FRIGIDAIRE 5304508690 Frigidaire ReadyClean™ Glass and Ceramic Cooktop Cleaner
- SKU: 5304508690
- Type: Misc accesories
- Height: 0 Inch
- Width: 0 Inch
More on the way
Extend your appliance's warranty beyond the manufacturer's terms with our Extended Protection Plan.
Enjoy added peace of mind long after the original warranty expires.
This Protection Plan includes:
Product Line | Electric Cooktop |
Power Type | Electric 240v |
Size | 30" |
Installation Type | Built-In |
Factory | Rayong |
Color | Black Stainless Steel |
Installation | |
Installed Over a Wall Oven | Yes |
Power Supply Connection Location | Right Center |
Electrical Specifications | |
Amps @ 240 Volts | 38.3 Amps |
Connected Load @ 240V | 9.2 kW |
Minimum Circuit Required | 40 Amps |
Voltage Rating | 240 V |
Certifications and Approvals | |
ADA Compliant | Yes |
Cooktop | |
Cooking Surface Type | Smooth |
Hot-Surface Indicator Light | Yes |
Dimensions and Volume | |
Height | 2 5/8" |
Width | 30 5/8" |
Depth | 21 3/8" |
Cutout Height | 5" |
Minimum Cutout Width | 28 1/2" |
Minimum Cutout Depth | 19 5/8" |
Maximum Cutout Width | 29 7/8" |
Maximum Cutout Depth | 20 1/2" |
Safety Certifications and Approvals | |
CSA Listed | Yes |
UL Listed | Yes |
Controls | |
Sabbath Mode | No |
General Specifications | |
Frigidaire Fit Promise | Yes |
Product Weight | 31 lbs |
Prop 65 Label | Yes |
Warranty - Labor | 1 Year |
Warranty - Parts | 1 Year |
Cooktop Performance | |
Right Front Element Burner Size | 7" |
Right Rear Element Burner Size | 6" |
Left Front Element Burner Size (Small) | 5" |
Left Front Element Burner Size (Large) | 7" |
Left Rear Element Burner Size | 6" |
Center Rear Element Burner Size | 9" |
Right Front Element Burner | 1,800 Watts |
Right Rear Element Burner | 1,200 Watts |
Left Front Element Burner (Small) | 750 Watts |
Left Front Element Burner (Large) | 1,800 Watts |
Left Rear Element Burner | 1,200 Watts |
Center Rear Element Burner | 3,200 Watts |
Display | |
Control Location | Front |
Display Type | Mechanical |
