SKU: PT2AFSFS

Hoshizaki PT2AFSFS Refrigerator, Two Section Pass Thru Upright, Full Stainless Doors with Lock Stainless Steel

Quick Specification More details

Width:
55"
Depth:
35.75"
Height:
79.5"
Type:
Specialty Refrigerators

About this product

Interior capacity of 52.5 cubic feet
Epoxy electrocoated (E-Coat) evaporator coil to help fight corrosion for extended life
Stainless steel exterior (front, sides, top) and a stainless steel interior
One piece, full door length, extruded aluminum flush mount door handle

Summer Sale

Clearance

SKU: PT2AFSFS

Hoshizaki PT2AFSFS Refrigerator, Two Section Pass Thru Upright, Full Stainless Doors with Lock Stainless Steel

Active Rebates

We’ll confirm fit, specs & delivery before you order.

• Chat • Email • Call Us

Quick Specification More details

Width:
55"
Depth:
35.75"
Height:
79.5"
Type:
Specialty Refrigerators

About this product

Interior capacity of 52.5 cubic feet
Epoxy electrocoated (E-Coat) evaporator coil to help fight corrosion for extended life
Stainless steel exterior (front, sides, top) and a stainless steel interior
One piece, full door length, extruded aluminum flush mount door handle

Product Details for HOSHIZAKI PT2AFSFS

Technical Details

Dimensions & weight

Weight	592 lbs.
Width	55 in.
Depth	35.75 in.
Height	79.5 in.

Number of boxes, shipping dimensions, & shipping weight

Number of Boxes	1
Shipping Weight	632 lbs.
Total of Shipping Weight	632 lbs.
Source	Calculation

Product details

Electrical Specs	Electrical Connection: 5 – 15P NEMA, 115v/60/1, 10 ft. cord and plug, Energy Consumption: 3.24 kwh/day, Amperage: 8, Max Fuse/HACR Breaker: 15 A
Operating Limits	Ambient Temp Range: 45 – 100°F, Voltage Range: 104 – 126V, Control Setpoint Range: 31 – 52°F, Refrigerant: R290
Refrigeration Data	Nominal Compres. of 1545 BTU/hr at 1/2 HP, Heat Rejection: 1429 BTU/hr
Shipping Weight	592
Storage Specs	Interior storage capacity: 52.5 ft3, Door opening: 21.75″ W x 59.25″ H, Depth with both doors fully extended: 87.25″ D, Shelves included: 6

Warranty

Parts	7 Years
Labor	7 Years
Compressor	7 Years

Description

The PT2A-FS-FS Steelheart Series Pass Thru two section refrigerator with full stainless doors is a space saving workhorse. Solid state digital controller with temperature alarms and LED display (°F or °C). With a interior capacity of 52.5 cubic feet this efficient pass thru refrigerator and front air flow design is perfect for hot/tight kitchens. The PT2A-FS-FS is constructed of stainless steel, which protects this unit from accidental damage and rust. Plus, it is easy to clean.

Product Features

Interior capacity of 52.5 cubic feet
Epoxy electrocoated (E-Coat) evaporator coil to help fight corrosion for extended life
Stainless steel exterior (front, sides, top) and a stainless steel interior
One piece, full door length, extruded aluminum flush mount door handle
Lockable Full Stainless Doors
Interior LED light bar is mounted horizontally on the ceiling
R290 refrigerant
Nominal Compres. of 1545 BTU/hr at 1/2 HP
115v/60/1, 10 ft. cord and plug
Top mounted energy efficient non-electric evaporation system
Unique “ducted” air distribution system
7-7-7 Warranty (seven years labor, seven years parts, seven years compressor)
