SKU: DB130H

Hoshizaki DB130H 22″ W Hotel/Motel Ice Dispenser with 130 lbs Capacity – Stainless Steel Exterior

Quick Specification More details

Width:
22"
Depth:
30"
Height:
53"
Type:
Ice Makers

About this product

Stainless steel auger and agitator
Single phase, 115v/60/1, Hardwired connection (no cord/plug included)
Stores up to 130 lbs of ice
Push button single auger agitator dispenses ice at 20 lbs. per minute

Summer Sale

Clearance

SKU: DB130H

Hoshizaki DB130H 22″ W Hotel/Motel Ice Dispenser with 130 lbs Capacity – Stainless Steel Exterior

Active Rebates

We’ll confirm fit, specs & delivery before you order.

• Chat • Email • Call Us

Quick Specification More details

Width:
22"
Depth:
30"
Height:
53"
Type:
Ice Makers

About this product

Stainless steel auger and agitator
Single phase, 115v/60/1, Hardwired connection (no cord/plug included)
Stores up to 130 lbs of ice
Push button single auger agitator dispenses ice at 20 lbs. per minute

Product Details for Hoshizaki DB130H

Technical Details

Product details

Electrical Specs	Single phase, 115v/60/1, Hardwired connection (no cord/plug included), Amperage: 1.4, Max Fuse/HACR Breaker: 15 A
Compatible Icemakers	KM-340M, KM-515M, KM-600M, KM-650M
Ice Storage Capacity	130 lbs, Cubic Volume: 3.7 ft3
Shipping Weight	195

Dimensions & weight

Weight	195 lbs.
Width	22 in.
Depth	30 in.
Height	53 in.

Number of boxes, shipping dimensions, & shipping weight

Number of Boxes	1
Shipping Weight	235 lbs.
Total of Shipping Weight	235 lbs.
Source	Calculation

Warranty

Parts	3 Years
Labor	3 Years

Description

Safely store and dispense up to 130 lbs of ice with this Hotel/Motel Ice Dispenser. The DB-130H is the perfect 22″ wide ice storage bin and dispenser for many resorts, hotels, and other hospitality services! It boasts a seamless bin linear and Foamed-in-place polyurethane insulation in all of the bin walls including the bottom of the unit providing your operation with maximum ice preservation. The DB-130H features a durable and easy to maintain Stainless Steel exterior cabinet. This model comes Standard with 6″ Painted Flange Legs and the Ice dispensing area is ADA compliant. Single phase, 115v/60/1, Hardwired connection (no cord/plug included), 60 W dispensing gear motor, 1.4 Amps, 3/4″ FPT drain. The unit is UL Listed, ETL Sanitation Listed, ADA Compliant, Georgia Made Certified and includes a Three Years: Parts & Labor warranty on entire machine. Compatible icemakers/dispensers, sold separately: KM-340M, KM-515M, KM-600M, KM-650M
