| PTAC | Yes |
| Type | Wall |
| Chassis Type | Thru the Wall |
| Wall Sleeve Included | No |
| Maximum Cooling Amps | 6.7 Amps |
| Maximum Cooling Watts | 1,420 Watts |
| Heat | Electric Heat |
| Energy Efficiency Rating | 10.2 |
| Remote Control Included | No |
| Window Type | Standard |
| Indoor CFM, High | 470 CFM |
| Indoor CFM, Low | 360 CFM |
| Vent CFM | 75 CFM |
| Cooling BTU | 14500/14300 |
| Cooling Watts | 1420/1400 |
| EER | 10.2/10.2 |
| Heater Size (kW) | 5.0 |
| Moisture Removal (Pints/hr) | 3.0 |
| Sensible Heat Ratio | 0.72 |
| Voltage (1 PHASE, 60 Hz) | 230/208 |
| Volt Range | 253-187 |
| Current (Amps) | 6.2/6.7 |
| Power Factor | 0.99 |
| Compressor LRA | 34.5 |
| Compressor RLA | 6.4 |
| Outdoor Fan Motor (HP) | 0.09 |
| Indoor CFM, HIGH | 470 |
| Indoor CFM, LOW | 360 |
| Vent CFM | 75 |
| Sleeve Dimensions (HxWxD) | 16" x 42" x 13 3/4" |
| Dimensions with Front (HxWxD) | 16"x 42"x 21 1/2" |
| Cut Out Dimensions (HxW) | 16 1/4" x 42 1/4" |
| R-410A Charge (Oz.) | 34.2 |
| Brand | Friedrich |
| Series | ZoneAire Series |
| Model | PZE15K5SB |
| Cooling Capacity (BTU) | 14,500 BTU |
| WiFi | No |
| Remote Control | No |
| Remote Monitoring | No |
| Energy Star Rated | No |
| ADA Compliant | No |
| Plug Type | 6-30P |
| Voltage | 230/208 Volts |
| Number of Boxes | 1 |
| Shipping Width | 47 in. |
| Shipping Height | 21 in. |
| Shipping Length | 26.5 in. |
| Source | Calculation |
| Width | 42 in. |
| Height | 16 in. |
| Depth | 21.5 in. |
| Cubic Feet Measurement | 8.36 ft³ |
| Dimensional Weight | 103.94 lbs. |
| Total of Cubes | 8.36 ft³ |
| Total of Dimensional Weight | 103.94 lbs. |
