SKU: DT1AHS

Hoshizaki DT1AHS Refrigerator and Freezer, Single Section Dual Temp Upright, Half Stainless Doors with Lock Stainless Steel

Quick Specification More details

Width:
27.5"
Depth:
35"
Height:
79.5"
Type:
Bottom Freezer Refrigerators

About this product

Interior capacity of 10.19 cubic feet refrigerator, 10.9 cubic feet freezer
Epoxy electrocoated (E-Coat) evaporator coil to help fight corrosion for extended life for extended life
Stainless steel exterior (front, sides, top) and a stainless steel interior
One piece, full door length, extruded aluminum flush mount door handle

Summer Sale

Clearance

SKU: DT1AHS

Hoshizaki DT1AHS Refrigerator and Freezer, Single Section Dual Temp Upright, Half Stainless Doors with Lock Stainless Steel

Active Rebates

We’ll confirm fit, specs & delivery before you order.

• Chat • Email • Call Us

Quick Specification More details

Width:
27.5"
Depth:
35"
Height:
79.5"
Type:
Bottom Freezer Refrigerators

About this product

Interior capacity of 10.19 cubic feet refrigerator, 10.9 cubic feet freezer
Epoxy electrocoated (E-Coat) evaporator coil to help fight corrosion for extended life for extended life
Stainless steel exterior (front, sides, top) and a stainless steel interior
One piece, full door length, extruded aluminum flush mount door handle

Product Details for HOSHIZAKI DT1AHS

Technical Details

Dimensions & weight

Weight	415 lbs.
Width	27.5 in.
Depth	35 in.
Height	79.5 in.

Number of boxes, shipping dimensions, & shipping weight

Number of Boxes	1
Shipping Weight	455 lbs.
Total of Shipping Weight	455 lbs.
Source	Calculation

Product details

Electrical Specs	Electrical Connection: 5 – 15P NEMA, 115v/60/1, 10 ft. cord and plug, Energy Consumption: 4.49 kwh/day, Amperage: 5.5, Max Fuse/HACR Breaker: 15 A
Operating Limits	Ambient Temp Range: 45 – 100°F, Voltage Range: 104 – 126V, Control Setpoint Range: 33 – 52°F,-10 – +10°F, Refrigerant: R-290
Refrigeration Data	Nominal Compres. of 988 BTU/hr at 1/6 HP refrigerator and 1354 BTU/hr at 1/5 HP freezer, Heat Rejection: 168/439 BTU/hr
Shipping Weight	415
Storage Specs	Interior storage capacity: 10.19 ft3, Door opening: 21.75″ W x 27.75″ H, Depth with both doors fully extended: 58.5″ D, Shelves included: 3

Warranty

Parts	7 Years
Labor	7 Years
Compressor	7 Years

Description

The DT1A-HS Steelheart Series Dual Temp single section refrigerator and freezer with a half stainless doors is a space saving workhorse. Solid state digital controller with temperature alarms and LED display (°F or °C). With a interior capacity of 10.19 cubic feet refrigerator, 10.9 cubic feet freezer this efficient dual temp refrigerator and freezer and front air flow design is perfect for hot/tight kitchens. The DT1A-HS is constructed of stainless steel, which protects this unit from accidental damage and rust. Plus, it is easy to clean.

Product Features

Interior capacity of 10.19 cubic feet refrigerator, 10.9 cubic feet freezer
Epoxy electrocoated (E-Coat) evaporator coil to help fight corrosion for extended life for extended life
Stainless steel exterior (front, sides, top) and a stainless steel interior
One piece, full door length, extruded aluminum flush mount door handle
Lockable Half Stainless Doors
Interior LED light bar is mounted horizontally on the ceiling
R-290 refrigerant
Includes 3 epoxy coated wire coated shelves
Nominal Compres. of 988 BTU/hr at 1/6 HP refrigerator and 1354 BTU/hr at 1/5 HP freezer
115v/60/1, 10 ft. cord and plug
Top mounted energy efficient non-electric evaporation system
Exclusive “stepped” door design to protect recessed door gasket
7-7-7 Warranty (seven years labor, seven years parts, seven years compressor)
