MIELE DAC2247 DAC 2247 Stella Stainless steel - Ceiling extractor in compact design in 45 7/8 (1165) in (mm) width in Stainless Steel
Sale price
$2,999.00
Regular price
$4,388.97
Save
$1,389.97
/ 31% OFF
Out of stock
Thanks for contacting us.
We'll get back to you as soon as possible.
Error!
Something went wrong, please try again later.
Sale price
$2,999.00
Regular price
$4,388.97
Save
$1,389.97
/ 31% OFF
Product Details for MIELE DAC2247
Technical Details
General information
| Model number | DAC 2247 Stella |
| Manufacturer material number | 12565890 |
| EAN number | 4002516805946 |
Design
| Ceiling fan | Yes |
| Color | Stainless steel |
| Edge extraction | Yes |
Operating modes
| Recirculated mode | Can be retrofitted |
| OdorFree charcoal filter (order separately) | DKF 40-R |
User convenience
| Miele@home | Yes |
| Automatic function Con@ctivity | Yes |
| Electronic controls | Yes |
| EasySwitch | Yes |
| Operation | EasySwitch |
| ON/OFF switch | Yes |
| Power levels (number excl. Intensive) | 3 |
| Booster levels | 1 |
| Delayed shutdown for 5 or 15 minutes | Yes |
| Grease filter saturation indicator | Yes |
| Active charcoal filter saturation indicator | Yes |
| CleanCover | Yes |
Efficiency and sustainability
| ECO motor (DC motor) | Yes |
| PowerManagement system | Yes |
Lighting
| Number x W | 2 |
| Light intensity in Lx | 450 |
| Color temperature in K | 3500 |
Blower
| Dual-action blower | Yes |
| DC motor | Yes |
Exhaust air
| Air throughput | Values upon request |
| Air throughput with Booster level 1 (m /h) according to EN 61591 | 473.81 |
| Air throughput in CFM in Booster | 474 |
Technical data
| Overall hood height for vented mode and external in inches (mm) | 11 3/4 (296) |
| Overall height for recirculation mode ventilation hoods in mm | 11 3/4 (296) |
| Overall min. height for vented and external in in. (mm) | 11 3/4 (296) |
| Overall max. height for vented and external in in. (mm) | 11 3/4 (296) |
| Overall min. height for recirculation in in. (mm) | 11 3/4 (296) |
| Overall max. height for recirculation in in. (mm) | 11 3/4 (296) |
| Canopy width in in. (mm) | 45 7/8 (1165) |
| Canopy height in in. (mm) | 11 3/4 (296) |
| Depth of hood canopy in in. (mm) | 19 3/4 (500) |
| Minimum height above electric cooktops in mm | 24 1/8 (610) |
| Minimum safety distance above gas cooktops (max. 12.6 kW total power, burner 4.5 kW) in mm | 26 |
| Net weight in lbs. (kg) | 50 |
| Length of electrical wire in ft. (m) | 2 |
| Standard plug fitted | Yes |
| Plug type | NEMA plug: 5-15 |
| Total connected load in kW | 0.194 |
| Voltage in V | 120 |
| Fuse rating in A | 15 |
| Frequency in Hz | 60 |
| Number of phases | 1 |
Installation note
| Vent connection on side | Yes |
| Diameter of vent connection in in. (mm) | 6 |
Standard accessories
| Non-return flap | Yes |
| Reducer from 150 to 125 mm | Yes |
| Remote control | Yes |
Features
- Suitable for every home - vented or recirculating
- Delayed shutdown
Odor-free room air: "after cooking, the blower can be set to switch off automatically after 5 or 15 minutes." - Con@ctivity
Innovative convenience: the ventilation hood reacts automatically to settings on the cooktop. - Convenient operation - with Con@ctivity and remote control included
- filter saturation indicator
Easy filter replacement: a red light lets you know when the grease and/or charcoal filter is saturated. - Economy-Motor
Powerful and economical: The DC motor saves up to 50% electricity compared with conventional motors. - Powerful - 473.81 (805) ft /min (m3/h) in Booster level
- Powerful - in Booster level
- Efficient filtration- 10-ply stainless steel grease filters
- Safety turn off
Sensible, even in case of operating errors: The ventilation hood switches off automatically after 10 hours. - Panel can be customized
- Stainless-steel grease filters (10-layer)
Looks great and does a good job: Effective grease filtering and easy cleaning inside the dishwasher. - Manufactured with great care by Miele & Cie. KG
- View manufacturer details: Miele & Cie. KG
- Miele CleanCover
Protection and easy cleaning: The sealed, smooth surface prevents contact with cables and the motor. - Safety information
- Edge vented
Efficient and good-looking: With edge extraction, the grease filters are covered by a panel.
Description
What's included
Non-return flap
Reducer from 150 to 125 mm
Remote control
Non-return flap
Reducer from 150 to 125 mm
Remote control
Manuals & Guides
Key Features
Con@ctivity
Innovative convenience: the ventilation hood reacts automatically to settings on the cooktop.
Delayed shutdown
Odor-free room air: "after cooking, the blower can be set to switch off automatically after 5 or 15 minutes."
filter saturation indicator
Easy filter replacement: a red light lets you know when the grease and/or charcoal filter is saturated.
Economy-Motor
Powerful and economical: The DC motor saves up to 50% electricity compared with conventional motors.
Safety turn off
Sensible, even in case of operating errors: The ventilation hood switches off automatically after 10 hours.
Stainless-steel grease filters (10-layer)
Looks great and does a good job: Effective grease filtering and easy cleaning inside the dishwasher.
Miele CleanCover
Protection and easy cleaning: The sealed, smooth surface prevents contact with cables and the motor.
Edge vented
Efficient and good-looking: With edge extraction, the grease filters are covered by a panel.
Efficient filtration- 10-ply stainless steel grease filters
Suitable for every home - vented or recirculating
Panel can be customized
