SKU: UVL6048JSS | UPC: 883049569512

Whirlpool UVL6048JSS 48" 585 or 1170 CFM Motor Class Custom Hood Liner Stainless Steel

48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner
48" 585 or 1170 CFM Motor Class Custom Hood Liner

Quick Specification More details

  • Width:
    36"
  • Depth:
    22"
  • Height:
    11.5"
  • Type:
    Hood Inserts

About this product

  • Three-Speed Fan
  • Requires 585 or 1170 CFM Motor Class Blower
  • 105,000 BTU Rating
  • Four LED Lights with Night Light Setting
More on the way
On Sale

SKU: UVL6048JSS | UPC: 883049569512

Whirlpool UVL6048JSS 48" 585 or 1170 CFM Motor Class Custom Hood Liner Stainless Steel

$1,408.21 $2,210.97 Save $802.76 / 36% OFF

More on the way

Active Rebates

Extended Protection

?

Extend your appliance's warranty beyond the manufacturer's terms with our Extended Protection Plan.

Enjoy added peace of mind long after the original warranty expires.

This Protection Plan includes:

  • Full parts and labor coverage during the whole period of the extension plan.
  • Protection for the case of a power surge during both the period of the extension plan and manufacturer’s warranty
  • Food loss protection
  • 24/7 toll-free number for support

Click here for full details.

  • $43.49
  • $75.99
  • $115.99
  • $163.99

Delivery services

?

Delivery Services:
We offer a range of delivery services to meet your needs. Please note that these services are not available in certain locations.

For more details, please visit our Delivery and Installation Services page.

  • $180.00
  • $49.99
KT Appliance

We’ll confirm fit, specs & delivery before you order.

  •  Chat  • Email  • Call Us

Available services

Quick Specification More details

  • Width:
    36"
  • Depth:
    22"
  • Height:
    11.5"
  • Type:
    Hood Inserts

About this product

  • Three-Speed Fan
  • Requires 585 or 1170 CFM Motor Class Blower
  • 105,000 BTU Rating
  • Four LED Lights with Night Light Setting

Related Products

  • Product Details
  • Manuals & Guides
  • From The Manufacturer
  • Reviews
$1,408.21 $2,210.97 Save $802.76 / 36% OFF

Product Details for Whirlpool UVL6048JSS

Technical Details

Ventilation details
Auto Function No
BTU Threshold 65K/105K
Duct Direction Vertical
Duct Length 13
Duct Type Round
Exhaust Vent Location Top
Filters Grease Filters
HVI (CFM HS Horizontal) N/A
HVI (CFM HS Vertical) 510
Night Light No
Task Light Type LED
Vent Fan Location Side
Venting Exterior
Damper Included Yes
Duct Outlet Size 10 in
Lighting Control Type Slider
Number of Night Light Settings 1
Task Lighting Yes

Controls
Control Location Hidden
Control Type Slide Controls

Details
Hood Type Under Cabinet
Blower Type Centrifugal

Electrical
Power Cord Included No
Hz 60
Volts 120
Watts 446
Amps 3.72

Certifications
Star K Certified No
Energy Star Qualified No
Energy Star® Qualified No

Dimensions & weight
Length 22 in.
Weight 52.91 lbs.
Maximum Height 36 in
Minimum Height 30 in
Width 36 in.
Height 11.5 in.
Canopy Height 11.5 in
Gross Weight 52.91 lbs
Net Weight 33.51 lbs

Number of boxes, shipping dimensions, & shipping weight
Number of Boxes 1
Shipping Width 53 in.
Shipping Height 16 in.
Shipping Length 27 in.
Shipping Weight 92.91 lbs.
Total of Shipping Weight 92.91 lbs.
Source Calculation

Other
Common Size 48 in

Capacity
Volume 13.741 Cu.Ft.

Cubic feet measurement & dimensional weight
Cubic Feet Measurement 5.27 ft³
Dimensional Weight 65.53 lbs.
Total of Cubes 5.27 ft³
Total of Dimensional Weight 65.53 lbs.

Description

This 48-inch custom hood liner allows you to conceal ventilation within cabinetry or a decorative hood cover, creating a style all your own. Choose from two compatible blower motor options (sold separately) for complete customization of your ventilation system. A 65,000 BTU rating allows this hood liner to pair with 48-inch rangesor cooktops of comparable output.


Product Features

  • Three-Speed Fan
    Features low, medium and high settings, so you can choose the right fan speed for every cooking adventure, from gentle simmering to high-heat searing.
  • Requires 585 or 1170 CFM Motor Class Blower
    Allowing you to customize a powerful ventilation system with your choice of commercial-style blowers.
  • 105,000 BTU Rating
    pairs with KitchenAid® Commercial-Style Ranges, Rangetops and other models with total burner outputs up to 105,000 BTU.
  • Four LED Lights with Night Light Setting
    Provide two levels of brightness, allowing you to illuminate the entire cooking surface below with natural-looking light or subtly accent the kitchen with a soft, inviting glow.
  • Removable Filters
    Use multiple layers of screening to help capture the grease, steam and odors of high-heat cooking. Filters are removable for easy cleaning with soap and water.
  • KitchenAid® Custom Hood Liners
    KitchenAid® Custom Hood Liners allow you to conceal ventilation within custom cabinetry or a decorative hood cover, creating a style all your own.
