Sale price $1,590.00 Regular price $2,373.16 Save $783.16 / 33% OFF

Product Details for Summit CT66LWBIIF

Technical Details

Overview

Nominal Height 13.39
Height of Cabinet 13.19
Nominal Width 9.45
Width 9.3
Nominal Depth 9.45
Depth 9.25
Depth with door at 90(degree) 17.77
Capacity 5.1
Defrost Type Cycle
Door Panel-Ready
Cabinet White
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Amps 1.4
Voltage/Frequency 115
Weight 100.0
Parts & Labor Warranty 1
Compressor Warranty 5
UPC 761101068848

Refrigerator-freezer

Door Swing RHD
Reversible Factory Reversible
Adjustable Shelves Yes
Crisper Qty 1
Crisper Finish Transparent
Crisper Cover Glass
Interior Light Yes
Refrigerator - Interior Height 7.68
Refrigerator - Interior Width 8.07
Refrigerator - Interior Depth 6.69
Refrigerator - Shelf Type Wire
Refrigerator - Shelf Qty 2
Refrigerator - Full Door Shelves 3
Freezer - Interior Height 1.97
Freezer - Interior Width 7.48
Freezer - Interior Depth 4.53
Thermostat Type Dial
Fan Type Exterior
Refrigerant Type R600a
Refrigerant Amount 0.92
High Side PSI 180.0
Low Side PSI 80.0
Level Legs 4
Compressor Step Height 2.76
Compressor Step Width 8.07
Compressor Step Depth 1.97

Features

  • Less than 24 inches wide to fit tight spaces
  • Keyed lock offers added security
  • Front-breathing design lets you make the best use of space by installing your appliance under the counter
  • Allows the unit to be used freestanding
  • Adjustable legs allow the unit to be sized from 33 1/2" to 34 3/4" high
  • Customize the front by mounting an overlay panel over the door; seamless look can blend into other cabinetry with no exposed frame. Handle not included (panel size: 23 5/16" W x 28 1/4" H and at least 3/4" thick; maximum weight: 10 lbs.)
  • This system utilizes user-friendly automatic defrost operation in the fresh food section and efficient manual defrost operation in the freezer compartment
  • Our unique and efficient design separately cools the refrigerator while maintaining a lower temperature in the freezer compartment by utilizing two evaporators
  • Rearrange the refrigerator space to fit any sized item or remove shelves for simple cleanup
  • Get the longest life and best taste out of produce by storing greens in lower slide drawer
  • Keep tall bottles and condiments right on the door for convenient access
  • Automatically illuminates when the door is opened
  • Dial thermostat located inside for easy temperature management
  • Environmentally friendly design does not contain ozone-damaging chemicals
  • Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations



Description

Accucold by Summit Appliance offers a wide range of undercounter refrigeration for general purpose storage. The CT66JBI Series includes built-in undercounter refrigerator-freezers equipped with dual evaporator cooling for optimum storage conditions. Sized with a 24" footprint, the CT66LWBIIF can be used built-in under counters or freestanding. The interior offers over 5 cu.ft. of storage capacity. This model has a white cabinet. The factory reversible door includes a factory installed lock and an integrated frame designed to accept full overlay panels for a custom look. Users provide their own handle. Inside, our unique dual evaporator system separately cools the refrigerator and freezer section to ensure proper storage temperature. Cycle defrost operation reduces user maintenance in the automatic defrost fresh food section, with static manual defrost operation in the freezer compartment. Door storage provides easy access for tall bottles and small condiments. Additional features include adjustable shelves, a clear crisper, and automatic interior lighting. The CT66LWBIIF has long proven itself to have one of the best temperature performance records in the industry. To see additional finish options on this unit, browse the full CT66WBI Series. NOTE: This unit is designed for general purpose applications and does not meet DOE energy standards for residential use.
