| Parts | 1 Year |
| Labor | 1 Year |
| App Filter-Multi Brand | Monogram |
| App Filter - Hood Type | Telescopic downdraft |
| App Filter - Venting Type | External |
| App Filter - Cabinet Width | Vent 36 in. |
| Fan Speed Control | Variable |
| Optional Blower Mount Capabilities | Yes |
| Max CFM | 500 |
| Downdraft Exhaust (CFM) | 500 |
| Exhaust Options | Vented to Outside |
| Product Type | Telescopic Downdraft |
| Control Type | Rotary-Mechanical |
| Telescopic Assembly | Stainless Steel |
| Cover Plate | Stainless Steel |
| Removable Grease Filter(s) | Yes |
| CFM/ Sones Rating | 500/11.0 |
| Blower Type | Internal |
| Cabinet Width | 36 in |
| Net Weight | 69 lb |
| Approximate Shipping Weight | 73 lb |
| Telescoping Height | 7 in |
| Electrical Requirements | 120V ; 60Hz ; 4.0A |
| Amp Rating at 120V | 4.0 |
| Watts | 375 |
| Hertz | 60 |
| Duct Extension | 100 ft. |
| Labor Warranty | Limited 1-year entire appliance |
| Warranty Notes | See written warranty for full details |
| Parts Warranty | Limited 1-year entire appliance |
| Color Appearance | Stainless Steel |
| Width | 36 in. |
| Height | 7 in. |
| Length | 7 in. |
| Weight | 69 lbs. |
| Number of Boxes | 1 |
| Shipping Width | 41 in. |
| Shipping Height | 12 in. |
| Shipping Length | 12 in. |
| Shipping Weight | 109 lbs. |
| Total of Shipping Weight | 109 lbs. |
| Source | Calculation |
| Cubic Feet Measurement | 1.02 ft³ |
| Dimensional Weight | 12.69 lbs. |
| Total of Cubes | 1.02 ft³ |
| Total of Dimensional Weight | 12.69 lbs. |
| Venting Type | Externally Vented |
