Hoshizaki HDD380S Refrigerator, Three Section, Stainless Steel Back Bar Direct Draw, Solid Doors
Active Rebates
Thanks for contacting us.
We'll get back to you as soon as possible.
Error!
Something went wrong, please try again later.
Sale price
Contact us for Pricing
Product Details for HOSHIZAKI HDD380S
Technical Details
Product details
| Electrical Specs | Electrical Connection: 5 – 15P NEMA, 115v/60/1, 10 ft. cord and plug, Energy Consumption: N/A Watts, Amperage: 5.2, Max Fuse/HACR Breaker: 15 A |
| Operating Limits | Ambient Temp Range: 45 – 100°F, Voltage Range: 104 – 126V, Control Setpoint Range: 33 – 38°F, Refrigerant: R-134a |
| Refrigeration Data | Nominal Compres. of N/A BTU/hr at 1/3 HP, Heat Rejection: 2345 BTU/hr |
| Shipping Weight | 385 |
| Storage Specs | Interior Storage Capacity: 26.79ft3, Door Opening: 19.6875″ W x 28.625″ H , Depth with Door fully extended: 51.5″ D, Keg Cushions Included: 4 |
Dimensions & weight
| Width | 80 in. |
| Depth | 29 in. |
| Height | 36.88 in. |
Warranty
| Parts | 3 Years |
| Labor | 3 Years |
Description
The HDD-3-80-S Back Bar Direct Draw is a Three Section Refrigerator with a solid door that has all the right features. It boasts an impressive Net capacity of 26.79 cubic feet. The durable 1/3 HP motor that powers the compressor at the side of this unit that distributes air from left to right rather than from back to front. Side to side circular airflow ensures ice-cold products even when doors are opened regularly. Engineered to maintain food safe temperatures in +100°F kitchens. Plus the self-closing doors come standard with barrel locks.
Product Features
- Discontinued – Replaced by DD80-S
- Dimensions: 80″ W x 29″ D x 36.88″ H
- Net capacity of 26.79 cubic feet
- Nominal Compres. of N/A BTU/hr at 1/3 HP
- Electrical consumption of N/A kWh/day at 5.2 Amps, 10 ft long cord with a 5 – 15P NEMA plug
- Engineered to maintain food safe temperatures in +100°F kitchens
- Includes (4) keg cushions to protect floor and allow air to circulate below kegs
- One piece, vinyl coated steel handle with built-in lock
- (2) polished stainless steel insulated towers with (4) plated brass faucets
- Self-closing doors come standard with barrel locks
- Front breathing, side mount refrigeration that distributes air from left to right rather than from back to front
- Stainless Steel exterior front, sides and rear, plus a 18 gauge stainless steel top
- Stainless steel interior with LED lights
- R-134a refrigerant
- Automatic “off cycle” defrost cycle
- Thick stainless steel threshold protects door frame when loading and unloading cabinet
- Fits: (4) 1/2 Barrels (Keg)
- Cabinets walls and doors well insulated (2″ thick) and are designed to maintain interior temperatures between 33°F to 38°F
- Electronic controller with LED display (°F or °C)
- Made to Order
- 115v/60/1, 10 ft. cord and plug
- Shipping Crate: 82.5″ L x 31.25″ D x 42.5″ H at 385 lbs
- Cabinet fits: (4) 1/2 barrels and (1) slim 1/4 barrel, or (6) slim 1/4 barrels, or (8) 1/6 barrels, or (1) 1/2 barrel and (1) slim 1/4 barrel and (3) 1/6 barrels
- Five Years compressor warranty, Three Years parts and labor warranty
