Product Details for HOSHIZAKI WLF46B

Technical Details

Dimensions & weight

Weight 278 lbs.
Width 46 in.
Depth 33.25 in.
Height 40.25 in.

Number of boxes, shipping dimensions, & shipping weight

Number of Boxes 1
Shipping Weight 318 lbs.
Total of Shipping Weight 318 lbs.
Source Calculation

Product details

Electrical Specs Electrical Connection: 5 – 15P NEMA, 115v/60/1, 10 ft. cord and plug, Energy Consumption: 3.36 kwh/day, Amperage: 4, Max Fuse/HACR Breaker: 15 A
Operating Limits Ambient Temp Range: 45 – 100°F, Voltage Range: 104 – 126V, Control Setpoint Range: -10 – +10°F, Refrigerant: R290
Refrigeration Data Nominal Compres. of 2431 BTU/hr at 1/3+ HP, Heat Rejection: 645 BTU/hr
Shipping Weight 278
Storage Specs Nominal storage capacity: 11.78 ft3, Interior storage capacity: 11.78 ft3, Door opening: 25.5″ W x 23″ H, Depth with door fully extended: 60.5″ D, Shelves included: 2

Warranty

Parts 7 Years
Labor 7 Years
Compressor 7 Years

Description

The WLF46B Steelheart Series Worktop single section side mount freezer with a stainless door is a space saving workhorse. Engineered to maintain food safe temperatures in 100°F ambient conditions. With a net capacity of 11.78 cubic feet this efficient worktop side mount freezer and front air flow design is perfect for hot/tight kitchens. The WLF46B is constructed of stainless steel, which protects this unit from accidental damage and rust. Plus, it is easy to clean. The WLF46B also includes (2) epoxy coated wire shelves adjustable in 1/2″ increments on anodized aluminum supports, (4) 6″ stem casters (2 with brakes) are standard, plus a field reversible, spring assisted self closing door with stay open feature (no kit req’d). Electrical consumption of 3.36 kWh/day at 4 Amps, 10 ft long cord with a 5 – 15P NEMA plug. Optional kits: 2″ or 4″ casters, Overshelves (single or double), Epoxy wire shelf, Stainless steel shelf, Foot pedal kit (left or right hinge), See Spec Sheet for additional options. The unit is ETL Safety (US & C) Listed, ETL Sanitation, Georgia Made Certified, ENERGY STAR® Qualified and includes a 7-7-7 Warranty (seven years labor, seven years parts, seven years compressor — visit hoshizakiamerica.com/support/warranty for eligibility information).


Product Features

  • Net capacity of 11.78 cubic feet
  • Innovative air distribution system distributes air evenly to maintain product temperature
  • Stainless steel exterior (front, sides, top) and a stainless steel interior
  • Enamel coated evaporator coil for extended life
  • Extruded aluminum flush mount door handle
  • (1) stainless steel door with ABS interior liner
  • R290 refrigerant
  • Automatic off-cycle defrost
  • Nominal Compres. of 2431 BTU/hr at 1/3+ HP
  • 115v/60/1, 10 ft. cord and plug
  • ENERGY STAR® qualified
  • 7-7-7 Warranty (seven years labor, seven years parts, seven years compressor)
