| Overall Width | 20.125 in |
| Overall Depth | 17.75 in |
| Overall Height | 20 in |
| Net Weight | 64 lb |
| Approximate Shipping Weight | 71 lb |
| Cooktop Burner Grate Color | Matte Black |
| Oven Door Features | Oven Window |
| Installation | RV Ready |
| Control Knobs | Black |
| Handle Color | Black |
| Color Appearance | Black |
| Oven Door Features | Glass Door |
| Ignition System | Piezo |
| Burner - Right Rear | 6,500 BTU |
| Interior Oven Light | Halogen |
| Fuel Type | Liquid Propane Gas |
| Flame Detection | Yes |
| Oven Interior | Easy Clean Interior |
| Oven Control Features | Light On/Off |
| Cooktop Burner Type | Sealed |
| Oven Rack Features | 1 Nickel |
| Burner - Left Rear | 6,500 BTU |
| Product Type | Drop-In |
| Cooktop Burner Grate Material | Continuous Cast Iron |
| Cooktop Burner Grate Features | Matte Black |
| Valves (Degree of Turn) | 260 |
| Burner - Center | 8,000 BTU Center Front |
| RV Ready | Yes |
| Cooktop Surface | Porcelain-Enamel |
| Control Location | Front Controls |
| Oven Rack Positions (Single or Upper/Lower) | 3 |
| Cooking Technology | Traditional |
| Cooktop Burner Grate Features | Edge-to-Edge Grates |
| Cooktop Burner Grate Features | Continuous Grates |
| Cooktop Burner Grate Features | Fixed to prevent vibration, but removable |
| Oven Interior | Black Enamel |
| Warranty Notes | See written warranty for full details |
| Labor Warranty | Limited 2-year entire appliance |
| Parts Warranty | Limited 2-year entire appliance |
| Bake/Broiler BTU Rating - LP (000's BTU's) | 7.1 BTU Bake |
| Volts/Hertz | 12V DC |
| Electrical Requirements | 12V |
| Hertz | 60 |
| Cover Accessory (sold separately) | JXCVR21 |
| Width | 20.13 in. |
| Height | 20 in. |
| Length | 17.75 in. |
| Weight | 64 lbs. |
| Number of Boxes | 1 |
| Shipping Width | 25.13 in. |
| Shipping Height | 25 in. |
| Shipping Length | 22.75 in. |
| Shipping Weight | 104 lbs. |
| Total of Shipping Weight | 104 lbs. |
| Source | Calculation |
| Cubic Feet Measurement | 4.13 ft³ |
| Dimensional Weight | 51.4 lbs. |
| Total of Cubes | 4.13 ft³ |
| Total of Dimensional Weight | 51.4 lbs. |
| Total Capacity (cubic feet) | 1.80 cu ft |
