Sale price $2,500.00 Regular price $3,162.97 Save $662.97 / 20% OFF

Product Details for MONOGRAM ZDT900SIYII

Technical Details

Features

Wash System 900 Series
Sensor Clean Sensor
Tub Type Tall Tub
Leveling System Front Adjustable Leveling Legs
OU Certified No
Number of Place Settings 16
Custom Panel Ready Integrated Panels
Latch Pull with Handle
Number of Options 11
Style Built-In Top Control
Water Filtration System 100% Filtration with Hard Food Disposer and Removable Filter
Cutlery Tray Full 3rd rack (above upper rack) on full extension slides w/wash manifold
Floor Protection Floor Protect with Alert
Short Description Fully Integrated Dishwasher
Rack Color Silver
WiFi Connect Built-In
Racking System Adjustable 3rd rack
Interior Lighting LED
Exterior Style Custom Panel
Product Type Built-In
Number of Cycles 10
Tub and Door Liner Stainless Steel
Sabbath Mode Yes
Showroom Power Mode Yes
Connected Capabilities Amazon Alexa,The Google Assistant,IFTTT,Amazon Dash Replenishment,Sonos,Google Home
Connected Features Smart Assist II,Bottle Wash Jets,1/2 Load Wash Zones,Rinse,Cascade Platinum Plus/Shine,Child Lock,Dishwasher Cleaning
Control Type Top Controls,Cap Touch Controls
Dishwasher Control Features Hi-Resolution Color LCD Control Display,Last Cycle Memory,Audible End-of-Cycle Signal
Dishwasher Cycles Auto,1 Hour Wash & Dry,Intense,Crystal,Normal,Cycles Plus,Favorites,PrepRinse,Dishwasher Cleaning,CASCADE PLATINUM PLUS,HydroSave,Quiet
Dishwasher Drying Features Fan Dry On/Off plus Max Dry,2 Fans/Extra Heater
Dishwasher Options Delay Start 1-12 Hr.,Pre Soak,Wash TempBoost,Sani (Certified to NSF Standard 184),Heated Dry,Wash Zone Upper Only,Wash Zone Lower Only,Start/Reset,Bottle Wash,Silverware Wash
Dispenser Rinse Aid with Indicator and Adjustment,Electronic Low Rinse Aid Sensor
Lower Rack Ball-Tip Tines,Multi-Position Fold Down Tines,1 Rack handle
Rack Features Ball-Tipped Tines,2 Fold-Down Tines - Lower,Adjustable Upper Rack,3 Piece Silverware Basket
Upper Rack Premium Height Adjustable,Ball-Tipped Tines,2 Stem Safe Shelves,1/2 fixed tines, 1/2 fold down tines,1 Rack handle
Wash Arms 3 Pressurized Wash Arms,Lower - Reversing Blade,Middle - Blade,Bottle Wash Jets,Silverware Wash Jets,90+ Spray Jet Wash System,Jets - Variable Pressure
Wash System Features Variable Speed Dual Pumps and Motors,Automatic Temperature Control,Hard Food Disposer with removable filter,Dedicated Silverware Jets,Middle Wash Arm,Reversing Blade Lower Wash Arm,Deep Clean

Power / ratings

Power Connection Factory installed - w/offset flat plug, optional hardwire kit WD21X23559
Hertz 60
Electrical Requirements 120 V; 60 Hz; 10.2 A
Watts 1296
Calrod Heater Watts 1200

Weights & dimensions

Height w/ Legs Retracted - Minimum Height 33.375 in
Overall Depth 24 in
Cabinet Width 24 in
Overall Width 23.75 in
Overall Height 34 in
Height w/Legs Extended - Maximum Height 34.625 in
Depth with Door Open 25.5 in
Cutout Height (in) 33.5
Cutout Width (in) 24
Cutout Depth (in) 24
Approximate Shipping Weight 139
Net Weight 126

Warranty

Labor Warranty Limited 2-year entire appliance
Parts Warranty Limited 2-year entire appliance
Warranty Notes Limited 5-year rack and electronic control,Ltd Lifetime SS tub and inner door

Economical / quiet

Quiet Package 38 dBA
Motor Type Variable Speed
Quiet Features 38 dBA on regular cycle based on results from base model ZDT900SSYSS
Door Insulation Insulation,Mastic
Outer Wrap Full-wrap Blanket,Bitumen

Description

38 dBA Quiet Operation
Harmonizing power and serenity, engineered to deliver flawless cleaning at a quiet 38 dBA in Normal Cycle and 37 dBA in Quiet Cycle, making this the quietest dishwasher in the industry* *Based on the Quiet Wash Cycle achieving 37dba. Industry defined as residential dishwashers sold in North America, assessed January 1st 2026.

Flush Installation Capability
Dishwashers designed to fully integrate and be installed flush, even with inset cabinetry

HYDROSAVE(TM) Cycle
Reduces water usage by more than 25%*, perfect for those that are resource conscious, cleaning lightly soiled dishes *Compared to Normal Cycle 4-place setting soil load

Entertainer's Third Rack With Wash Zone
The full extension third rack allows for flexibility to accommodate larger items below and features an added wash manifold engineered to ensure utensils properly spaced and cleaned

Advanced Wash System
Achieve a pristine clean, using over 90 powerful wash jets to deliver a 360 clean, reaching all corners of the dishwasher

Max Dry System
This precise and efficient drying system delivers beautifully dry dishes every time, including hard to dry items like champagne flutes

Platinum Plus Cycle
A premium cycle that provides the highest level of cleaning when you choose to use Cascade Platinum Plus detergent. It helps you save up to 30 minutes of cycle time without sacrificing excellent performance

LED Illuminated Interior
LED lighting illuminates the entire interior to load and unload dishes with ease

Steam & Sanitization
Eliminate the need to pre-wash dishes at the end of every meal, thanks to Steam + Sanitize feature that easily loosens lingering traces of food with an added bonus of sanitization

Bottle & Silverware Jets
Powerful jets designed and specifically located to clean hard to reach taller items, like bottles, and silverware

Intuitive LCD Touch Controls
Easily select your cycle and customize wash and dry selections with the glass touch controls and brilliant LCD screen

Hard Food Disposer
Designed to maintain a kitchen's cleanliness and efficiency, the hard food disposer with stainless steel blades grinds food into tiny particles that wash away with ease

WiFi Connected With SmartHQ
Built-in WiFi and the SmartHQ app make it easy to control and monitor your dishwasher, wherever you are

Handles Sold Separately
Elevate your dishwasher's look by selecting a Statement or Minimalist Collection handle

Panel Ready Design
Designed to simplify panel alignment and installation, ensuring a flawless fit with your kitchen



Product Features

  • 38 dBA Quiet Operation
    Harmonizing power and serenity, engineered to deliver flawless cleaning at a quiet 38 dBA in Normal Cycle and 37 dBA in Quiet Cycle, making this the quietest dishwasher in the industry* *Based on the Quiet Wash Cycle achieving 37dba. Industry defined as residential dishwashers sold in North America, assessed January 1st 2026.
  • Flush Installation Capability
    Dishwashers designed to fully integrate and be installed flush, even with inset cabinetry
  • HYDROSAVE™ Cycle
    Reduces water usage by more than 25%*, perfect for those that are resource conscious, cleaning lightly soiled dishes *Compared to Normal Cycle 4-place setting soil load
  • Entertainer's Third Rack With Wash Zone
    The full extension third rack allows for flexibility to accommodate larger items below and features an added wash manifold engineered to ensure utensils properly spaced and cleaned
  • Advanced Wash System
    Achieve a pristine clean, using over 90 powerful wash jets to deliver a 360 clean, reaching all corners of the dishwasher
  • Max Dry System
    This precise and efficient drying system delivers beautifully dry dishes every time, including hard to dry items like champagne flutes
  • Platinum Plus Cycle
    A premium cycle that provides the highest level of cleaning when you choose to use Cascade Platinum Plus detergent. It helps you save up to 30 minutes of cycle time without sacrificing excellent performance
  • LED Illuminated Interior
    LED lighting illuminates the entire interior to load and unload dishes with ease
  • Steam & Sanitization
    Eliminate the need to pre-wash dishes at the end of every meal, thanks to Steam + Sanitize feature that easily loosens lingering traces of food with an added bonus of sanitization
  • Bottle & Silverware Jets
    Powerful jets designed and specifically located to clean hard to reach taller items, like bottles, and silverware
  • Intuitive LCD Touch Controls
    Easily select your cycle and customize wash and dry selections with the glass touch controls and brilliant LCD screen
  • Hard Food Disposer
    Designed to maintain a kitchen's cleanliness and efficiency, the hard food disposer with stainless steel blades grinds food into tiny particles that wash away with ease
  • WiFi Connected With SmartHQ
    Built-in WiFi and the SmartHQ app make it easy to control and monitor your dishwasher, wherever you are
  • Handles Sold Separately
    Elevate your dishwasher's look by selecting a Statement or Minimalist Collection handle
  • Panel Ready Design
    Designed to simplify panel alignment and installation, ensuring a flawless fit with your kitchen
