Product Details for FISHER & PAYKEL OR36SDG4X1
Technical Details
Warranty
| Parts | 2 Year |
| Labor | 2 Year |
| Parts and labor | 2 years |
Accessories (included)
| 2-pc grill system (Broil pan and Grill rack) | Yes |
| Broil pan | Yes |
| Broil rack | Yes |
| Chromed shelf runners | 1 set |
| Full extension telescopic shelves | 2 sets (part 578744) |
| Small pot support | 1 (part 533981 cast) |
Burner ratings
| Dual wok burner inner/outer (LPG) | 1000 - 18000BTU |
| Dual wok burner inner/outer (natural gas) | 1000 - 18000BTU |
| Maximum burner power | 18000 BTU |
| Semi-rapid burner (LPG) | 1500 - 7600BTU |
| Semi-rapid burner (natural gas) | 1500 - 8000BTU |
| Total cooktop power | 62000 BTU |
| Triple ring wok burner (LPG) x2 | 6100 - 12000BTU |
| Triple ring wok burner (natural gas) x2 | 6100 - 14000BTU |
Capacity
| Shelf positions | 7 |
| Total capacity | 4.9cu ft |
| Usable capacity | 3.8cu ft |
Cleaning
| Acid resistant graphite enamel | Yes |
| Dishwasher proof grates | Yes |
| Removable oven door | Yes |
| Removable shelf runners | Yes |
Controls
| Laser etched graphics | Yes |
Gas requirements
| Supply Pressure (LPG) | 11" W.C.P |
| Supply Pressure (natural gas) | 4" W.C.P |
Oven features
| Auto re-ignition system | Yes |
| Concealed element | Yes |
| Convection | Yes |
| Electronic ignition | Yes |
| Full extension telescopic sliding shelves | Yes |
| Soft open/close door | Yes |
| Storage drawer | Yes |
Oven functions
| Bake | Yes |
| Convection bake | Yes |
| Maxi Broil | Yes |
| Number of functions | 3 |
Oven performance
| Bake power | 17000 BTU |
| Broil | 13000 BTU |
| CoolTouch door | Quadruple glazed |
Power requirements
| Amperage | 15A |
| Supply frequency | 60Hz |
| Supply voltage | 120V |
Rangetop features
| Hob rail | Yes |
| LPG/Natural gas compatible | Yes |
| Sealed range top | Yes |
Safety
| ADA compliant | Yes |
| Advanced cooling system | Yes |
| Anti-tilt bracket | Yes |
| Balanced oven door | Yes |
| CoolTouch door | Yes |
| Full extension telescopic shelves | 2 sets (part 578744) |
| Full extension telescopic sliding shelves | Yes |
| Non-tip shelves | Yes |
| Spill containment | 5⁄8 gallon |
Dimensions & weight
| Width | 35 in. |
| Height | 35 in. |
| Length | 25 in. |
Number of boxes, shipping dimensions, & shipping weight
| Number of Boxes | 1 |
| Shipping Width | 40 in. |
| Shipping Height | 40 in. |
| Shipping Length | 30 in. |
| Source | Calculation |
Cubic feet measurement & dimensional weight
| Cubic Feet Measurement | 17.72 ft³ |
| Dimensional Weight | 220.32 lbs. |
| Total of Cubes | 17.72 ft³ |
| Total of Dimensional Weight | 220.32 lbs. |
Description
Make your range a focal point. With a large capacity oven and five burners, this is the perfect way to cook for a crowd.
Product Features
- Performance Power
- Design Quality
- Large Capacity
- Easy Cleaning
