MIELE DAS4720 DAS 4720 Stainless steel - Built-in ventilation hood for installation in narrow upper cabinets with EasySwitch controls in Stainless Steel
Sale price
$1,699.00
Regular price
$1,938.97
Save
$239.97
/ 12% OFF
In Stock
Extended Protection
?
Extend your appliance's warranty beyond the manufacturer's terms with our Extended Protection Plan.
Enjoy added peace of mind long after the original warranty expires.
This Protection Plan includes:
- Full parts and labor coverage during the whole period of the extension plan.
- Protection for the case of a power surge during both the period of the extension plan and manufacturer’s warranty
- Food loss protection
- 24/7 toll-free number for support
-
$49.99
-
$83.99
-
$131.99
-
$195.99
-
Delivery services
?
Delivery Services:
We offer a range of delivery services to meet your needs. Please note that these services are not available in certain locations.
For more details, please visit our Delivery and Installation Services page.
-
$180.00
-
$49.99
Thanks for contacting us.
We'll get back to you as soon as possible.
Error!
Something went wrong, please try again later.
Sale price
$1,699.00
Regular price
$1,938.97
Save
$239.97
/ 12% OFF
Product Details for MIELE DAS4720
Technical Details
Design
| Built-in ventilation hood | Yes |
| Color | Stainless steel |
General information
| Model number | DAS 4720 |
| Manufacturer material number | 11878520 |
| EAN number | 4002516495925 |
Operating modes
| Recirculated mode | Can be retrofitted |
| Recirculation conversion kit (order separately) | DUU 151,DUU 150 |
| OdorFree charcoal filter (order separately) | 31.0 |
User convenience
| Miele@home | Yes |
| Automatic function | Con@ctivity 3.0 |
| Automatic function Con@ctivity | Yes |
| Electronic controls | Yes |
| EasySwitch | Yes |
| Operation | EasySwitch |
| Booster levels | 1 |
| Programmable Intensive switch-off | Yes |
| Con@ctivity | Yes |
| Delayed shutdown for 5 or 15 minutes | Yes |
| Grease filter saturation indicator | Yes |
| Active charcoal filter saturation indicator | Yes |
| CleanCover | Yes |
Lighting
| LED ClearView lighting | Yes |
| Number x W | 1 |
| Light intensity in Lx | 330 |
| Color temperature in K | 3500 |
| Light dimmer function | Yes |
Blower
| Dual-action blower | Yes |
| AC motor | Yes |
Exhaust air
| Air throughput | Values upon request |
| Air throughput with Booster level 1 (m /h) according to EN 61591 | 497.35 |
| Air throughput in CFM in Booster | 498 |
Technical data
| Canopy width in in. (mm) | 29 7/8 (758) |
| Canopy height in in. (mm) | 1 1/2 (36) |
| Depth of hood canopy in in. (mm) | 10 3/4 (273) |
| Minimum height above electric cooktops in mm | 24 1/8 (610) |
| Minimum safety distance above gas cooktops (max. 12.6 kW total power, burner 4.5 kW) in mm | 26 |
| Net weight in lbs. (kg) | 36 |
| Length of electrical wire in ft. (m) | 2 |
| Standard plug fitted | Yes |
| Plug type | NEMA plug: 5-15 |
| Total connected load in kW | 0.353 |
| Voltage in V | 120 |
| Fuse rating in A | 15 |
| Frequency in Hz | 60 |
| Number of phases | 1 |
Features
- Classic design - stainless-steel panel, 30" wide
- Con@ctivity
Innovative convenience: the ventilation hood reacts automatically to settings on the cooktop. - Unique user convenience - Con@ctivity
- Delayed shutdown
Odor-free room air: "after cooking, the blower can be set to switch off automatically after 5 or 15 minutes." - LED strip for uniform lighting
- filter saturation indicator
Easy filter replacement: a red light lets you know when the grease and/or charcoal filter is saturated. - Efficient filtration- 10-ply stainless steel grease filters
- Safety turn off
Sensible, even in case of operating errors: The ventilation hood switches off automatically after 10 hours. - Recirculation mode - Active AirClean or Longlife AirClean filter
- Con@ctivity 3.0
Innovative convenience: The ventilation hood reacts automatically to settings on the cooktop. - Manufactured with great care by Miele & Cie. KG
- Stainless-steel grease filters (10-layer)
Looks great and does a good job: Effective grease filtering and easy cleaning inside the dishwasher. - View manufacturer details: Miele & Cie. KG
- Safety information
- Miele CleanCover
Protection and easy cleaning: The sealed, smooth surface prevents contact with cables and the motor.
Description
What's included
Non-return flap
Non-return flap
Manuals & Guides
Key Features
Con@ctivity
Innovative convenience: the ventilation hood reacts automatically to settings on the cooktop.
Delayed shutdown
Odor-free room air: "after cooking, the blower can be set to switch off automatically after 5 or 15 minutes."
filter saturation indicator
Easy filter replacement: a red light lets you know when the grease and/or charcoal filter is saturated.
Safety turn off
Sensible, even in case of operating errors: The ventilation hood switches off automatically after 10 hours.
Con@ctivity 3.0
Innovative convenience: The ventilation hood reacts automatically to settings on the cooktop.
Stainless-steel grease filters (10-layer)
Looks great and does a good job: Effective grease filtering and easy cleaning inside the dishwasher.
Miele CleanCover
Protection and easy cleaning: The sealed, smooth surface prevents contact with cables and the motor.
Classic design - stainless-steel panel, 30" wide
Recirculation mode - Active AirClean or Longlife AirClean filter
Unique user convenience - Con@ctivity
Manufactured with great care by Miele & Cie. KG
LED strip for uniform lighting
