Fisher Paykel CDV3304HL Gas Cooktop, 30", LPG Other

Quick Specification More details

Width:
30"
Depth:
21"
Height:
5"
Type:
Gas Cooktops

About this product

Cooktop Power
Precise Control
Cooking Flexibility
Easy To Clean

Fisher Paykel CDV3304HL Gas Cooktop, 30", LPG Other

$1,999.00 ~~$2,868.97~~ Save $869.97 / 30% OFF

Quantity:

More on the way

Active Rebates

Extended Protection

1-Year Extended Protection
$49.99
2-Year Extended Protection
$83.99
3-Year Extended Protection
$131.99
5-Year Extended Protection
$195.99
Manufacturer Warranty Only

Cooktop Install Kit
$40.00
Standard Cooktop Install - Direct Replacement, No Modifications
$180.00
Old Appliance Removal (Unit Must be Disconnected by Owner if Installation was Not Added)
$49.99

We’ll confirm fit, specs & delivery before you order.

• Chat • Email • Call Us

Quick Specification More details

Width:
30"
Depth:
21"
Height:
5"
Type:
Gas Cooktops

About this product

Cooktop Power
Precise Control
Cooking Flexibility
Easy To Clean

Product Details
Manuals & Guides
From The Manufacturer
Reviews

$1,999.00 ~~$2,868.97~~ Save $869.97 / 30% OFF

Product Details for Fisher Paykel CDV3304HL

Technical Details

Burner ratings

Max burner power	Yes
Power back left	15,000 BTU
Power back right	15,000 BTU
Power front left	20,000 BTU
Power front right	15,000 BTU
Total cooktop power	65,000 BTU

Controls

Metal illuminated dials	Yes
Titanium coated, illuminated metal dials	Yes

Gas requirements

Fitting and pipe	½ NPT, min. â…" âˆ… flex line
Supply Pressure (natural gas)	6" to 9" W.C

Performance

Sealed Dual Flow Burners™	4
Sealed cooking surface	Yes
Simmer on all burners	140°F

Power requirements

Amperage	15A
Supply frequency	60Hz
Supply voltage	120V

Recommended back guards ventilation

Downdraft	HD30
Minimum CFM	600 BTU
Pro hood	HCB30-6 N
Traditional hood	ES30

Safety

ADA compliant

Yes

Warranty

Parts and labor

2 years

Dimensions & weight

Width	30 in.
Height	5 in.
Length	21 in.

Number of boxes, shipping dimensions, & shipping weight

Number of Boxes	1
Shipping Width	35 in.
Shipping Height	10 in.
Shipping Length	26 in.
Source	Calculation

Cubic feet measurement & dimensional weight

Cubic Feet Measurement	1.82 ft³
Dimensional Weight	22.66 lbs.
Total of Cubes	1.82 ft³
Total of Dimensional Weight	22.66 lbs.

Description

The Fisher & Paykel CDV3304HL 30-inch gas cooktop combines professional-grade performance with sleek design. Equipped with four sealed Dual Flow Burners™, it provides a powerful heat output of up to 20,000 BTU, allowing for seriously fast boiling and a precise 140°F full surface simmer with the gentlest of flames. The self-locating continuous grates are designed for easy and safe sliding of pots and pans across the cooktop surface, focusing the flame on the base of each pan where it is most required. The LED halo control dials offer information at a glance and assist in alerting you if any burners are accidentally left on. With an easy-clean design featuring a commercial-style stainless steel finish, sealed burners, and a single sheet cooking surface, maintenance is effortless. Built to last with distinctive, bold styling, this cooktop is designed to match the Fisher & Paykel Professional style family of appliances.
