Name: ZEPHYR DMEM90ASGX 36" Mesa Wall
Brand: ZEPHYR
SKU: DMEM90ASGX-KT
Price: 1999.00 USD
Availability: InStock

Key Specs

Type: Ductless hoods
Width: 35.31 Inch
Depth: 19.68 Inch
Height: 13.81 Inch

More details

Translation missing: en.products.product.product_variants

$1,999.00 $2,199.00 Save $200.00

Check Delivery Options

More on the way

Quantity:

Extended Protection

5 Year Major Appliance True Extended under $2,500.00
$195.99
3 Year Major Appliance True Extended under $2,500.00
$131.99
Decline Protection

Product Information
Technical Details
Manuals & Guides
Features
Videos
Reviews

General
Model: DMEM90ASGX
Brand: ZEPHYR
Color: SATIN GOLD
Height: 13.81
Width: 35.31
Length: 19.68
Cooking Capabilities
Number of Burners: 0
Number of Elements: 0
Convection: No
Self-Cleaning: No
Cooking Capabilities
Warming Drawer: No
Hidden element: No
Proof cook mode: No
Continuous grate: No
Down draft: No
Storage Drawer: No
Induction: No
Features
Sabbath mode: No
Recessed turntable: No
Number of Shelves: 0
Convection: No
Advanced Features
Wi-Fi Connectivity: No
Smart Features: No
Power & Consumption
Microwave wattage: 0
CFM: 0

Taking kitchen glamour to new heights, the Mesa Wall hood is available in three high-style finishes: satin gold, matte black, and stainless steel, for the very latest in kitchen design trends. With Invisible Touch Controls, hybrid baffle filters and multiple blower options, the Mesa is set to become the hardworking star of the most fashionable kitchens. Additional options include an accent rail in satin gold or stainless steel; remote control; and duct cover in satin gold, matte black, or stainless steel.

Brand	Zephyr
Manufacturer	Zephyr
Category	Range Hood
Sub-Category	Wall
Vent Type	Convertible
UPC	646328008863
GTIN	00646328008863
Country of Origin	Italy
Model Group	DME-A
Model Name	Mesa
Collection	Designer Collection
Blower Included	No
Internal Blower 1 CFM	600
Internal Blower 1 Min. Sones	1.4
Internal Blower 1 Max Sones	6
Internal Blower 2 CFM	290
Internal Blower 2 Max Sones	3
In-Line Blower CFM	1000
External Blower CFM	1000
Minimum CFM	200
Installation Type	Wall
For Outdoor Use	No
Color	Satin Gold
Controls Type	Invisible Touch
Blower Speeds	3
Automatic Delay-Off	Yes
Clean Air Function	Yes
Lighting Type	LED
Lights Quantity	2
Watts Per Bulb	5
Lights Levels	3
Grease Filter Type	Hybrid Baffle
Compatible Mesh or Baffle Filter Part Number	50210045
Duct Discharge	Vertical or Horizontal
Duct Size; Horizontal; IN	8
Duct Size; Vertical; IN	6, 8
Mounting Height Above Cooktop; IN	24 - 36
Voltage	120
Maximum Amperage	6.53
ADA Compliant	Yes, with optional remote
Warranty Parts / Labor	2 / 1
Compatible Appliances	CBI-390A, CBE-1000, CBI-290A, CBI-600A, PBN-1000A, CBI-290C, PBI-1000B-DME, Z0F-C010, Z1C-00MEMB, ZRC-01ME, MERAIL-00SG, MERAIL-00SS, MERAIL-00MB, MUA006A, MUA008A, Z1C-00MESG, RC-0003
Bluetooth Connected	No
Wi-Fi Connected	No
Remote Included	No
Remote Optional	Yes
Energy Star Certified	No
Alexa & Google Home Compatible	No
CEC Title 20 Compliant	Yes
Primary Material	Steel
Wattage	783
Certification	UL
Nominal Width; IN	36
Net Width; IN	35.3125
Net Depth; IN	19.6875
Net Height; IN	13.8125
Weight; LBS	70
Ceiling Height Minimum	8 ft.
Ceiling Height Maximum	10.5 ft.
Shipping Length; IN	38.2
Shipping Width; IN	23.3
Shipping Height; IN	26.7
Shipping Weight; LBS	72.7
Shipping Method	LTL
Freight Class	300
Certification #	E503546
Clean Filter Alert	Yes
Duct Type	Vertical
