SKU: KUIX535HPA | UPC: 883049483283

KitchenAid KUIX535HPA 15'' Automatic Ice Maker Panel Ready

15'' Automatic Ice Maker
15'' Automatic Ice Maker
15'' Automatic Ice Maker
15'' Automatic Ice Maker

Quick Specification More details

  • Width:
    17.25"
  • Depth:
    26" - 27"
  • Height:
    36.07"
  • Type:
    Ice Machines

About this product

  • Fully Flush Installation with Articulating Hinge
  • Clear Ice Technology
  • Built-In Drain Pump System
  • Holds 25 Pounds of Ice

SKU: KUIX535HPA | UPC: 883049483283

KitchenAid KUIX535HPA 15'' Automatic Ice Maker Panel Ready

Active Rebates

KT Appliance

We’ll confirm fit, specs & delivery before you order.

  •  Chat  • Email  • Call Us

Related Accessories

Quick Specification More details

  • Width:
    17.25"
  • Depth:
    26" - 27"
  • Height:
    36.07"
  • Type:
    Ice Machines

About this product

  • Fully Flush Installation with Articulating Hinge
  • Clear Ice Technology
  • Built-In Drain Pump System
  • Holds 25 Pounds of Ice

Related Products

  • Product Details
  • Manuals & Guides
  • Key Features
  • From The Manufacturer
  • Reviews
Contact us for Pricing

Product Details for KitchenAid KUIX535HPA

Technical Details

Warranty
Parts 2 Year
Labor 2 Year

Controls
Control Location Interior Up Front
Control Type Electronic Touch
Ambient Temperature Range 55F to 110F

Details
Drain Connection Rear Access 5/8in. OD
Drain Pump Pump Included
Stainless Steel Cutting Grid 3/4in. x 3/4in. Cubes
Water Inlet Connection 1/4in. OD PEX Tubing
Door Opening Direction Right
Ice Capacity Storage 25
Water Supply Pressure 30 - 120 psi

Certifications
ADA Compliant No
UL Yes
prop65 Standard - Standard

Dimensions & weight
Width 17.25 in.
Height 36.07 in.
Length 28.37 in.
Weight 107 lbs.
Cabinet Width (in) 14 7/8
Carton Depth 28 3/8
Carton Height 36 1/8
Carton Width 17 1/4
Cutout Depth (in) 25
Cutout Height (in) 34 1/2
Cutout Width (in) 15
Depth Closed Excluding Handles 24 5/8
Depth Closed Including Handles 26 1/16
Depth Excluding Doors 22 1/8
Depth With Door Open 90 Degree 39 1/2
Gross Weight 107 lbs.
Height To Top Of Cabinet 33 5/8
Height To Top Of Door Hinge 34 1/16
Net Weight 96.5
Cabinet Width (IN,inches) 14.8750
Cutout Depth(IN,inches) 25.0000
Cutout Height(IN,inches) 34.5000
Cutout Width(IN,inches) 15.0000
Depth Closed Excluding Handles(IN,inches) 24.6250
Depth Closed Including Handles(IN,inches) 26.0625
Depth Excluding Doors(IN,inches) 22.0625
Depth With Door Open 90 Degree(IN,inches) 39.5625
Height To Top Of Cabinet(IN,inches) 33.6250
Height To Top Of Door Hinge(IN,inches) 34.0625
Net Weight(LB,pounds) 96
Carton Depth(IN,inches) 28.3750
Carton Height(IN,inches) 36.1250
Carton Width(IN,inches) 17.2500
Gross Weight(LB,pounds) 107

Number of boxes, shipping dimensions, & shipping weight
Number of Boxes 1
Shipping Width 20 in.
Shipping Height 41.13 in.
Shipping Length 31.06 in.
Shipping Weight 147 lbs.
Total of Shipping Weight 147 lbs.
Source Calculation

Cubic feet measurement & dimensional weight
Cubic Feet Measurement 8.17 ft³
Dimensional Weight 101.62 lbs.
Total of Cubes 8.17 ft³
Total of Dimensional Weight 101.62 lbs.

Dimensions
Cutout Depth 25
Cutout Height 34.5
Cutout Width 15
Height To Top Of Cabinet 33.625
Height To Top Of Door Hinge 34.063
carton depth 28.37
carton height 36.07
carton width 17.25
gross weight 107 lbs.
net weight 96.5

Exterior details
Cabinet Finish Textured
Cabinet Material Prepainted Steel
Handle Location Horizontal
Reversible Door Yes

Filter details
Water Filter Indicator/Reset Yes
Water Filter Location Interior
Water Filter Part Number F2WC9I1

Freezer details
Defrost Type Automatic Defrost

Icemaker details
Ice Maker On/Off Yes

Oven details
Interior Light LED

Refrigerator details
Interior Liner Finish Plastic
Liner Color White

Capacity
Volume 10.215 Cu.Ft.

Description

Enjoy an ample supply of clear, uniformly shaped ice cubes ideal for a variety of everyday applications. This 15-inch ice maker accepts an overlay-style front panel (requires custom panel and handle, not included) that adds an elegant finishing touch to your kitchen or bar area. Fully Flush Installation blends with surrounding cabinetry for a refined built-in look.


Product Features

  • Clear Ice Technology
    provides cubes of uniform 3/4" x 3/4" x 1/2" size and shape that are ideal for daily use or a variety of entertaining needs. Clear Ice Technology allows for attractive drink presentation and a slow melt rate so beverages won't water down quickly.
  • Built-In Drain Pump System
    Allows this ice maker to be installed nearly anywhere in the home within 100 feet of an under-sink drain line, so you can keep a continuous supply of clear ice in your kitchen or entertaining space
  • Holds 25 Pounds of Ice
    ensures a generous supply of fresh ice is conveniently at your fingertips.
  • Max Ice
  • Reversible Door
    offers flexible installation options by allowing hinge installation on either side of the door.

Manuals & Guides

Key Features

Fully Flush Installation with Articulating Hinge

allows the ice maker's door to sit flush without protruding or leaving a gap between the ice maker and the adjoining cabinets. Articulating hinge design allows the door to open 90 degrees without swinging beyond its normal closed width, providing a built-in look that adds a touch of style to your kitchen or bar space.

Filter-Ready

provides a dedicated space where a filter can be inserted to help remove contaminants, improving taste and clarity. A filter is not required but can be purchased separately. Use filter #F2WC9I1 and change every six months for best results.

PrintShield™ Finish

resists smudges and fingerprints. The specialized coating for stainless steel is easy to clean with just water and a soft cloth, so you can spend more time cooking and less time cleaning up.

Self Cleaning Cycle

Uses high temperature to power through soils in the oven cavity, requiring only a quick wipe down at the end of the cycle.
