Name: ZEPHYR AK9546AS 48" Monsoon Mini II Insert
Brand: ZEPHYR
SKU: AK9546AS-KT
Price: 999.0 USD
Availability: OutOfStock

ZEPHYR AK9546AS 48" Monsoon Mini II Insert

Key Specs

Type: Hood inserts
Width: 46.37 Inch
Depth: 18.06 Inch
Height: 6.12 Inch

More details

Translation missing: en.products.product.product_variants

$999.00 $1,298.00 Save $299.00

Check Delivery Options

Out of stock

Quantity:

Product Information
Specifications
Manuals & Guides
Features
Reviews

General
Model: AK9546AS
Brand: ZEPHYR
Type: Range Hoods
Color: STAINLESS STEEL
Height: 6.12
Width: 46.37
Length: 18.06
Cooking Capabilities
Number of Burners: 0
Number of Elements: 0
Convection: No
Self-Cleaning: No
Cooking Capabilities
Warming Drawer: No
Hidden element: No
Proof cook mode: No
Continuous grate: No
Down draft: No
Storage Drawer: No
Induction: No
Features
Sabbath mode: No
Recessed turntable: No
Number of Shelves: 0
Convection: No
Advanced Features
Wi-Fi Connectivity: No
Smart Features: No
Power & Consumption
Microwave wattage: 0
CFM: 0

A quiet storm of air-clearing power in a designer package, the Monsoon Mini II gets the job done. Featuring a 600-CFM blower, hybrid baffle filters, Airflow Control Technology (ACT(TM)), and dual-level LumiLight LED lighting. Also includes recirculating and make-up air options.

Brand	Zephyr
Manufacturer	Zephyr
Category	Range Hood
Sub-Category	Insert
Vent Type	Convertible
UPC	646328009938
GTIN	00646328009938
Country of Origin	Taiwan
Model Group	AK95-A
Model Name	Monsoon Mini II
Collection	Core Collection
Blower Included	Yes
Blower CFM w/ACT	390, 290
Internal Blower 1 CFM	600
Internal Blower 1 Min. Sones	1.4
Internal Blower 1 Max Sones	6
Minimum CFM	200
Installation Type	Insert
For Outdoor Use	No
Color	Stainless Steel
Controls Type	Electronic
Blower Speeds	3
Automatic Delay-Off	Yes
Clean Air Function	No
Lighting Type	LED
Lights Quantity	2
Watts Per Bulb	6
Lights Levels	2
Grease Filter Type	Hybrid Baffle
Compatible Mesh or Baffle Filter Part Number	50210041
Duct Discharge	Vertical or Horizontal
Duct Size; Horizontal; IN	3.25 x 10
Duct Size; Vertical; IN	7, 3.25 x 10
Mounting Height Above Cooktop; IN	24 - 34
Voltage	120
Maximum Amperage	2
ADA Compliant	No
Warranty Parts / Labor	3 / 1
Compatible Appliances	ZRC-9100A, Z0F-C091, AK00067, MUA006A
Bluetooth Connected	No
Wi-Fi Connected	No
Remote Included	No
Remote Optional	No
Energy Star Certified	No
Alexa & Google Home Compatible	No
CEC Title 20 Compliant	Yes
Primary Material	Stainless Steel
Wattage	240
Certification	UL
Nominal Width; IN	48
Net Width; IN	46.375
Net Depth; IN	18.0625
Net Height; IN	6.125
Weight; LBS	39.5
Ceiling Height Minimum	8 ft.
Ceiling Height Maximum	12 ft.
Shipping Length; IN	9
Shipping Width; IN	51
Shipping Height; IN	22.5
Shipping Weight; LBS	44
Shipping Method	LTL
Freight Class	125
Certification #	E127334
Clean Filter Alert	Yes
Cutout Depth in.	18.5
Cutout Width in.	46.5
Duct Type	Vertical
Duct Type	Vertical
