Product Details for Thor Kitchen HRG4808U
Technical Details
Technical details
| Fuel Type | Natural Gas / LP Convertible |
| Installation Type | Freestanding |
| Color | Stainless Steel |
| Electrical Requirements | 120 |
| Circuit Breaker (A) | 15 |
| Frequency (Hz) | 60 |
| Controls Type | Knob |
Burner performance
| Total Burners | 6 |
| [1] Front Left Burner | 18 |
| [2] Front Middle Burner | 18 |
| [3] Front Right Burner | 18 |
| [4] Rear Left Dual Burner | 15 |
| [5] Rear Middle Dual Burner | 15 |
| [6] Rear Right Dual Burner | 15 |
| [7] Griddle Burner | 15 |
| Gas Flame Broiler | 16 |
| U-Shape Bake Burner | 22 |
| Tube Bake Burner 18 Inch Oven | 14 |
Dimensions
| Product Width | 47 7/8 |
| Product height (from bottom to top of back splash) | 38 1/2 -39 1/2 |
| Product height (from bottom to top of side panel) | 38 1/2 -39 1/2 |
| Product depth (from back panel to bullnose) | 27 15/16 |
| Product depth (from back panel to control board) | 26 1/2 |
| Product depth (from back panel to side panel front) | 24 13/16 |
| Depth of control panel (minimum) | 1 11/16 |
| Depth of control panel (bullnose | 3 1/8 |
| Cast iron cooking grate (W x L) | 10 3/4 x 23 |
Weight
| Adjustable Leg Sizes | 1.0 |
| Net weight | 403 |
| Gross weight | 485 |
Cutout
| Cutout Height | 35 11/16 (+1 ) |
| Cutout Width | 48 1/8 |
| Cutout Depth | 24 13/16 |
Accessories not included
| Liquid Propane Gas Conversion Kit | LPKHRG4808U |
| 30 Inch Telescopic Rack | TR30SS |
| 48 Inch Island Trim | ITHRG4808U |
| Bamboo Cutting Board | CB0001 |
| Wok Ring | WK01 |
| Cast Iron Reversible Griddle | RG1022 |
| Cast Iron Range Griddle | RG1032 |
Features
- Infrared gas flame broiler radiates heat evenly to sear your food and seal in the juices
- From a high-powered 18,000 BTU burner to a burner with a steady 650 BTU simmer function, this range gives you the power you need for large family meals and the consistent low heat desired for cooking delicate sauces or melting chocolate
- Telescopic racks use ball bearing rack guides for an effortless glide in and out of the oven. This luxury feature allows the rack to extend fully without tipping over for smooth, easy handling of even the heaviest dishes, and adjusts to fit different rack support levels
Description
Key Features
High-powered Btu Burners
From a high-powered 18,000 BTU burner to a burner with a steady 650 BTU simmer function, this range gives you the power you need for large family meals and the consistent low heat desired for cooking delicate sauces or melting chocolate
HIGH-POWERED BTU BURNERS
From a high-powered 18,000 BTU burner to a burner with a steady 650 BTU simmer function, this range gives you the power you need for large family meals and the consistent low heat desired for cooking delicate sauces or melting chocolate
Luxglide™ Telescopic Racks
Telescopic racks use ball bearing rack guides for an effortless glide in and out of the oven. This luxury feature allows the rack to extend fully without tipping over for smooth, easy handling of even the heaviest dishes, and adjusts to fit different rack support levels
LUXGLIDE(TM) TELESCOPIC RACKS
Telescopic racks use ball bearing rack guides for an effortless glide in and out of the oven. This luxury feature allows the rack to extend fully without tipping over for smooth, easy handling of even the heaviest dishes, and adjusts to fit different rack support levels
Infrared Broiler
Infrared gas flame broiler radiates heat evenly to sear your food and seal in the juices
15,000 BTU Griddle
The 15,000 BTU griddle offers additional cooking space and flexibility
Commercial Convection Fan
Convection fan provides controlled heat distribution for fast and efficient cooking
INFRARED BROILER
Infrared gas flame broiler radiates heat evenly to sear your food and seal in the juices
