Product Details for Forno FFSGS626030RED

Technical Details

Dimensions & weight

Width 30 in.
Height 28 in.
Length 37.4 in.
Weight 231 lbs.
Overall Height - Top to Bottom (in) 38
Overall Width - Side to Side (in) 30
Overall Depth - Front to Back (in) 28
Interior Height - Top to Bottom (in) 16
Interior Width - Side to Side (in) 24.92
Interior Depth - Front to Back (in) 18.7
Cutout Width - Side to Side (in) 30
Cutout Height - Top to Bottom (in) 36
Cutout Depth - Front to Back (in) 25
Overall Product Weight (lbs) 227.07
Depth with door open 90° (in) 44.25
Cutout Dimensions 30.25"W x 28″D
Oven Interior Dimensions 24.92"W x 16″H x 18.7″D

Number of boxes, shipping dimensions, & shipping weight

Number of Boxes 1
Shipping Width 35 in.
Shipping Height 33 in.
Shipping Length 42.4 in.
Shipping Weight 271 lbs.
Total of Shipping Weight 271 lbs.
Source Calculation

Cubic feet measurement & dimensional weight

Cubic Feet Measurement 18.18 ft³
Dimensional Weight 226.01 lbs.
Total of Cubes 18.18 ft³
Total of Dimensional Weight 226.01 lbs.

Header

Model Number FFSGS6260-30RED
Brand Name FORNO
Product UPC 686136965002
Market CANADA,USA
Collection Name Alta Qualita
Serie's Name Capriasca
Product Name (Short & Sweet) < 36 Characters Capriasca 30" Freestanding Gas Range
Product Description (more detailed) <= 100 characters Capriasca 30-inch Gas Range Stainless Steel, 5 Brass Burners 100,000 BTU, 4.32 cu.ft. Oven
Product Description (more detailed) > 100 characters Capriasca 30-inch Freestanding Gas Range All Stainless Steel with Red Door, 5 Brass Burners 100,000 BTU, Wok Support, 4.32 cu.ft. Convection Oven with Rotisserie

Technical information

Color/Finish Stainless Steel
Burner Fuel Gas
LP gas convertible Yes
Total Cooktop BTU Output 100,000
Cooking Surface Control Type Push & Turn/Knobs
Simmer Burner Yes
Oval Burner No
Cooktop Surface Structure Grate; Deep Recessed
Number of Ovens 1
Overall Oven BTU 30000
Auto Re-Ignition Yes
Number of Knobs 6
Glide/Rollout Racks Yes
Racks Material Stainless-Steel
Oven Ignition Type Automatic Ignition
Broiler Location Oven
Overall Bake Element BTU 20000
Interior Light 2
Oven Preheating Indicator Yes
Storage Drawer No
Temperature Gauge No
Clock No
Oven Fuel Gas
Interior Light(s) Type Halogen
Knobs Color/Finish Zinc Coated
Cabinet Color Stainless Steel
Overall Capacity Cu. Ft. 4.32
Bulb Type G9
Fingerprint-Resistant No
Fuel Type Gas
Gas Type Natural Gas
Gas Heat Configuration (cooktop) Sealed Burner
Number of Burners/Cooking Zones 5
Cooking Surface Ignition Type Electronic
Number of Simmer Burner 5
Number of Oval Burner 0
Diswasher-Safe Grates No
Overall Oven Capacity (Cubic Feet) 4.32
Oven Control Type Manual/Knob
Automatic Shut-Off No
Number of Racks 3
Number of Rack Positions 5
Broiler Gas
Overall Broil BTU 10000
Automatic Convection Conversion No
Control Location Front
Cooktop Hot Surface Indicator No
Warmer Drawer No
Timer No
Primary Material Metal
Dual-Ring Burner Yes
Convection Oven Yes
Cabinet Material Stainless Steel

General product weight & dimensions

Product Overall Weight (lbs) 227.07
Product Dimensions W x D x H (inches) 30 x 28 x 38
Product Width (in) 30
Product Depth (in) 28
Product Height (in) 38
Cutout dimensions W x D x H (inch) 30 x 25 x 36
Cutout Width (INCH) 30
Cutout Depth (INCH) 25
Cutout Height (INCH) 36
Main Oven Interior Depth (IN) 18.70
Main Oven Interior Height (IN) 16.00
Main Oven Interior Width (IN) 24.92
Main Oven Usable Interior (W x D x H) 24 X 14 X 10.38

Certification

Safety Listing cETLus
Title 20 - California Regulation Does Not Apply
Star-K Certified Does Not Apply
ADA Compliant Does Not Apply

Warranty

Commercial Warranty No
Warranty on Parts 2 Years
Warranty Script (English) Experience peace of mind with FORNO products, each backed by a 2-year warranty covering labor and parts, ensuring satisfaction and confidence in the reliability of our high-quality appliances
Warranty Type Limited
Warranty on Labor 2 Years

Shipping

Shipping Method LTL
Shipping Weight Box 1 (Carton Weight + 35 lbs) 374.51
Needs to be shipped on a pallet Yes
Shipping Width Box 1 (with pallet) 40
Shipping Height Box 1 (Height carton + 6-inch of the pallet) 49.31

Description

The Forno Capriasca 30 Inch Gas Range enhances your home kitchen with professional styling and performance through its durable and beautiful 304-grade stainless-steel design. The cooking surface features 5 sealed dual-ring brass burners, totaling 100,000 BTU. All burners, each at 20,000 BTU, can simmer precisely at 1,000 BTU. Continuous heavy-duty cast-iron grates facilitate easy sliding of pots or pans off heat over the enamel cooktop cavity, simplifying spill cleanup. The 4.32 cu. ft. gas oven, with a 30,000 BTU output and infrared red mesh broiler, enclosed in a blue enamel interior, offers optional convection for precise, and consistent cooking on multiple levels. For convenient viewing, a 3-layer glass oven door window is included. The package includes 3 telescopic stainless-steel oven racks, wok support, and an LP conversion kit. Additionally, zinc-coated illuminated metal knobs with bezel rings ensure enduring beauty.

Please note: This model is composed of individual items that must be ordered separately to complete the kit.


Product Features

  • Continuous cast iron grates ensure even heat, providing cookware stability and mobility off the source.
  • 5 Sealed Dual-Ring Brass Burners combine a total stove-top out of 100,000 BTU
  • Sealed Dual-Ring Brass Burners can achieve high heat searing or delicate simmering control
  • Deep recessed black enamel range top cavity contains spills for quick clean-ups
  • 4.32 Cu.Ft Convection Fan Oven with 30,000 BTU Total Broil and Bake output
  • Insulated Oven Door with a 3-Layer Glass Window and Smooth Friction Hinges
  • 5 Sealed Dual-Ring Brass Burners combine a total of 100,000 BTU
  • Continuous Cast Iron Grates provide heat distribution
  • 4.32 Cu.Ft Convection Fan Oven
  • Adjustable Stainless Steel Legs Accommodate Counter Heights between 36” to 37”
  • 3 Heavy-Duty Stainless Steel Telescopic Oven Racks with ball bearing rack guides
  • Sealed burners for high heat searing or precise simmering control
  • Black Enamel Cooktop Cavity
  • Blue Oven with Smooth Friction Hinges
  • Stainless steel side panels allow for install at end of counter for long lasting beauty.
  • Includes Rotisserie Skewer & Forks, LP conversion kit and 3-Prong Plug
  • Speckled Blue Enamel Oven Interior with 2 Halogen Lights
  • Pro-Style Handles and Illuminated Zinc Coated Metal Control Knobs and Bezel Rings
