Sale price $1,358.97 Regular price $1,779.97 Save $421.00 / 23% OFF

Product Details for SUMMIT TEM230BKWY

Technical Details

Warranty

Parts 1 Year
Labor 1 Year

Dimensions & weight

Width 30 in.
Height 44 in.
Length 24 in.
Weight 160 lbs.

Cubic feet measurement & dimensional weight

Cubic Feet Measurement 18.33 ft³
Dimensional Weight 227.91 lbs.
Total of Cubes 18.33 ft³
Total of Dimensional Weight 227.91 lbs.

Overview electric range

Nominal Height 44.0" (112 cm)
Height of Cabinet 44.0" (112 cm)
Nominal Width 30.0" (76 cm)
Width 30.0" (76 cm)
Nominal Depth 24.0" (61 cm)
Depth 24.0" (61 cm)
Door Stainless Steel
Cabinet Black
Voltage/Frequency 220 V AC/60 Hz
Weight 160.0 lbs. (73 kg)
Parts & Labor Warranty 1 Year
UPC 761101012902
Oven Capacity 3.7 cu.ft. (105 L)
Cooktop Surface Porcelain
Element Type Coils
Number of Elements 4
Element #1 Size 6.0" (15 cm)
Element #1 Wattage 1500.0
Element #2 Size 6.0" (15 cm)
Element #2 Wattage 1500.0
Element #3 Size 6.0" (15 cm)
Element #3 Wattage 1500.0
Element #4 Size 8.0" (20 cm)
Element #4 Wattage 2400.0
Burner Controls Dial
Oven Controls Dial
Oven Light Yes
Cooking Timer Yes
Backguard Yes
Backguard Display Yes
Oven Window Yes
Oven Interior Height 14.0" (36 cm)
Oven Interior Width 24.0" (61 cm)
Oven Interior Depth 19.0" (48 cm)

Description

Summit Appliance offers a wide selection of American-made household ranges built for long-lasting durability in space-challenged kitchens. The TEM230BKWY is an apartment-sized 220V electric range sized at 30" wide, with a generous 3.7 cu.ft oven interior that can accommodate large trays. The oven window and interior light with an on/off switch make it easy to monitor your cooking without opening the door. Two adjustable oven racks are included. The waist-high broiler is located inside the oven, allowing you to switch functions without moving contents to a separate compartment on the floor. The lower drop-down storage compartment is ideal for keeping pots and pans out of the way in small kitchens. Designed to meet the most current UL-858 safety standards, this unit features one 8" 2400W and three 6" 1500W coil elements with a safety sensor that will cycle the element off before reaching dangerous flashpoint temperatures. Heating resumes automatically. Upfront push-to-turn knobs offer additional protection, ensuring users won't reach over hot burners to adjust the heat. Stainless steel doors feature professional style towel bar handles, bringing classic elegance to smaller kitchen spaces.The deluxe 8" high backguard includes a digital clock and timer for added convenience when cooking. This unit has a recessed oven door and is conveniently sized at just 24" deep for a better fit in galley in L-shaped kitchens, where every inch counts. We include an anti-tip bracket for added safety. This unit does not include a line cord (a standard 40 amp 3 or 4-prong cord can be installed by your electrician). With its classic style and quality construction, Summit's made in the USA cooking line offers reliable cooking for smaller homes. Additional choices are available in 20", 24", and 36" wide fits.


Product Features

  • 24 inch depth
    Shallower fit is ideal for L-shaped and galley kitchens
  • Electric Range
    30" wide 220V electric range with coil elements and a full-sized oven
  • Made in the USA
    Designed and constructed domestically
  • 30 inch wide range
    Standard size ideal for most kitchens
  • Professional towel bar handles
    Curved handles in brushed stainless steel offer an easier grip in attractive style
  • Four coil elements
    Three standard 6" 1500W and one large 8" 2400W element
  • Meets UL-858
    Designed to comply with the latest UL safety standards, the elements include a sensor that will cycle the element off and on if it reaches flashpoint temperature
  • Chrome drip pans
    Each coil element includes a removable chrome pan for easier cleaning
  • Stainless steel finish
    Doors and backguard are constructed from brushed stainless steel for modern luxury built to last
  • Storage compartment
    Bottom drop-down compartment is ideal for storing cookware, helping to free up space in your small kitchen
  • Oven window and interior lighting
    Door includes a window and exterior on/off rocker light switch, making it easier to monitor your cooking without opening the door
  • Adjustable oven racks
    Two wire racks with safety brakes included, with several glide positions to accommodate a variety of sizes
  • Deluxe backguard
    8" high backguard helps to protect your walls from spills and splashes
  • Digital clock and timer
    Backguard includes time readout
  • Upfront oven/burner controls
    All knobs are located in the front of the range, letting you adjust your heating without reaching over hot burners
  • Push-to-turn knobs
    Burner knobs require a small amount of force to turn on for added protection against accidents; oven knob is not push-to-turn
  • Indicator lights
    Control panel includes an 'on' light for the oven and burners for added safety when using the range
  • Recessed oven door
    Smart design limits the depth and protects adjacent cabinets
  • Porcelain and steel construction
    Solid construction built to hold up to everyday use
  • Broiler pan included
    Two-piece porcelain broiler tray with grease well
  • Anti-tip bracket
    Included for user installation to help prevent tipping
  • Cord not included
    Compatible with standard 40 amp 3 or 4-wire range cords
  • ADA compliant design
    Upfront controls and easy-to-operate knobs offer easier accessibility that complies with the Americans for Disabilities Act (ADA) guidelines
  • Waist-high broiler
    Broiler is located inside the oven, eliminating the need to transfer contents to a separate compartment towards the floor
  • Removable oven door and range top
    Allows for easier cleaning as needed
