SKU: BIM26LHD | UPC: 761101108452

Summit BIM26LHD 15 lb. Drain-Free Built-In Icemaker Stainless Steel

15 lb. Drain-Free Built-In Icemaker
15 lb. Drain-Free Built-In Icemaker
15 lb. Drain-Free Built-In Icemaker
15 lb. Drain-Free Built-In Icemaker
15 lb. Drain-Free Built-In Icemaker
15 lb. Drain-Free Built-In Icemaker
15 lb. Drain-Free Built-In Icemaker
15 lb. Drain-Free Built-In Icemaker

Quick Specification More details

  • Width:
    14.88"
  • Depth:
    16.75"
  • Height:
    24.5"
  • Type:
    Ice Makers

About this product

  • No-Drain 15" Wide Icemaker
  • Large capacity
  • Drain-free design
  • Sealed back
Summer Sale
Clearance

SKU: BIM26LHD | UPC: 761101108452

Summit BIM26LHD 15 lb. Drain-Free Built-In Icemaker Stainless Steel

$842.78 $1,154.97 Save $312.19 / 27% OFF

Out of stock

Active Rebates

KT Appliance

We’ll confirm fit, specs & delivery before you order.

  •  Chat  • Email  • Call Us

Quick Specification More details

  • Width:
    14.88"
  • Depth:
    16.75"
  • Height:
    24.5"
  • Type:
    Ice Makers

About this product

  • No-Drain 15" Wide Icemaker
  • Large capacity
  • Drain-free design
  • Sealed back
  • Product Details
  • Manuals & Guides
  • From The Manufacturer
  • Reviews
$842.78 $1,154.97 Save $312.19 / 27% OFF

Product Details for Summit BIM26LHD

Technical Details

Warranty
Parts 1 Year
Labor 1 Year

Dimensions & weight
Width 14.88 in.
Height 24.5 in.
Length 16.75 in.
Weight 50 lbs.

Cubic feet measurement & dimensional weight
Cubic Feet Measurement 3.53 ft³
Dimensional Weight 43.93 lbs.
Total of Cubes 3.53 ft³
Total of Dimensional Weight 43.93 lbs.

Overview icemaker
Nominal Height 25.0" (64 cm)
Height of Cabinet 24.5" (62 cm)
Height to Hinge Cap 25.0" (64 cm)
Nominal Width 15.0" (38 cm)
Width 14.88" (38 cm)
Width with Door Open 15.13" (38 cm)
Nominal Depth 17.0" (43 cm)
Depth 16.75" (43 cm)
Depth with door at 90° 32.25" (82 cm)
Defrost Type Manual
Door Stainless Steel
Cabinet Black
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Amps 1.2
Voltage/Frequency 115 V AC/60 Hz
Weight 50.0 lbs. (23 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
UPC 761101108452
Door Swing LHD
Reversible Yes
Height Adjustable No
Daily Ice Production 15.0 lbs. (7 kg)
Ice Storage Capacity 12.0 lbs. (5 kg)
Ice Shape Crescent
Size of Cube 7/8" x 7/8" x 2-3/8"
Number of Ice Cube Sizes 1
Refrigerant Type R600a
Refrigerant Amount 1.69 oz.
High Side PSI 120.0
Low Side PSI 55.0
Interior Height 12.25" (31 cm)
Interior Width 11.0" (28 cm)
Interior Depth 12.25" (31 cm)
Level Legs 4

Description

Summit combines convenience and luxury to craft the BIM26 - a freestanding or built-in capable drain-free icemaker. Sized at just under 15" wide, the BIM26 features a front-breathing design for built-in installation but also has a fully finished cabinet to allow freestanding use. Its petite 25" height makes this the optimal unit for use in kitchen islands, home bars, break rooms, RVs, and even boat kitchens. The factory-reversible door features a stainless steel finish for a professional style built to last, paired with a sleek handle mounted horizontally to finish the look. There's a sealed back to allow more flush installation. This unit comes with a left-hand door swing. For a right-hand version, see the BIM26. A look inside the BIM26 shows it can produce 15 lbs of crescent-shaped ice daily. The static manual defrost cooling system allows ice to stay solid longer. No drain or pump is required, offering more placement flexibility. For optimal convenience, Summit has pre-installed the connection hose. Plus, this icemaker comes with a removable ice bucket, ice scoop, and a holder for the scoop. With its large capacity, the BIM26 produces 15 lbs of crescent-shaped ice and stores up to 12 lbs. With its stainless steel door, black cabinet, and low maintenance design, the BIM26 is a great way to finish any undercounter kitchen or home bar space and allows you to maintain an entire supply of ice with less waste. Alternative units are also available in different sizes, colors, and makes. Browse the full Summit product line to explore your options.


Product Features

  • No-Drain 15" Wide Icemaker
    Built-in or undercounter capable icemaker designed for kitchen islands, home bars, break rooms, health offices, RVs, and even boat kitchens.
  • Large capacity
    Produces 15 lbs of crescent-shaped ice and stores up to 12 lbs
  • Drain-free design
    Convenient design allows more flexibility in positioning the unit
  • Sealed back
    Space-saving design with easier cleanability
  • Ice scoop included
    Large ice scoop and holder included for your convenience
  • Lasting ice cube production
    Crescent-shaped ice provides a harder and longer-lasting ice
  • Removable bin
    Users can remove the ice bucket for fast and easy cleaning
  • Insulated storage bin
    Ice stays solid longer in this cold-protected bin
  • Left hand door swing
    For this unit with a standard right hand door swing, see model BIM26
  • 100% CFC free
    Environmentally friendly design without ozone-damaging chemicals
  • Lead-free certified
    Complies with California Health and Safety Code 116876 lead leaching requirements per NSF NSF/ANSI/CAN 61-2022 standard, as well as with lead content requirements for ‘lead free’ plumbing as defined by California, Vermont, Maryland, and Louisiana state laws and the U.S. Safe Drinking Water Act Section 1417(d) per NSF/ANSI/CAN 372-2022 standard
  • Built-In capable
    Make the best use of space by installing your icemaker under the counter
  • Manual defrost
    Static cooling system helps to keep ice frozen for longer periods of time compared to other systems
  • Reversible door
    User-reversible door swing for flexible placement
  • Standard water hookup
    Operates with a standard 1/4” OD water supply line
  • Modern handle
    Horizontally mounted towel bar style handle in stainless steel
