SKU: IM50BAAQ

Hoshizaki IM50BAAQ Sphere Cube Icemaker, Air-cooled, Built in Storage Bin Stainless Steel

Active Rebates

We’ll confirm fit, specs & delivery before you order.

• Chat • Email • Call Us

Quick Specification More details

Width:
24.75"
Depth:
20.75"
Height:
39.5"
Type:
Ice Makers

About this product

Up to 50 lbs or 500 spheres of ice produced per 24 hours
Up to 36 lbs of built-in storage capacity (ft3)
Produces individual sphere cubes
Durable stainless steel exterior

Product Details for HOSHIZAKI IM50BAAQ

Technical Details

Product details

Utility Consumption	15.7 kWh per 100 lbs @ 90/70, 69 gal of Potable Water per 100 lbs @ 90/70
Electrical Specs	Single phase, 115v/60/1, 6′ 5″ ft cord with NEMA 5-15 plug, Amperage: 5, Max Fuse/HACR Breaker: 15 A
Operating Limits	Ambient Temp Range: 45 – 100°F, Water Temp Range: 45 – 90°F, Water Pressure: 7 – 113psig, Voltage Range: 104 – 127V, Heat Rejection: 1500 BTU/hr, Refrigerant Charge: R-134a, (7.1 oz. / 201 g)
Plumbing Specs	1/2″ FPT Inlet, Minimum 1/2″ Nominal ID Copper Water Tubing or Equivalent, 3/4″ FPT Outlet, Minimum 3/4″ Nominal ID Hard Pipe or Equivalent

Number of boxes, shipping dimensions, & shipping weight

Number of Boxes	1
Source	Calculation

Dimensions & weight

Width	24.75 in.
Depth	20.75 in.
Height	39.5 in.

Warranty

Parts	3 Years
Labor	3 Years
Parts (Condenser)	5 Years

Description

The IM-50BAA-Q is capable of producing approximately 50 lbs of individual sphere cubes. The sphere cube shape melts very slowly, chilling beverages with very minimal dilution. This Air-cooled, Built in Storage Bin icemaker features Up to 36 lbs of built-in storage capacity (ft3)*. The IM-50BAA-Q is a Single phase, 115v/60/1, 6.5 ft. cord with NEMA 5-15 plug and uses R-134a refrigerant (7.1 oz. / 201 g). Nozzle injects water into the sphere ice forming chamber of the evaporator, making 15 spheres at a time. Please consult the Specification Sheet for additional details.*Rated in accordance with AHRI Standard 820(I-P). Capacity based on 100% of total volume x 30 lb/ft3 average density of ice.

Product Features

Up to 50 lbs or 500 spheres of ice produced per 24 hours
Up to 36 lbs of built-in storage capacity (ft3)
Produces individual sphere cubes
Durable stainless steel exterior
Front in, back out airflow
Ice scoop included
Foam injected polyurethane for insulation (HFC free)
Nozzle injects water into the sphere ice forming chamber of the evaporator, making 15 spheres at a time
R-134a refrigerant (7.1 oz. / 201 g)
5 amps (15 Amp Max fuse)
15.7 kwh/100 lbs.@ 90/70
Single phase, 115v/60/1, 6.5 ft. cord with NEMA 5-15 plug
Clean ice and easy maintenance lead to longer unit life span
Five Years: Parts warranty on Compressor, air-cooled condenser coil.
Dimensions: 24-3/4″ W x 20-3/4″ D x 39- 1/2 ” H
Heat Rejection:1500 BTU/hr
Three Years: Parts & Labor warranty on entire machine.
