Sale price $2,925.00 Regular price $4,054.50 Save $1,129.50 / 27% OFF

Product Details for Summit FFRF36ADA

Technical Details

Overview

Nominal Height 12.6
Height of Cabinet 12.4
Nominal Width 14.17
Width 13.98
Width with Door Open 14.47
Nominal Depth 9.84
Depth 9.55
Depth with Handle 9.89
Depth with door at 90(degree) 15.75
Capacity 5.8
Defrost Type Frost-Free
Door Stainless Steel
Cabinet Black
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Sanitation ETL-S
Energy Usage/Year 504.0
Amps 1.3
Voltage/Frequency 115
Weight 160.0
Parts & Labor Warranty 1
Compressor Warranty 5
UPC 761101063324

Refrigerator-freezer

Door Swing French
Adjustable Shelves Yes
Interior Light Yes
Refrigerator - Interior Height 9.25
Refrigerator - Interior Width 5.02
Refrigerator - Interior Depth 6.59
Refrigerator - Capacity 2.9
Refrigerator - Shelf Type Glass
Refrigerator - Shelf Qty 3
Refrigerator - Temperature Range 36
Refrigerator - Refrigerant Type R600a
Refrigerator - Refrigerant Amount 1.59
Freezer - Interior Height 9.25
Freezer - Interior Width 5.02
Freezer - Interior Depth 6.59
Freezer - Capacity 2.9
Freezer - Shelf Type Chrome
Freezer - Shelf Qty 3
Thermostat Type Digital
Fan Type Interior and Exterior
Refrigerant Type R600a
Refrigerant Amount 1.59
High Side PSI 150.0
Low Side PSI 50.0
Level Legs 2
Freezer - Temperature Range -22
Compressor Step Height 1.87
Compressor Step Width 5.02
Compressor Step Depth 1.67

Features

  • ETL-S listed to NSF-7 standard and meets UL-471 for use in commercial settings
  • 31 1/2 height for use under lower ADA compliant counters
  • Front-breathing system allows the unit to be used built-in
  • Separate refrigerator and freezer sections with single compressor operation
  • No-frost operation ensures reduced maintenance in both the refrigerator and freezer compartments
  • Keyed locks for each section offer added security
  • Stainless steel handles offer an attractive finish for the appliance
  • Digital control panel allows for easy temperature control, with a clear readout in Fahrenheit or Celsius
  • Interior LED lighting in the primary refrigerator section offers an attractive and energy efficient presentation
  • Refrigerator section includes three spill-proof glass shelves for easier cleaning, while the freezer includes three adjustable chrome shelves to ensure proper cold air circulation
  • Freezer compartment temperature can be set to serve as a second refrigerator as needed
  • Fan-forced cooling ensures the unit is evenly cooled from top to bottom
  • Space-saving design with no exposed coils in the rear offers easy cleanability
  • In the event of power loss, the unit will retain its last temperature settings upon power recovery
  • Allows the unit to be used freestanding
  • Two leveling legs ensure the unit is even when placed on uneven surfaces
  • Environmentally friendly design without ozone-damaging chemicals
  • Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations



Description

SUMMIT brings quality and value under the counter with the industry s largest collection of ADA compliant built-in refrigeration. The FFRF36ADA features a versatile design that meets NSF-7 and UL-471 commercial standards but is also approved for residential use. Sized at 36" wide, this all-in-one, side-by-side refrigerator-freezer is designed for built-in or freestanding installation. This unit features a jet black cabinet and stainless steel doors complete with pro style handles. Both sections include factory-installed keyed locks for added security. Digital controls are located in the kickplate, allowing you to adjust the temperature without opening the door. This unit has a sealed back design to enable easier cleanup and added space savings. Inside, the FFRF36ADA features a 2.9 cu.ft. frost-free freezer compartment on the left and a 2.9 cu.ft. frost-free refrigerator compartment on the right. Both sections are frost-free for easy maintenance, with internal fans to help provide even cooling. The refrigerator compartment includes three adjustable glass shelves with five placement options that offer multiple spill-proof storage options. The freezer compartment includes three adjustable chrome shelves, with five placement options for optimal storage options and proper cold air circulation. The freezer compartment includes three adjustable chrome shelves for proper cold air circulation. Additionally, the freezer section can be converted to run as a refrigerator, allowing you to adjust the temperature range to best accommodate your storage needs at the touch of a button. The FFRF36ADA is sized at 31 1/2 inches high to fit under lower ADA compliant counters. For this unit with panel ready doors, see the FFRF36IFADA. NOTE: Due to its larger commercial design, the FFRF36ADA requires an additional 5/8" of width for each door to open to a full 90 . If placing this unit against a right angle wall, be sure to accommodate this extra space.
