Product Details for HOSHIZAKI ULF60B

Technical Details

Dimensions & weight

Weight 322 lbs.
Width 60 in.
Depth 33.25 in.
Height 33.875 in.

Number of boxes, shipping dimensions, & shipping weight

Number of Boxes 1
Shipping Weight 362 lbs.
Total of Shipping Weight 362 lbs.
Source Calculation

Product details

Electrical Specs Electrical Connection: 5 – 15P NEMA, 115v/60/1, 10 ft. cord and plug, Energy Consumption: 4.5 kwh/day, Amperage: 5, Max Fuse/HACR Breaker: 15 A
Operating Limits Ambient Temp Range: 45 – 100°F, Voltage Range: 104 – 126V, Control Setpoint Range: -10 – +10°F, Refrigerant: R290
Refrigeration Data Nominal Compres. of 2870 BTU/hr at 1/2+ HP, Heat Rejection: 786 BTU/hr
Shipping Weight 322
Storage Specs Nominal storage capacity: 17.22 ft3, Interior storage capacity: 17.22 ft3, Door opening: 19.5″ W x 23″ H, Depth with door fully extended: 54.75″ D, Shelves included: 4

Warranty

Parts 7 Years
Labor 7 Years
Compressor 7 Years

Description

The ULF60B Steelheart Series Undercounter two section side mount freezer with stainless doors is a space saving workhorse. Engineered to maintain food safe temperatures in 100°F ambient conditions. With a net capacity of 17.22 cubic feet this efficient undercounter side mount freezer and front air flow design is perfect for hot/tight kitchens. The ULF60B is constructed of stainless steel, which protects this unit from accidental damage and rust. Plus, it is easy to clean. The ULF60B also includes (4) epoxy coated wire shelves adjustable in 1/2″ increments on anodized aluminum supports, (4) 4″ stem casters (2 with brakes) are standard, plus field reversible, spring assisted self closing doors with stay open feature (no kit req’d). Electrical consumption of 4.5 kWh/day at 5 Amps, 10 ft long cord with a 5 – 15P NEMA plug. Optional kits: 2″ or 6″ casters, Overshelves (single or double), Epoxy wire shelf, Stainless steel shelf, Foot pedal kit (left or right hinge), See Spec Sheet for additional options. The unit is ETL Safety (US & C) Listed, ETL Sanitation, Georgia Made Certified and includes a 7-7-7 Warranty (seven years labor, seven years parts, seven years compressor — visit hoshizakiamerica.com/support/warranty for eligibility information).


Product Features

  • Net capacity of 17.22 cubic feet
  • Innovative air distribution system distributes air evenly to maintain product temperature
  • Enamel coated evaporator coil for extended life
  • Stainless steel exterior (front, sides, top) and a stainless steel interior
  • (2) stainless steel doors with ABS interior liner
  • Extruded aluminum flush mount door handles
  • R290 refrigerant
  • Nominal Compres. of 2870 BTU/hr at 1/2+ HP
  • 115v/60/1, 10 ft. cord and plug
  • 7-7-7 Warranty (seven years labor, seven years parts, seven years compressor)
