Product Details for Liebherr UF501

Technical Details

General product information

Series Premium
Model type Integrated under-worktop freezer with NoFrost
GTIN 4016803122296

Output and consumption

Voltage 115 V ~
Frequency 60 Hz
Noise level 38
Connection rating 2.3 A 188 W
Energy consumption per year 302
Energy consumption in 24h 0.827

Control and functions

SuperFrost Automatic
Malfunction: Warning signal optical and acoustical
Temperature display Freezer
Type of control Magic Eye with LC and digital temperature display
Door alarm, freezing visual and audible
Position of control unit behind the door
Front frame heating present
BottleTimer
Control unit Touch

Freezer compartment

Ice cube tray Ice cube tray with lid
Freezer tray 0
Ice cube storage 0.0
Adjustable temperature range +7 °F to -18 °F
FrostSafe Drawers closed on all sides, transparent
No. of drawers in freezer compartment 3
Star-rating 4
VarioSpace
Freezing capacity in 24 hrs 0.0
Defrosting method automatic
Interior light, freezer compartment LED light
Number of cold storage accumulators 2
Number of ice cube trays 1

Design and materials

Material of adjustable shelves in the freezer compartment Glass

Set-up and installation

Connector cable (length) 2,220
Door opening angle 115°
Door hinges Left
Height-adjustable feet 4
Levelling bars
Type of installation Under-worktop
Ventilation Base ventilation
Door assembly Fixed door
Plug type USA

Other

Net capacity, total 0.0

Dimensions & weight

Width 23.56 in.
Height 32.31 in.
Length 21.69 in.
Weight 88.8 lbs.

Number of boxes, shipping dimensions, & shipping weight

Number of Boxes 1
Shipping Width 28.56 in.
Shipping Height 37.31 in.
Shipping Length 26.69 in.
Shipping Weight 128.8 lbs.
Total of Shipping Weight 128.8 lbs.
Source Calculation

Cubic feet measurement & dimensional weight

Cubic Feet Measurement 9.56 ft³
Dimensional Weight 118.79 lbs.
Total of Cubes 9.56 ft³
Total of Dimensional Weight 118.79 lbs.

Description

Freezing fresh food in this Liebherr undercounter freezer is easy with SuperFrost technology. Liebherr's SuperFrost setting speeds up freezing so that your freshly stored food can be frozen rapidly. This unique 24-inch wide freezer includes three transparent and fully removable FrostSafe drawers on rollers to best organize frozen foods. Since the FrostSafe drawers are fully enclosed, the continuously circulating cold air does not escape when the door is opened, enhancing the freezer’s energy efficiency. This unit also includes a hidden compartment at the bottom of the freezer for additional storage. The door closes gently and without slamming even when the freezer is full, thanks to Liebherr’s SoftSystem technology. Choose Liebherr for energy efficiency and superior performance for years to come.


Product Features

  • German Engineering
    Our superior products offer premium quality, cutting edge design and innovative features that fit with your busy lifestyle. Plus, exclusive components and materials along with the latest production processes ensure energy efficiency and performance for years to come.
  • NoFrost
    Liebherr’s NoFrost appliances provide expert refrigeration technology to ensure long-term freshness. The food is frozen with chilled recirculating air, and any humidity is expelled. As a result, the freezer is always free of ice, and food no longer frosts over. NoFrost convenience makes defrosting a thing of the past.
  • Energy Star
    Liebherr refrigerators help to produce less energy waste and greenhouse gas emissions with the aim to have the least damaging effect on the environment and offering solutions that help consumers conserve energy.
  • Automatic SuperFrost function
    The automatic SuperFrost function makes freezing simple and saves energy. It quickly reduces the temperature to -32 °C and thus creates the cold air required to preserve vital vitamins. As soon as the food is completely frozen, the automatic SuperFrost function switches back to normal mode after max. 65 hours, and thus assists in saving electricity.
  • Door alarm
    The audible door alarm alerts the user if the door has been open for longer than 60 seconds for safe protection of the food.
  • Temperature alarm
    The temperature alarm notifies immediately visually and audibly in case of inadvertent&nbsp; <font>temperature deviations</font>, for example when a door is opened or after a power failure.
  • FrostSafe
    With the FrostSafe, the extra-high and removable drawers are closed all round. This means that the cold cannot dissipate so quickly when the appliance is opened. The transparent front of the compartments guarantees an optimum overview of the frozen items.
  • VarioSpace
    All freezers with NoFrost and SmartFrost feature drawers and intermediate glass shelves underneath them which can be conveniently removed.This results in VarioSpace – the practical system for extra storage space so that space can be created quickly even for larger frozen food items.
  • Reversible door hinges
    It is possible to change the door hinge on the appliance. The reversible door hinges permit optimum use of the appliance wherever it is located.
  • Door-on-door system
    The unit door and appliance door are firmly interconnected with the unit door being fixed directly onto the appliance door.
  • VarioBase
    The VarioBase permits the adjustment of kitchen units in height and depth. All four height-adjustable feet permit adjustment from the front with a 60 mm range. In addition, the ventilation grille can be adjusted within a range of 55 mm to match the front of the kitchen units.
