Product Details for Summit CT663BK

Technical Details

Overview

Nominal Height 12.99
Height of Cabinet 12.75
Height to Hinge Cap 12.85
Nominal Width 9.45
Width 9.3
Nominal Depth 9.06
Depth 9.06
Depth with Handle 9.7
Depth with door at 90(degree) 17.87
Capacity 5.04
Defrost Type Cycle
Door Black
Cabinet Black
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Energy Usage/Year 330.0
Amps 1.2
Voltage/Frequency 115
Weight 100.0
Parts & Labor Warranty 1
Compressor Warranty 5
UPC 761101067506

Refrigerator-freezer

Door Swing RHD
Reversible Yes
Adjustable Shelves Yes
Crisper Qty 1
Crisper Finish Transparent
Crisper Cover Glass
Wine Bottle Shelving Yes
Interior Light Yes
Refrigerator - Interior Height 7.09
Refrigerator - Interior Width 8.27
Refrigerator - Interior Depth 7.09
Refrigerator - Capacity 4.5
Refrigerator - Shelf Type Glass
Refrigerator - Shelf Qty 2
Refrigerator - Full Door Shelves 3
Refrigerator - Temperature Range 36
Freezer - Interior Height 2.07
Freezer - Interior Width 7.48
Freezer - Interior Depth 4.53
Freezer - Capacity 0.6
Thermostat Type Dial
Refrigerant Type R600a
Refrigerant Amount 0.92
High Side PSI 180.0
Low Side PSI 80.0
Level Legs 2
Compressor Step Height 2.17
Compressor Step Width 8.27
Compressor Step Depth 2.36
Sound Level 32.6

Features

  • Includes a full refrigerator and freezer section for undercounter use
  • Rated by the DOE to perform with more efficiency than federal standards require, saving your unit energy and you on higher utility costs
  • Ideal 24" footprint offers full 5.1 cu.ft. storage capacity in a slim fit
  • Our unique and efficient design separately cools the refrigerator while maintaining a lower temperature in the freezer compartment by utilizing two evaporators
  • This system utilizes user-friendly automatic defrost operation in the fresh food section and efficient manual defrost operation in the freezer compartment
  • Rearrange your refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up
  • Store tall bottles and condiments right on the door for convenient access
  • Get the longest life and best taste out of produce by storing it in a convenient slide drawer
  • Removable scalloped wine shelf is included to store champagne and wine bottles
  • Cold wall design with hidden evaporator creates a seamless, easy to clean interior
  • Automatically illuminates when you open the door
  • Dial thermostat located inside for easy temperature management
  • Stainless steel handle adds an attractive touch
  • User-reversible door swing for added flexibility
  • Environmentally friendly design without ozone-damaging chemicals
  • Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations



Description

Summit's Peak24 series of undercounter European-made refrigeration features energy efficient refrigerator-freezer choices that offer the largest capacity in the industry for recessed installation in 24" openings. Sized with a 24 footprint, the ENERGY STAR certified CT663BK refrigerator-freezer offers a generous 5.1 cu.ft. storage capacity, a larger interior than many units in this size class. This model features a black exterior finish with a user-reversible door swing. A stainless steel handle completes the look. Inside, the CT663BK features a dual evaporator to allow separated cooling of the fresh and frozen food sections. The refrigerated compartment utilizes low maintenance automatic defrost, while the interior freezer compartment is manual defrost to achieve lower storage temperatures ideal for ice cream and other frozen food. The deluxe interior includes adjustable glass shelves for spill-proof storage and easier cleaning, as well as a scalloped wine shelf to hold wine and champagne bottles safely in place. Door racks offer additional convenience for tall bottles and condiments and a clear crisper drawer ensures your produce is stored under the ideal conditions. This model includes automatic interior lighting and an adjustable dial thermostat. This model is UL listed for residential use. With its large capacity and user-friendly features, this refrigerator-freezer is a convenient option for homes, offices, schools, and other settings in need of reliable cold storage. Additional choices are available in lower ADA height. Browse the full Summit catalog to discover the perfect appliance for your refrigeration needs.
