SKU: RGV3485GDL | UPC: 822843819973

Fisher Paykel RGV3485GDL Gas Range, 48", 5 Burners with Griddle, LPG Other

Quick Specification More details

Width:
47"
Depth:
29"
Height:
35"
Type:
Professional Ranges

About this product

Generous Capacity
Cooktop Power
Cooking Flexibility
Design Quality

SKU: RGV3485GDL | UPC: 822843819973

Fisher Paykel RGV3485GDL Gas Range, 48", 5 Burners with Griddle, LPG Other

$13,799.00 ~~$20,841.97~~ Save $7,042.97 / 33% OFF

Out of stock

Active Rebates

We’ll confirm fit, specs & delivery before you order.

• Chat • Email • Call Us

Related Accessories

Fisher Paykel GPRG12 Cast Iron Flat Griddle, 12" Other

Quick Specification More details

Width:
47"
Depth:
29"
Height:
35"
Type:
Professional Ranges

About this product

Generous Capacity
Cooktop Power
Cooking Flexibility
Design Quality

Product Details for Fisher Paykel RGV3485GDL

Technical Details

Burner ratings

Maximum burner power	23500 BTU
Power back left	18500BTU
Power back right	18500BTU
Power centre	23500BTU
Power front left	18500BTU
Power front right	18500BTU
Power griddle	24000BTU
Total cooktop power	121500 BTU

Capacity

Shelf positions (main oven)	5
Shelf positions (second oven)	5
Total capacity (main oven)	5.3cu ft
Total capacity second oven	2.4cu ft
Usable capacity (main oven)	3.9cu ft

Cleaning

Easy clean porcelain basepan

Yes

Controls

Electric circuit	3 wire
Metal illuminated dials	Yes

Gas requirements

Fitting and pipe	½ NPT, min. â…" âˆ… flex line
Supply Pressure (natural gas)	6" to 9" W.C

Oven features

Auto re-ignition system	Yes
Electronic oven control	Yes
Full extension telescopic sliding shelves	Yes
Infrared Broiler	Yes
Internal light	Yes
Titanium coated, illuminated metal dials	Yes

Oven functions

Bake	Yes
Broil	Yes
Convection bake	Yes
Slow cook	Yes

Oven performance

Main oven - Bake power	28,000 BTU
Main oven - Broil power	18,500 BTU
Secondary oven - Bake power	18,000 BTU

Power requirements

Amperage	15A
Supply frequency	60Hz

Rangetop features

Sealed range top	Yes
Vent trim included	Yes

Recommended back guards ventilation

Combustible situation	BGRV3-3048H
Non combustible situation	BGRV2-3048 / BGRV2-1248
Recommended hood	HCB48-12_N (48"" Professional Range Hood, Dual Blower)

Safety

ADA compliant	Yes
Full extension telescopic sliding shelves	Yes

Secondary oven features

3/4 Extension racks	2
Electronic oven control	Yes
Internal light	Yes

Secondary oven functions

Bake	Yes
Convection bake	Yes
Number of secondary oven functions	4
Proof	Yes
Slow cook	Yes

Dimensions & weight

Width	47 in.
Height	35 in.
Length	29 in.

Number of boxes, shipping dimensions, & shipping weight

Number of Boxes	1
Shipping Width	52 in.
Shipping Height	40 in.
Shipping Length	34 in.
Source	Calculation

Cubic feet measurement & dimensional weight

Cubic Feet Measurement	27.61 ft³
Dimensional Weight	343.2 lbs.
Total of Cubes	27.61 ft³
Total of Dimensional Weight	343.2 lbs.

Description

The brand Fisher & Paykel RGV3485GDL delivers commercial-grade cooking power and refined aesthetics with its expansive 48-inch gas range, tailored for culinary precision and control. Featuring five dual flow sealed burners including two 23,500 BTU power burners, this range provides intense heat for searing and fast boiling, along with gentle simmer capability. The integrated 18,000 BTU stainless steel griddle offers versatility for breakfast items, seared proteins, or grilled vegetables. Two gas ovens offer a combined 7.7 cu. ft. capacity, with the main oven featuring gas convection for even heat distribution and superior baking performance. Constructed from professional-grade stainless steel, it also includes heavy-duty oven racks, precise knob controls, and soft-close doors for premium functionality and comfort. Designed for demanding kitchens, the RGV3485GDL elevates cooking at home with professional power and finesse.
