Summit AFZ2PVBIADAMCLHD 2.47 Cu.Ft. MOMCUBE Freezer, ADA Height White
Sale price
Contact us for Pricing
Active Rebates
Thanks for contacting us.
We'll get back to you as soon as possible.
Error!
Something went wrong, please try again later.
Sale price
Contact us for Pricing
Product Details for Summit AFZ2PVBIADAMCLHD
Technical Details
Overview freezer
| Nominal Height | 32.0" (81 cm) |
| Height of Cabinet | 32.0" (81 cm) |
| Nominal Width | 20.0" (51 cm) |
| Width | 19.75" (50 cm) |
| Width with Door Open | 20.25" (51 cm) |
| Nominal Depth | 23.0" (58 cm) |
| Depth | 22.63" (57 cm) |
| Depth with Handle | 24.38" (62 cm) |
| Depth with door at 90° | 41.25" (105 cm) |
| Capacity | 2.47 cu.ft. (70 L) |
| Defrost Type | Manual |
| Door | White |
| Cabinet | White |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Amps | 1.3 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 99.0 lbs. (45 kg) |
| Parts & Labor Warranty | 2 Years |
| Compressor Warranty | 5 Years |
| UPC | 761101107493 |
| Door Swing | LHD |
| Reversible | No |
| Interior Height | 22.0" (56 cm) |
| Interior Width | 14.25" (36 cm) |
| Interior Depth | 15.5" (39 cm) |
| Shelf Type | Wire |
| Shelf Qty | 4 |
| Adjustable Shelves | Yes |
| Thermostat Type | Digital |
| Interior Light | Yes |
| Refrigerant Type | R290 |
| Refrigerant Amount | 1.31 oz. |
| High Side PSI | 280.0 |
| Low Side PSI | 130.0 |
| Compressor Step Height | 6.13" (16 cm) |
| Compressor Step Width | 14.25" (36 cm) |
| Compressor Step Depth | 7.5" (19 cm) |
| Temperature Range | -18 to -4ºF |
Description
Accucold's MOMCUBE® freezers are designed and purpose-built for breast milk storage. All MOMCUBE® units are laboratory-tested to maintain proper breast milk temperature, as recommended by the CDC and ideal for maternity wards, hospitals, NICUs, employee wellness rooms complying with Section 4207 of the Patient Protection and Affordable Care Act, and other facilities. The AFZ2PVBIADAMCLHD is a 2.47 cu.ft. all-freezer with a temperature range of -18°F to -4°F as recommended for the long-term storage of human milk. The microprocessor temperature controller is externally located to minimize door openings, helping to protect stored contents from ambient temperature. The buffered temperature probe is encased in a glycol-filled bottle to better simulate temperature of the stored milk product, with an additional sensor that reads air temperature to ensure superior temperature control. The current and min/max temperature display is viewable in Celsius or Fahrenheit to the nearest tenth of a degree. The audible and visual temperature alarm sounds if the unit's interior goes out of range. Additional alarms include a power failure alert, door open alarm, and sensor failure alarm. This model is equipped with remote alarm contacts in the rear and a 1/2" probe port on the right side to accept additional monitoring devices. A hospital grade cord with 'green dot' plug is also included for added safety in high traffic areas. Inside, this freezer features adjustable plastic-coated wire shelves that can be positioned at 1/2" increments to accommodate virtually any sized item. This unit includes LED internal lighting with an on/off rocker switch. The interior is constructed from white powder coated metal to ensure added durability and better temperature retention. Static manual defrost cooling helps to ensure stable temperature conditions. The AFZ2PVBIADAMCLHD comes in a white cabinet finish with a blue accented control panel. The factory-installed antimicrobial handle is powder-coated with naturally occurring silver ions, which help to reduce the spread of germs, allowing for a safer, cleaner user experience. The door ships with a left hand swing and self-closing function, while a factory-installed lock provides security as needed, with two keys for staff use. Powerful magnetic gaskets ensure a positive seal. Designed with hydrocarbon refrigerant, all Accucold Performance Series MOMCUBE freezers provide an energy efficient solution to breast milk storage. Additional sizes, as well as matching refrigerators, are also available. Explore the full Pharma-Vac series at accucold.com/momcube.
Product Features
-
MOMCUBE Breast Milk Freezer
Purpose-built Performance Series freezer for the long-term storage of breast milk -
Antimicrobial silver ion-coated handle
Powder-coated handle with naturally occurring silver ions to help reduce the spread of germs -
100% CFC free
Environmentally friendly design without ozone-damaging chemicals -
Versatile design
Compatible with Pyxis®, Omnicell®, and AcuDose RX® -
Usage stickers
Ships with removable warning stickers for "DO NOT UNPLUG," "DO NOT ADJUST TEMPERATURE," and "DO NOT STORE PERSONAL ITEMS", as well as breast milk storage guidelines -
Eco-Friendly
Using environmentally friendly hydrocarbons refrigerants for a greener footprint -
Extended warranty
2 years parts and labor/5 years compressor -
Fully finished white cabinet
Allows the unit to be used freestanding -
Magnetic door gasket
Quality door gaskets ensure a tight seal for energy savings and improved performance -
Left hand door swing
This unit ships with a left hand door swing. For the doors to open in the other direction, see model AFZ2PVBIADAMC -
Self-closing door
Added protection in busy settings -
Interior light
Energy efficient LED lighting with internal on/off switch -
Durable interior
Walls are constructed from white powder coated metal for added strength and improved temperature retention -
Hospital grade cord with 'green dot' plug
Secure three-pronged cord for added unit safety -
Adjustable plastic-coated wire shelves for improved circulation
Shelves can be positioned with a front lip for small storage items or reversed to a flat position to better hold larger items, with multiple shelf positions spaced at 1/2" to accommodate virtually any size -
Factory-installed lock
Keyed lock conveniently located towards the top of the door for added security (2 keys included) -
Purpose-built design
Designed and purpose-built for breast milk storage in accordance with the CDC's guidelines -
Resettable min/max display
Control panel provides a readout of the low and high temperatures in 15 minute increments -
Microprocessor control panel
Digital controls with a large LED readout in Celsius or Fahrenheit for intuitive temperature management -
Password protection
Control panel requires password entry to adjust the parameters beyond the set point -
Sensor failure alarm
Audible and visual alarm warns if the sensor is disrupted -
Audible power failure alarm
Battery-powered alarm sounds if the power connection is interrupted -
Open door alarm
Alarm will sound if the door is left ajar for over 4 minutes (adjustable from 1-99 minutes) -
Access port
Includes a pre-installed 1/2" probe hole in the right interior wall to allow easier connection to user-provided monitoring equipment -
Manual defrost operation
Static cooling system for an efficient and stable interior -
Remote alarm contacts
Electronic controller is equipped with a volt-free contact for alarm forwarding to an external remote system (contacts located in the external rear of the unit) -
Temperature alarm
Visual and audible alarms alert if the interior temperature rises or falls out of set range -
Adjustable temperature
Intuitive controls let you adjust the interior temperature between -18°F to -4ºF -
+/-1ºC Variation
The published temperature variation is derived from the maximum deviation of an NTC sensor in a 1 oz. vial located nearest the chamber geometric center during a 24 hour test period -
Recessed or freestanding use
Versatile design allows recessed installation under counters or freestanding use -
ADA Compliant
Just under 32" tall designed to fit under ADA compliant counters -
CARB Compliant
Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
