What's included: 2 items

  • 27" Commercial High-Efficiency Energy Star-Qualified Front-Load Washer, Non-Vend

    Whirlpool CHW9160GW 27" Commercial High-Efficiency Energy Star-Qualified Front-Load Washer, Non-Vend White

    • SKU SKU: CHW9160GW UPC: 883049433516
    • Type Front Load Washers
  • 27" Commercial Electric Front-Load Dryer, Non-Vend

    Whirlpool CED9160GW 27" Commercial Electric Front-Load Dryer, Non-Vend White

    • SKU SKU: CED9160GW UPC: 883049433615
    • Type Front Load Matching Dryers
  • Product Details
  • Manuals & Guides
  • From The Manufacturer
  • Reviews
Sale price $2,817.89 Regular price $4,518.82 Save $1,700.93 / 37% OFF

Product Details for Whirlpool CHW9160GW

Technical Details

Details

Hoses Included Yes
Water Factor 4.23
Maximum Spin Speed 1, 000
Operating Pressure 20-100

Controls

Control Type Electronic
Electronic Display Type Cycle Indicator Lights
LED Color Blue

Cycles

Number of Wash Cycles 3
Washer Cycle Selections Colors; Delicates; Whites

Modifiers

Number of Wash/Rinse Temperatures 3
Rinse Temperature Cold; Hot; Warm

Certifications

ADA Compliant ADA Compliant with Optional Pedestal
CEE Tier Rating Tier II
prop65 CA

Exterior details

Lid/Door Swing Left
Window Yes

Interior details

Advanced Vibration Control Yes
Automated Dispenser Precision Dispense
Automatic Load Size Sensing Technology Yes
Dispense System Detergent, Fabric Softener & Bleach
Washer Drum Material Stainless Steel

Performance details

Motor Horsepower 1/2 HP

Product details

Energy Star® Qualified ENERGY STAR® Qualified

Dimensions & weight

Length 28.81 in.
Weight 244 lbs.
Full Width Console Yes
carton depth 33.5
carton height 40.5
carton width 29
gross weight 244
net weight 235
Width 29 in.
Height 40.5 in.

Number of boxes, shipping dimensions, & shipping weight

Number of Boxes 1
Shipping Width 29 in.
Shipping Height 40.5 in.
Shipping Length 33.81 in.
Shipping Weight 284 lbs.
Total of Shipping Weight 284 lbs.
Source Calculation

Capacity

Volume 22.77 Cu.Ft.

Cubic feet measurement & dimensional weight

Cubic Feet Measurement 19.58 ft³
Dimensional Weight 243.46 lbs.
Total of Cubes 19.58 ft³
Total of Dimensional Weight 243.46 lbs.

Description

Give your customers the sustained performance they expect over time with this commercial front-load, single-load washer. Combining the constant, reliable action of the drive system with regular cycle times from automatic load balancing helps provide optimal cleaning, load after load keeping customers happy and getting the job done. Plus, we re backing it with a 90-Day Labor, Two-Year Limited Parts-Only Warranty.



Product Features

  • Commercial-Grade Cabinet
    Built from heavy, galvanized steel, this cabinet is designed to keep up with traffic in a commercial laundry space.
  • Triple-Lip Seal with Garter Spring
    Provides an effective seal, helping to reduce potential moisture contamination. Addition of garter spring enhances spring support if any deflection occurs.
  • Premium Bearings
    Oversized, premium NSK bearings are sealed for added protection.
  • Six-Point Suspension
    Provides optimal stability for entire wash unit as a result of four dampers and two springs.
  • Powerful Drive System
    The robust drive system is designed and tested to last in the commercial environment, giving your customers the performance they expect over time.
  • Microprocessor Controls
    Controls offer owners the ability to customize vend prices and washer cycle options, such as Super Cycle, ensuring optimal revenue opportunities. Controls also give customers the option to select the ideal cycle for individual wash needs.
  • Redesigned Bellow
    The redesigned bellow helps keep small items from getting caught or snagged, ensuring all items get an equal clean.
  • Durable Dispenser
    The durable soap dispenser offers the end user convenient space to load detergent, and its sturdiness adds to the machine's overall durability.
  • Shaft Sleeve
    Helps to prevent drive shaft wear. The robust axial compression tube locks the two inner races of the premium NSK bearings ensuring they turn with the shaft, helping to prevent drive shaft wear.
  • Trunnion
    Shock-resistant, cast-metal trunnion provides additional strength to overall drive system and basket structure.
  • Card Reader Compatible
  • Accelerometer
    Detects unbalanced loads and redistributes to finish the final spin.
  • Multi-Level Pricing
    To help maximize revenue options, owners have the ability to price each cycle independently.
  • Cycle Modifiers
    Price cycles individually, add a rinse or modify water temperature.
  • Time of Day Pricing
    Controls offer the flexibility to program different vend pricing based on the day of the week and time of day.
  • Progressive Spin Logic
    Delivers consistent cycle times by reallocating weight to complete spin out of unbalanced loads.
  • Water Inlet Hose Included
    The durable water inlet hose is robust and resists kinking or bending, helping the machine operate at full capacity.
  • ADA Compliant with Optional Pedestal Installed
  • Optional Pedestals Sold Separately
    4" Pedestal (WHP0400VW) or 10" Pedestal (WHP1000VW)
  • Robust Hinge
    This door hinge is built to maintain its integrity and aesthetics.
  • Automatic Load Balancing
    A six point suspension with four dampers and two springs help deliver consistent cycle times and optimal unbalanced performance.
  • Super Cycle
    Super Cycle offers an extra three minutes of wash time or an additional rinse for an additional cost to the user, boosting revenue opportunities.
  • High-Efficiency Design
    Helps reduce energy and water costs.
  • Front-Access Panel
    The front-access panel provides fast entry to the motor, transmission, and wash tub for streamlined self-service.
  • 90-Day Labor, Two-Year Limited Parts-Only Warranty
    This quality dryer is backed with a 90-Day Labor, Two-Year Limited Parts-Only Warranty.
  • Front Access Panel
    The front-access panel streamlines self-service by providing quick entry to the motor, transmission, and wash tub—minimizing downtime and helping to keep the machine running and generating revenue.
  • Large Capacity Wash Basket
    Ideal for Family-Size Loads
  • Time-of-Day Pricing
    Controls offer the flexibility to program different vend pricing based on the day of the week and time of day. This allows owners to take full advantage of revenue-generating opportunities for their operation.

From The Manufacturer

Reviews

  • Product Details
  • Manuals & Guides
  • From The Manufacturer
  • Reviews
Sale price $2,817.89 Regular price $4,518.82 Save $1,700.93 / 37% OFF

Product Details for Whirlpool CED9160GW

Technical Details

Controls

Control Type Electronic
Neon Indicator Yes
Front Controls Yes

Details

Electronic Burner Ignition Yes
5 Rib Belt Yes
Blower Guard Yes
Door Opening Direction Right
Front Serviceable Yes
Fuel Type Electric
Heating Elements 5, 600
Industrial Grade Cabinet Yes
Large Lint Screen Yes
Machine in Use Indicator Yes
Time Remaining Display Yes

Cycles

Number of Dryer Cycles 3
Drying Cycles Selections Colors/Delicates; Cotton/Whites; Permanent Press

Exterior details

Reversible Door Yes
Window Yes

Installation considerations

Exhaust Diameter 4
Four Way Venting Yes

Interior details

Drum Speed 50
Dryer Drum Material Powder Coat
Lint Screen Location Front

Modifiers

Number of Temperatures 3

Performance details

Motor Horsepower 1/3 HP

Dimensions & weight

Length 29 in.
Weight 160 lbs.
Full Width Console Yes
carton depth 31
carton height 44
carton width 29.5
gross weight 160
net weight 147
Width 29.5 in.
Height 44 in.

Number of boxes, shipping dimensions, & shipping weight

Number of Boxes 1
Shipping Width 29.5 in.
Shipping Height 44 in.
Shipping Length 34 in.
Shipping Weight 200 lbs.
Total of Shipping Weight 200 lbs.
Source Calculation

Capacity

Volume 23.286 Cu.Ft.

Certifications

prop65 CA

Cubic feet measurement & dimensional weight

Cubic Feet Measurement 21.78 ft³
Dimensional Weight 270.81 lbs.
Total of Cubes 21.78 ft³
Total of Dimensional Weight 270.81 lbs.

Description

Get an extra boost in customer satisfaction with this commercial front-load dryer. Backed by the trusted Whirlpool name, this machine offers exceptional drying. A cabinet made of commercial-grade steel and porcelain-enamel top protect the machine from heavy use over time. Microprocessor controls offer easy, streamlined use and intuitive diagnostics for quick service. Plus, it s backed by our 90-Day Labor, Two-Year Limited Parts-Only Warranty.



Product Features

  • Porcelain-Enamel Top
    The premium porcelain-enamel top and lid possess a quality finish that lends to the machine's longevity.
  • ADA Compliant with or without Optional Pedestal
  • Microprocessor Controls
    Microprocessor controls offer flexibility and individual cycle pricing options for optimal earnings, while end users can easily choose their preferred wash experience with one-touch cycle selection. In addition, the display clearly conveys prices, selections, and time remaining. Built-in diagnostics help streamline service calls.
  • Optional pedestals sold separately
    4" Pedestal (WHP0400VW) or 10" Pedestal (WHP1000VW)
  • 90-Day Labor/Two-Year Limited Parts Only Warranty
    This quality dryer is backed with a 90-Day Labor, Two-Year Limited Parts-Only Warranty
  • Front-Access Panel
    Provides quick entry to the motor, transmission, and wash tub for service.
  • Extra-Large Capacity
    The extra-large, 6.7-cu.-ft. capacity means loads from small to large can be dried efficiently and effectively.
  • Simple Programming
    Gets machines up and running quickly and efficiently.
  • One-Touch Cycle Selection
    Simple, one-touch cycle selection provides clear options for end users.
  • Matching Washer Available
    The matching commercial-grade, single-load, front-load washer gets the job done, time after time.
