SKU: DT2AFS

Hoshizaki DT2AFS Refrigerator and Freezer, Two Section Dual Temp Upright, Full Stainless Doors with Lock Stainless Steel

Quick Specification More details

Width:
55"
Depth:
35"
Height:
79.5"
Type:
Upright Freezers

About this product

Interior capacity of 23.1 cubic feet refrigerator, 23.1 cubic feet freezer
Epoxy electrocoated (E-Coat) evaporator coil to help fight corrosion for extended life for extended life
Stainless steel interior and exterior
One piece, full door length, extruded aluminum flush mount door handle

Summer Sale

Clearance

SKU: DT2AFS

Hoshizaki DT2AFS Refrigerator and Freezer, Two Section Dual Temp Upright, Full Stainless Doors with Lock Stainless Steel

Active Rebates

We’ll confirm fit, specs & delivery before you order.

• Chat • Email • Call Us

Quick Specification More details

Width:
55"
Depth:
35"
Height:
79.5"
Type:
Upright Freezers

About this product

Interior capacity of 23.1 cubic feet refrigerator, 23.1 cubic feet freezer
Epoxy electrocoated (E-Coat) evaporator coil to help fight corrosion for extended life for extended life
Stainless steel interior and exterior
One piece, full door length, extruded aluminum flush mount door handle

Product Details for Hoshizaki DT2AFS

Technical Details

Dimensions & weight

Weight	634 lbs.
Width	55 in.
Depth	35 in.
Height	79.5 in.

Number of boxes, shipping dimensions, & shipping weight

Number of Boxes	1
Shipping Weight	674 lbs.
Total of Shipping Weight	674 lbs.
Source	Calculation

Product details

Electrical Specs	Electrical Connection: 5 – 20P NEMA, 115v/60/1, 10 ft. cord and plug, Energy Consumption: 8.59 kwh/day, Amperage: 14, Max Fuse/HACR Breaker: 20 A
Operating Limits	Ambient Temp Range: 45 – 100°F, Voltage Range: 104 – 126V, Control Setpoint Range: 33 – 52°F,-10 – +10°F, Refrigerant: R-290
Refrigeration Data	Nominal Compres. of 770 BTU/hr at 1/4 HP refrigerator and 1425 BTU/hr at 3/4 HP freezer, Heat Rejection: 376/1401 BTU/hr
Shipping Weight	634
Storage Specs	Interior storage capacity: 23.1 ft3, Door opening: 21.75″ W x 59.25″ H, Depth with both doors fully extended: 59.25″ D, Shelves included: 6

Warranty

Parts	7 Years
Labor	7 Years
Compressor	7 Years

Description

The DT2A-FS Steelheart Series Dual Temp two section refrigerator and freezer with full stainless doors is a space saving workhorse. EverCheck digital control system with audio and visual alarms. With a interior capacity of 23.1 cubic feet refrigerator, 23.1 cubic feet freezer this efficient dual temp refrigerator and freezer and front air flow design is perfect for hot/tight kitchens. The DT2A-FS is constructed of stainless steel, which protects this unit from accidental damage and rust. Plus, it is easy to clean.

Product Features

Interior capacity of 23.1 cubic feet refrigerator, 23.1 cubic feet freezer
Epoxy electrocoated (E-Coat) evaporator coil to help fight corrosion for extended life for extended life
Stainless steel interior and exterior
One piece, full door length, extruded aluminum flush mount door handle
Interior LED light bar is mounted horizontally on the ceiling
EverCheck digital control system with audio and visual alarms
R-290 refrigerant
Energy efficient thermostatic expansion valve self contained refrigeration system
Includes 6 epoxy coated wire coated shelves
Nominal Compres. of 770 BTU/hr at 1/4 HP refrigerator and 1425 BTU/hr at 3/4 HP freezer
Top mounted energy efficient non-electric evaporation system
115v/60/1, 10 ft. cord and plug
Exclusive “stepped” door design to protect recessed door gasket
7-7-7 Warranty (seven years labor, seven years parts, seven years compressor)
