Sale price $3,500.00 Regular price $4,542.97 Save $1,042.97 / 22% OFF

Product Details for MONOGRAM ZVIS481SRSS

Technical Details

Warranty

Parts 2 Year
Labor 2 Year

Features

Fan Speed Control 3 Speed + Boost
WiFi Connect Built-In
Max CFM 1120
Required Duct Size 10-in. Round
Ducting Vertical and Recirculating
Light Controls On/Off/Night
Filter Cleaning Reminders Yes (through app)
Automatic Light/Fan Activation Yes (Chef Connect)
Time Delay Shut-Off Yes
Product Type Designer Hood
Exhaust Options Vented to Outside or Recirculating
Vertical Exhaust Blower Rating (CFM) 1220-CFM
Variable Speed Fan Yes
Lighting Levels 4
Removable Filter Yes
Control Location Hidden Controls
Recirculating Capable Yes
Blower Levels 4 Including Boost
CFM/ Sones Rating 1120/9.0
Blower Type Internal
Collection Statement,Minimalist
Connected Capabilities Amazon Alexa,Google Home
Control Type Electronic Touch,Rim Lit Metal Touch
Cooktop Lighting LED Bar,LED
Exhaust Options Vented to Outside,Recirculating

Appearance

Blower / Light Switch Color Backlit
Exterior Design Chimney - Island
Design Style Chimney
Color Appearance Stainless Steel
Design Style Chimney,Statement Collection,Minimalist Collection

Weights & dimensions

Cabinet Width 48 in
Overall Depth 26.6 in
Overall Height 11.1 in
Overall Width 48 in
Approximate Shipping Weight 150
Net Weight 140

Warranty

Warranty Notes See written warranty for full details
Labor Warranty Limited 1-year entire appliance
Parts Warranty Limited 1-year entire appliance

Dimensions & weight

Width 48 in.
Height 11.1 in.
Length 26.6 in.
Weight 140 lbs.

Number of boxes, shipping dimensions, & shipping weight

Number of Boxes 1
Shipping Width 53 in.
Shipping Height 16.1 in.
Shipping Length 31.6 in.
Shipping Weight 180 lbs.
Total of Shipping Weight 180 lbs.
Source Calculation

Cubic feet measurement & dimensional weight

Cubic Feet Measurement 8.2 ft³
Dimensional Weight 101.96 lbs.
Total of Cubes 8.2 ft³
Total of Dimensional Weight 101.96 lbs.

Power / ratings

Hertz 60

Economical / quiet

Venting Type Convertible

Accessories

Optional Accessories ZX12IC1SRSS - 12' High Ceiling Duct Cover Kit,ZX14IC1SRSS - 14' High Ceiling Duct Cover Kit,ZX8IC1SRSS - 8' High Ceiling Duct Cover Kit,JXHC1 - Power Cord Kit,ZXR1220RSS - In-Line Blower - Bl

Description

Advanced Air Quality Monitoring
Equipped with integrated sensors, this hood continuously monitors indoor air quality, including particulates, VOCs, temperature, and humidity 24/7 - without the need to turn the hood on.

Perimeter Venting
Experience a sleek and modern approach to kitchen ventilation with discreet perimeter venting. This design not only enhances airflow efficiency but also maintains a clean, streamlined look. (Wall-mount unit shown in picture)

Air Quality Indicator
Easily track air quality changes with an intuitive light system that provides a clear, real-time visuals, ensuring peace of mind for cooking and entertaining. (Wall-mount unit shown in picture)

Real-Time Notifications
Stay connected with real-time alerts via the SmartHQ app whenever a change in air quality is detected.

Blower Required for Operation - Sold Separately
Added installation flexibility with with 4 fan speeds 1220CFM blower options. Either remote or integral blower must be purchased for operation and are sold separately.

Stainless Steel Design
Crafted from high-quality stainless steel, this ventilation hood adds a luxurious and professional-grade aesthetic, perfectly complementing modern and designer kitchens. (Wall-mount unit shown in picture)

Built-in WiFi
Control the hood with ease using built-in WiFi. Adjust vent speed, lighting, and receive air quality updates directly through the SmartHQ app, offering unparalleled convenience and smart home integration.

LED Lighting
Bright, efficient LED lights illuminate the cooking area, providing a perfectly lit workspace that enhances the visual appeal of the kitchen. (Wall-mount unit shown in picture)

Chef Connect
Synchronize the hood with the cooktop. This feature automatically activates ventilation and lighting when cooking begins, ensuring seamless operation and a flawless culinary experience. (Wall-mount unit shown in picture)

ADA Compliant
Accessibility, allowing full control via mobile devices. This feature eliminates the need for reaching, ensuring that all homeowners can enjoy premium functionality.

Customizable Duct Cover Accessories
Personalize the hood with customizable duct cover accessories, available in various lengths (8-14 feet). This feature ensures a perfect fit for any kitchen layout, enhancing both functionality and design. (Wall-mount unit shown in picture)



Product Features

  • Advanced Air Quality Monitoring
    Equipped with integrated sensors, this hood continuously monitors indoor air quality, including particulates, VOCs, temperature, and humidity 24/7 — without the need to turn the hood on.
  • Real-Time Notifications
    Stay connected with real-time alerts via the SmartHQ app whenever a change in air quality is detected.
  • Required Remote Blower - Sold Separately
    Added installation flexibility with in-line remote blowers with 4 fan speeds 1220CFM options. Either remote or integral blower must be purchased for operation and are sold separately.
  • Built-in WiFi
    Control the hood with ease using built-in WiFi. Adjust vent speed, lighting, and receive air quality updates directly through the SmartHQ app, offering unparalleled convenience and smart home integration.
  • Optional Charcoal Filter
    Optional charcoal filters are available to efficiently absorb and neutralize cooking odors, making them ideal for homes that prioritize freshness.
  • Blower Required for Operation - Sold Separately
    Added installation flexibility with with 4 fan speeds 1220CFM blower options. Either remote or integral blower must be purchased for operation and are sold separately.

Key Features

Perimeter Venting

Experience a sleek and modern approach to kitchen ventilation with discreet perimeter venting. This design not only enhances airflow efficiency but also maintains a clean, streamlined look. (Wall-mount unit shown in picture)

Air Quality Indicator

Easily track air quality changes with an intuitive light system that provides a clear, real-time visuals, ensuring peace of mind for cooking and entertaining. (Wall-mount unit shown in picture)

Stainless Steel Design

Crafted from high-quality stainless steel, this ventilation hood adds a luxurious and professional-grade aesthetic, perfectly complementing modern and designer kitchens. (Wall-mount unit shown in picture)

LED Lighting

Bright, efficient LED lights illuminate the cooking area, providing a perfectly lit workspace that enhances the visual appeal of the kitchen. (Wall-mount unit shown in picture)

Chef Connect

Synchronize the hood with the cooktop. This feature automatically activates ventilation and lighting when cooking begins, ensuring seamless operation and a flawless culinary experience. (Wall-mount unit shown in picture)

Customizable Duct Cover Accessories

Personalize the hood with customizable duct cover accessories, available in various lengths (8-14 feet). This feature ensures a perfect fit for any kitchen layout, enhancing both functionality and design. (Wall-mount unit shown in picture)
