| Lighting | 2 Level 7W LED Strip |
| Noise Level (Max) | 65 dB |
| Power | 120V |
| Frequency | 60Hz |
| Amperage | 3A |
| Filter Type | Aluminum Mesh |
| Blower Type | Internal |
| Control Type | 3 Speed Touch Control |
| Color/Finish | Stainless Steel |
| Accessories (not included) | Charcoal Filter (FT0130) Recirculating Kit (ARC3001P) 10-12ft Duct Extension (RHDC01AP) |
| Width | 30 in. |
| Net Weight | 26 lbs. |
| Gross weight | 36.2 lbs. |
| Ducted Hood Height (Inch) | 26 9/16″ – 41 15/16″ |
| Number of Boxes | 1 |
| Shipping Width | 35 in. |
| Source | Calculation |
| Blower Ratings | (dBA) |
| Low | 47 |
| Medium | 55 |
| High | 65 |
| Product Width (in) | 30″ |
| Product Depth (in) | 19 3/4" |
| Product Height (in) | 10 13/16″ |
| Ducted Hood Height (Inch) | 26 9/16″ - 41 15/16″ |
| Height of Range Hood / Extended Duct (in) | 44 7/16 / 77 3/4 (Ext. RHDC01AP Not Included) |
| Duct Diameter (in) | 6" |
| Duct Shape | Round |
