SKU: SP6DBS2D7ADA | UPC: 761101069517

Summit SP6DBS2D7ADA 24" Wide 2-Drawer All-Refrigerator, ADA Compliant Stainless Steel

Quick Specification More details

Width:
23.63"
Depth:
23.88"
Height:
32.25"
Type:
Compact Refrigerators

About this product

Commercially approved
ADA Compliant
Built-in capable
Fully finished cabinet

Summer Sale

Clearance

SKU: SP6DBS2D7ADA | UPC: 761101069517

Summit SP6DBS2D7ADA 24" Wide 2-Drawer All-Refrigerator, ADA Compliant Stainless Steel

$3,271.47 ~~$3,664.97~~ Save $393.50 / 10% OFF

Out of stock

Active Rebates

We’ll confirm fit, specs & delivery before you order.

• Chat • Email • Call Us

Quick Specification More details

Width:
23.63"
Depth:
23.88"
Height:
32.25"
Type:
Compact Refrigerators

About this product

Commercially approved
ADA Compliant
Built-in capable
Fully finished cabinet

Product Details
Manuals & Guides
From The Manufacturer
Reviews

$3,271.47 ~~$3,664.97~~ Save $393.50 / 10% OFF

Product Details for SUMMIT SP6DBS2D7ADA

Technical Details

Warranty

Parts	1 Year
Labor	1 Year

Dimensions & weight

Width	23.63 in.
Height	32.25 in.
Length	23.88 in.
Weight	120 lbs.

Cubic feet measurement & dimensional weight

Cubic Feet Measurement	10.53 ft³
Dimensional Weight	130.92 lbs.
Total of Cubes	10.53 ft³
Total of Dimensional Weight	130.92 lbs.

Overview refrigerator features drawer dimensions dimensions

Nominal Height	32.0" (81 cm)
Height of Cabinet	32.25" (82 cm)
Nominal Width	24.0" (61 cm)
Width	23.63" (60 cm)
Nominal Depth	24.0" (61 cm)
Depth	23.88" (61 cm)
Depth with Handle	25.38" (64 cm)
Depth with door at 90°	41.25" (105 cm)
Capacity	3.1 cu.ft. (88 L)
Defrost Type	Automatic
Door	Stainless Steel
Cabinet	Stainless Steel
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Sanitation	ETL-S
Amps	1.2
Weight	120.0 lbs. (54 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
UPC	761101069517
Thermostat Type	Dial
Fan Type	Interior and Exterior
Refrigerant Type	R600a
Refrigerant Amount	0.64oz.
High Side PSI	180.0
Low Side PSI	80.0
Level Legs Qty	4
Interior Height 1	9.5" (24 cm)
Interior Width 1	18.75" (48 cm)
Interior Depth 1	12.0" (30 cm)
Interior Height 2	12.63" (32 cm)
Interior Width 2	17.25" (44 cm)
Interior Depth 2	16.0" (41 cm)
Compressor Step Height	5.75" (15 cm)
Compressor Step Width	18.75" (48 cm)
Compressor Step Depth	4.0" (10 cm)

Description

SUMMIT COMMERCIAL offers a quality line of commercially approved drawer refrigerators assembled in the U.S.A. and fully constructed from stainless steel. The SP6DBS2D7ADA is a 24" wide two-drawer all-refrigerator that can be used built-in or freestanding. At 32" high, this unit is designed for use under lower ADA compliant counters. Two sliding drawers feature sleek stainless steel handles and magnetic gaskets to ensure a tight seal when closed. This unit includes an adjustable divider that lets you better organize your storage. The cabinet and drawers are constructed from durable stainless steel to ensure long-lasting luxury with a professional look. We offer an optional conversion kit that allows the drawers to be customized with overlay panels (see Panel Kit). Automatic defrost ensures minimum user maintenance, with a dial thermostat for easy temperature management. This model is ETL-S listed to NSF-7 standards for commercial use. For this unit in standard counter height, see the SP6DBS2D7.

Product Features

Commercially approved
ETL-S listed to NSF-7 Standards for use in commercial establishments
ADA Compliant
32 inch height is designed to fit under ADA compliant counters
Built-in capable
Make the best use of space by installing your appliance under the counter and flush with other cabinetry
Fully finished cabinet
Allows the unit to be used freestanding
Slim undercounter dimensions
Less than 24 inches wide to fit tight spaces
Adjustable thermostat
Dial thermostat for easy temperature management
Rapid chill compartment
Special rear section is perfect for chilling wine and beer from room to drinking temperature in under an hour
Automatic defrost
Reduced maintenance with auto defrost system
Adjustable drawer divider
Wire divider lets you separate items into four sections for easier organization
Complete stainless steel construction
Built with solid durability, inside and out
Large top drawer
Holds two liter bottles, gallon containers, and wine bottles in 12 1/2" height
Customizable drawer fronts
Order our conversion kit to install your own panels over the drawers
100% CFC free
Environmentally friendly design does not contain ozone-damaging chemicals
CARB Compliant
Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
