Summit CT66LWBIIFADA 24" Wide Built-In Refrigerator-Freezer, ADA Compliant (Panel Not Included) Panel-Ready

Quick Specification More details

Width:
23.63"
Depth:
23.5"
Height:
32"
Type:
Compact Refrigerators

About this product

Slim undercounter dimensions
Factory installed lock
Built-in capable
Fully finished white cabinet

Summer Sale

Clearance

SKU: CT66LWBIIFADA | UPC: 761101068855

Summit CT66LWBIIFADA 24" Wide Built-In Refrigerator-Freezer, ADA Compliant (Panel Not Included) Panel-Ready

$1,628.23 ~~$2,558.97~~ Save $930.74 / 36% OFF

Out of stock

Active Rebates

We’ll confirm fit, specs & delivery before you order.

• Chat • Email • Call Us

Quick Specification More details

Width:
23.63"
Depth:
23.5"
Height:
32"
Type:
Compact Refrigerators

About this product

Slim undercounter dimensions
Factory installed lock
Built-in capable
Fully finished white cabinet

Product Details
From The Manufacturer
Reviews

$1,628.23 ~~$2,558.97~~ Save $930.74 / 36% OFF

Product Details for Summit CT66LWBIIFADA

Technical Details

Dimensions & weight

Width	23.63 in.
Height	32 in.
Length	23.5 in.
Weight	100 lbs.

Cubic feet measurement & dimensional weight

Cubic Feet Measurement	10.28 ft³
Dimensional Weight	127.84 lbs.
Total of Cubes	10.28 ft³
Total of Dimensional Weight	127.84 lbs.

Overview refrigerator-freezer

Nominal Height	32.0" (81 cm)
Height of Cabinet	32.0" (81 cm)
Height to Hinge Cap	32.38" (82 cm)
Nominal Width	24.0" (61 cm)
Width	23.63" (60 cm)
Nominal Depth	24.0" (61 cm)
Depth	23.5" (60 cm)
Depth with door at 90°	45.13" (115 cm)
Capacity	5.1 cu.ft. (144 L)
Defrost Type	Cycle
Door	Panel-Ready
Cabinet	White
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Amps	1.4
Voltage/Frequency	115 V AC/60 Hz
Weight	100.0 lbs. (45 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
UPC	761101068855
Door Swing	RHD
Reversible	Factory Reversible
Adjustable Shelves	Yes
Crisper Qty	1
Crisper Finish	Transparent
Crisper Cover	Glass
Interior Light	Yes
Refrigerator - Interior Height	19.5" (50 cm)
Refrigerator - Interior Width	20.5" (52 cm)
Refrigerator - Interior Depth	17.0" (43 cm)
Refrigerator - Shelf Type	Wire
Refrigerator - Shelf Qty	2
Refrigerator - Full Door Shelves	3
Freezer - Interior Height	5.0" (13 cm)
Freezer - Interior Width	19.0" (48 cm)
Freezer - Interior Depth	11.5" (29 cm)
Thermostat Type	Dial
Fan Type	Exterior
Refrigerant Type	R600a
Refrigerant Amount	0.92 oz.
High Side PSI	180.0
Low Side PSI	80.0
Level Legs	4
Compressor Step Height	7.0" (18 cm)
Compressor Step Width	20.5" (52 cm)
Compressor Step Depth	5.0" (13 cm)

Description

Accucold by Summit Appliance offers a wide range of undercounter refrigeration for general purpose storage. The CT66JBIADA Series includes refrigerator-freezers designed for optimum storage conditions in built-in applications under lower ADA compliant counters. At 32" high, the CT66LWBIIFADA can be used built-in or freestanding in ADA compliant settings. The 24" footprint fits many popular cutouts while offering over 5 cu.ft. of storage capacity. This model has a white cabinet. The factory reversible door includes a lock and an integrated stainless steel frame designed to accept full overlay panels for a custom look. Users provide their own handle. Inside, our unique dual evaporator system separately cools the refrigerator and freezer sections to ensure proper storage temperature. Cycle defrost operation reduces user maintenance in the automatic defrost fresh food section, with static manual defrost operation in the freezer compartment. Door storage provides easy access for tall bottles and small condiments. Additional features include adjustable shelves, a clear crisper, and automatic interior lighting. The CT66LWBIIFADA has long proven itself to have one of the best temperature performance records in the industry. To see additional finish options on this unit, browse the full CT66WBIADA Series. NOTE: This unit is designed for general purpose applications and does not meet DOE energy standards for residential use.

Product Features

Slim undercounter dimensions
Less than 24" wide with a generous storage capacity
Factory installed lock
Keyed security on the refrigerator door
Built-in capable
Front-breathing design lets you make the best use of space by installing your appliance under the counter
Fully finished white cabinet
Allows the unit to be used freestanding
Cycle defrost
This system utilizes user-friendly automatic defrost operation in the fresh food section and efficient manual defrost operation in the freezer compartment
Adjustable thermostat
Dial thermostat located inside for easy temperature management
Door storage
Store tall bottles and condiments right on the door for convenient access
Dual evaporator
Our unique and efficient design separately cools the refrigerator while maintaining a lower temperature in the freezer compartment by utilizing two evaporators
Integrated door frame
Stainless steel door frame accepts full overlay panels to match adjacent cabinetry (panel size: 23 5/16" W x 28 1/4" H and at least 3/4" thick; maximum weight: 10 lbs.)
Adjustable shelves
Rearrange refrigerator space to accommodate all sizes or remove shelves for simple cleanup
Interior light
Automatically illuminates when you open the door
Clear crisper drawer
Get the longest life and best taste out of produce by storing greens in a bottom crisper
100% CFC Free
Environmentally friendly design with no ozone-damaging chemicals
ADA compliant
32" high to fit under lower ADA compliant counters
CARB Compliant
Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
