Sale price $1,327.47 Regular price $1,749.97 Save $422.50 / 24% OFF

Product Details for SUMMIT TEM630BKWY

Technical Details

Warranty

Parts 1 Year
Labor 1 Year

Dimensions & weight

Width 24 in.
Height 44 in.
Length 24 in.
Weight 135 lbs.

Cubic feet measurement & dimensional weight

Cubic Feet Measurement 14.67 ft³
Dimensional Weight 182.33 lbs.
Total of Cubes 14.67 ft³
Total of Dimensional Weight 182.33 lbs.

Overview electric range

Nominal Height 44.0" (112 cm)
Height of Cabinet 44.0" (112 cm)
Nominal Width 24.0" (61 cm)
Width 24.0" (61 cm)
Nominal Depth 24.0" (61 cm)
Depth 24.0" (61 cm)
Door Stainless Steel
Cabinet Black
Voltage/Frequency 220 V AC/60 Hz
Weight 135.0 lbs. (61 kg)
Parts & Labor Warranty 1 Year
UPC 761101005027
Oven Capacity 2.92 cu.ft. (83 L)
Cooktop Surface Porcelain
Element Type Coils
Number of Elements 4
Element #1 Size 6.0" (15 cm)
Element #1 Wattage 1500.0
Element #2 Size 6.0" (15 cm)
Element #2 Wattage 1500.0
Element #3 Size 6.0" (15 cm)
Element #3 Wattage 1500.0
Element #4 Size 8.0" (20 cm)
Element #4 Wattage 2400.0
Burner Controls Dial
Oven Controls Dial
Oven Light Yes
Cooking Timer Yes
Backguard Yes
Backguard Display Yes
Oven Rack Qty 2
Oven Window Yes
Oven Interior Height 14.0" (36 cm)
Oven Interior Width 19.0" (48 cm)
Oven Interior Depth 19.0" (48 cm)
Storage Compartment Yes
Broiler Location Inside Oven

Description

Summit Appliance offers a wide selection of American-made household ranges built for long-lasting durability in space-challenged kitchens. The TEM630BKWY is an apartment-sized 220V electric range sized at just 24" wide, with a generous 2.92 cu.ft oven interior that can accommodate large trays. The oven window and interior light with an on/off switch make it easy to monitor your cooking without opening the door. Two adjustable oven racks are included. The waist-high broiler is located inside the oven, allowing you to switch functions without moving contents to a separate compartment on the floor. The lower drop-down storage compartment is ideal for keeping pots and pans out of the way in small kitchens. Designed to meet the most current UL-858 safety standards, this unit features one 8" 2400W and three 6" 1500W coil elements with a safety sensor that will cycle the element off before reaching dangerous flashpoint temperatures. Heating resumes automatically. Upfront push-to-turn knobs offer additional protection, ensuring users won't reach over hot burners to adjust the heat. This unit complies with ADA guidelines. Stainless steel doors feature professional style towel bar handles, bringing classic elegance to smaller kitchen spaces.The deluxe 8" high backguard includes a digital clock and timer for added convenience when cooking. This unit has a recessed oven door and is conveniently sized at just 24" deep for a better fit in galley in L-shaped kitchens, where every inch counts. We include an anti-tip bracket for added safety. This unit does not include a line cord (a standard 40 amp 3 or 4-prong cord can be installed by your electrician). With its classic style and quality construction, Summit's made in the USA cooking line offers reliable cooking for smaller homes. Additional choices are available in 20", 30", and 36" wide fits.


Product Features

  • Slim 24 inch width
    Apartment-sized width offers all the functionality you need in a smaller footprint
  • Made in the USA
    Designed and constructed domestically
  • Professional towel bar handles
    Curved handles in brushed stainless steel offer an easier grip in attractive style
  • 24 inch depth
    Shallower fit is ideal for L-shaped and galley kitchens
  • Stainless steel finish
    Doors and backguard are constructed from brushed stainless steel for modern luxury built to last
  • Four coil elements
    Three standard 6" and one large 8" element
  • Chrome drip pans
    Each coil element includes a removable chrome pan for easier cleaning
  • Oven window and interior lighting
    Door includes a window and exterior on/off rocker light switch, making it easier to monitor your cooking without opening the door
  • Storage compartment
    Bottom drop-down compartment is ideal for storing cookware, helping to free up space in your small kitchen
  • Adjustable oven racks
    Two wire racks with safety brakes included, with several glide positions to accommodate a variety of sizes
  • Porcelain and steel construction
    Solid construction built to hold up to everyday use
  • Recessed oven door
    Smart design limits the depth and protects adjacent cabinets
  • Upfront oven/burner controls
    All knobs are located in the front of the range, letting you adjust your heating without reaching over hot burners
  • Deluxe backguard
    8" high backguard helps to protect your walls from spills and splashes
  • Push-to-turn knobs
    Burner knobs require a small amount of force to turn on for added protection against accidents; oven knob is not push-to-turn
  • Indicator lights
    Control panel includes an 'on' light for the oven and burners for added safety when using the range
  • Broiler pan included
    Two-piece porcelain broiler tray with grease well
  • Anti-tip bracket
    Included for user installation to help prevent tipping
  • Cord not included
    Compatible with standard 40 amp 3 or 4-wire range cords
  • ADA compliant design
    Upfront controls and easy-to-operate knobs offer easier accessibility that complies with the Americans for Disabilities Act (ADA) guidelines
  • Meets UL-858
    Designed to comply with the latest UL safety standards, the elements include a sensor that will cycle the element off and on if it reaches flashpoint temperature
  • Waist-high broiler
    Broiler is located inside the oven, eliminating the need to transfer contents to a separate compartment towards the floor
  • Digital clock and timer
    Backguard includes clock and timer for added convenience
  • Removable oven door and range top
    Allows for easier cleaning as needed
