound Level	33.5 dB

Description

NOTE: Product may vary from pictured unit. SUMMIT brings quality and value under the counter with the industry’s largest collection of built-in refrigeration. Sized at 30" wide, the FFRF3070BIF is an all-in-one side-by-side refrigerator-freezer. The front breathing design allows built-in installation under counters, while the fully finished black cabinet also enables freestanding use. The French swing doors feature an integrated stainless steel frame that lets users install their own overlay panels for a custom look (panel size: 30" H x 14 5/8" W). Users install their own handles. The sealed back ensures easier cleanup with added space savings. Inside, the FFRF3070BIF features a 2.4 cu.ft. frost-free freezer compartment on the left and a 3 cu.ft. frost-free refrigerator compartment on the right. The refrigerator includes a digital thermostat allowing users to manage the temperature in each compartment, with a readout in Celsius or Fahrenheit for added convenience. Adjustable glass shelves offer cleaner spill-proof storage for fresh food items, while two removable door shelves provide additional storage space as needed. An internal fan assures the compartment is cooled evenly from top to bottom. The freezer compartment includes adjustable wire shelves to ensure proper cold air circulation. Both sides feature LED lighting to provide an attractive, energy efficient presentation. The slotted floor design is ideal for keeping bottles safely in place. Additional features include an open door alarm, high temperature alarm, and Sabbath mode setting that allows you to disable certain functions during religious observance. With its innovative all-in-one design, user-friendly features, and full frost-free operation, the FFRF3070BIF is a great choice for smaller kitchens looking to maximize storage space under the counter.

Product Features

All-in-one design
Separate refrigerator and freezer sections with single compressor operation
Built-in capable
Front-breathing system allows the unit to be used built-in
Panel-ready doors
Integrated stainless steel door frame on each door accepts full overlay panels, allowing you to customize the door or blend it into your cabinetry design (panel dimensions: 30" H x 14 5/8" W at 3/4" thick; maximum weight: 10 lbs.)
Frost-free operation
No-frost operation ensures reduced maintenance in both the refrigerator and freezer compartments
Digital thermostat
Refrigerator section includes a digital control panel to manage each compartment's temperature for added convenience, with a readout in Celsius or Fahrenheit
LED lighting
Interior LED lighting in both sections offers an attractive and energy efficient presentation
Sabbath mode
Setting allows you to disable the digital displays, lights, and alarms for religious observance
Adjustable shelves
Refrigerator section includes spill-proof glass shelves for easier cleaning, while the freezer includes three adjustable wire shelves to ensure proper cold air circulation
Door shelves
Two removable door racks provide additional storage as needed
Open door alarm
Alarm will sound if either door is left open for over 60 seconds
High temperature alarm
Audible alarm sounds if the interior temperature rises above the recommended range
Slotted floors
Floor is specially designed with slots to allow you to store bottles safely on their sides
Internal fan (refrigerator compartment)
Fan-forced cooling ensures the compartment is evenly cooled from top to bottom
Sealed back
Space-saving design with no exposed coils in the rear offers easy cleanability
Right angle plug
Design allows you to plug the unit in flush against the wall socket with no need to add extra depth
Temperature memory function
In the event of power loss, the unit will retain its last temperature settings upon power recovery
Fully finished black cabinet
Allows the unit to be used freestanding
100% CFC free
Environmentally friendly design without ozone-damaging chemicals
CARB Compliant
Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
