SKU: AFZ5PVBIADAMC | UPC: 761101107509

Summit AFZ5PVBIADAMC 4 Cu.Ft. MOMCUBE Freezer, ADA Height White

Quick Specification More details

Width:
23.38"
Depth:
22" - 25"
Height:
31.75"
Type:
Mini Refrigerators

About this product

Performance MOMCUBE Breast Milk Freezer freezer
Purpose-built design
Adjustable temperature
Recessed or freestanding use

Clearance

SKU: AFZ5PVBIADAMC | UPC: 761101107509

Summit AFZ5PVBIADAMC 4 Cu.Ft. MOMCUBE Freezer, ADA Height White

Active Rebates

We’ll confirm fit, specs & delivery before you order.

• Chat • Email • Call Us

Quick Specification More details

Width:
23.38"
Depth:
22" - 25"
Height:
31.75"
Type:
Mini Refrigerators

About this product

Performance MOMCUBE Breast Milk Freezer freezer
Purpose-built design
Adjustable temperature
Recessed or freestanding use

Product Details
Manuals & Guides
From The Manufacturer
Reviews

Product Details for Summit AFZ5PVBIADAMC

Technical Details

Freezer

Door Swing	RHD
Reversible	Yes
Interior Height	22.5" (57 cm)
Interior Width	18.0" (46 cm)
Interior Depth	18.0" (46 cm)
Shelf Type	Wire
Shelf Qty	4
Adjustable Shelves	Yes
Thermostat Type	Digital
Interior Light	Yes
Refrigerant Type	R290
Refrigerant Amount	1.73 oz.
High Side PSI	280.0
Low Side PSI	130.0
Compressor Step Height	6.5" (17 cm)
Compressor Step Width	18.0" (46 cm)
Compressor Step Depth	7.13" (18 cm)
Temperature Range	-18 to -4ºF

Dimensions & weight

Width	23.38 in.
Height	31.75 in.
Length	25 in.
Weight	125 lbs.

Cubic feet measurement & dimensional weight

Cubic Feet Measurement	10.74 ft³
Dimensional Weight	133.51 lbs.
Total of Cubes	10.74 ft³
Total of Dimensional Weight	133.51 lbs.

Other

Number of Boxes	1
Source	Calculation
Capacity	3.88 cu.ft. (110 L)
Defrost Type	Manual
Door	White
Cabinet	White
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Amps	1.3
Voltage/Frequency	115 V AC/60 Hz
Parts & Labor Warranty	2 Years
Compressor Warranty	5 Years
UPC	761101107509

Description

Accucold's MOMCUBE freezers are designed and purpose-built for breast milk storage. All MOMCUBE® units are laboratory-tested to maintain proper breast milk temperature, as recommended by the CDC and ideal for maternity wards, hospitals, NICUs, employee wellness rooms complying with Section 4207 of the Patient Protection and Affordable Care Act, and other facilities. The AFZ5PVBIADAMC is a 4 cu.ft. all-freezer with a temperature range of -18°F to -4°F as recommended for the long-term storage of human milk. The microprocessor temperature controller is externally located to minimize door openings, helping to protect stored contents from ambient temperature. The buffered temperature probe is encased in a glycol-filled bottle to better simulate temperature of the stored milk product, with an additional sensor that reads air temperature to ensure superior temperature control. The current and min/max temperature display is viewable in Celsius or Fahrenheit to the nearest tenth of a degree. The audible and visual temperature alarm sounds if the unit's interior goes out of range. Additional alarms include a power failure alert, door open alarm, and sensor failure alarm. This model is equipped with remote alarm contacts in the rear and a 1/2" probe port on the right side to accept additional monitoring devices. A hospital grade cord with 'green dot' plug is also included for added safety in high traffic areas. Inside, this freezer features adjustable plastic-coated wire shelves that can be positioned at 1/2" increments to accommodate virtually any sized item. This unit includes LED internal lighting with an on/off rocker switch. The interior is constructed from white powder coated metal to ensure added durability and better temperature retention. Static manual defrost cooling helps to ensure stable temperature conditions. The AFZ5PVBIADAMC comes in a white cabinet finish with a blue accented control panel. The factory-installed antimicrobial handle is powder-coated with naturally occurring silver ions, which help to reduce the spread of germs, allowing for a safer, cleaner user experience. The user-reversible door ships with a right hand swing and self-closing function, while a factory-installed lock provides security as needed, with two keys for staff use. Powerful magnetic gaskets ensure a positive seal. Designed with hydrocarbon refrigerant, all Accucold Performance Series MOMCUBE freezers provide an energy efficient solution to breast milk storage. Additional sizes, as well as matching refrigerators, are also available. Explore the full Pharma-Vac series at accucold.com/momcube.

Product Features

Performance MOMCUBE Breast Milk Freezer freezer
Purpose-built Performance Series freezer for the long-term storage of breast milk
Purpose-built design
Designed and purpose-built for breast milk storage in accordance with the CDC's guidelines
Adjustable temperature
Intuitive controls let you adjust the interior temperature between -18°F to -4ºF
Recessed or freestanding use
Versatile design allows recessed installation under counters or freestanding use
ADA Compliant
Just under 32" tall designed to fit under ADA compliant counters
+/-1ºC Variation
The published temperature variation is derived from the maximum deviation of an NTC sensor in a 1 oz. vial located nearest the chamber geometric center during a 24 hour test period
Temperature alarm
Visual and audible alarms alert if the interior temperature rises or falls out of set range
Remote alarm contacts
Electronic controller is equipped with a volt-free contact for alarm forwarding to an external remote system (contacts located in the external rear of the unit)
Manual defrost operation
Static cooling system for an efficient and stable interior
Access port
Includes a pre-installed 1/2" probe hole in the right interior wall to allow easier connection to user-provided monitoring equipment
Open door alarm
Alarm will sound if the door is left ajar for over 4 minutes (adjustable from 1-99 minutes)
Audible power failure alarm
Battery-powered alarm sounds if the power connection is interrupted
Sensor failure alarm
Audible and visual alarm warns if the sensor is disrupted
Password protection
Control panel requires password entry to adjust the parameters beyond the set point
Microprocessor control panel
Digital controls with a large LED readout in Celsius or Fahrenheit for intuitive temperature management
Resettable min/max display
Control panel provides a readout of the low and high temperatures in 15 minute increments
Factory-installed lock
Keyed lock conveniently located towards the top of the door for added security (2 keys included)
Antimicrobial silver ion-coated handle
Powder-coated handle with naturally occurring silver ions to help reduce the spread of germs
Adjustable plastic-coated wire shelves for improved circulation
Shelves can be positioned with a front lip for small storage items or reversed to a flat position to better hold larger items, with multiple shelf positions spaced at 1/2" to accommodate virtually any size
Hospital grade cord with 'green dot' plug
Secure three-pronged cord for added unit safety
Durable interior
Walls are constructed from white powder coated metal for added strength and improved temperature retention
Interior light
Energy efficient LED lighting with internal on/off switch
Self-closing door
Added protection in busy settings
Reversible door
User-reversible door swing for added flexibility
Magnetic door gasket
Quality door gaskets ensure a tight seal for energy savings and improved performance
Fully finished white cabinet
Allows the unit to be used freestanding
Extended warranty
2 years parts and labor/5 years compressor
Eco-Friendly
Using environmentally friendly hydrocarbons refrigerants for a greener footprint
Versatile design
Compatible with Pyxis, Omnicell®, and AcuDose RX®
Usage stickers
Ships with removable warning stickers for "DO NOT UNPLUG," "DO NOT ADJUST TEMPERATURE," and "DO NOT STORE PERSONAL ITEMS", as well as breast milk storage guidelines
CARB Compliant
Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
100% CFC free
Environmentally friendly design without ozone-damaging chemicals
