Product Details for Fisher Paykel RGV3305N

Technical Details

Warranty

Parts 2 Year
Labor 2 Year

Burner ratings

Maximum burner power 23500 BTU
Power back left 18500BTU
Power back right 18500BTU
Power centre 23500BTU
Power front left 18500BTU
Power front right 18500BTU
Total cooktop power 97500 BTU

Capacity

Shelf positions 5
Total capacity 4.6cu ft
Usable capacity 3.4cu ft

Cleaning

Easy clean porcelain basepan Yes

Controls

Electric circuit 3 wire
Metal illuminated dials Yes

Gas requirements

Fitting and pipe ½ NPT, min. ⅝" ∅ flex line
Supply Pressure (natural gas) 6" to 9" W.C

Oven features

Auto re-ignition system Yes
Broil pan Yes
Electronic oven control Yes
Full extension telescopic sliding shelves Yes
Infrared Broiler Yes
Titanium coated, illuminated metal dials Yes

Oven functions

Bake Yes
Broil Yes
Convection bake Yes
Number of functions 4
Slow cook Yes

Oven performance

Bake power 21,000 BTU
Broil power 18,500 BTU

Power requirements

Power supply 120 V, 60 Hz
Service 15 A

Rangetop features

Sealed range top Yes
Vent trim included Yes

Recommended back guards ventilation

Combustible situation BGRV3-3030H
Non combustible situation BGRV2-3030 / BGRV2-1230
Recommended hood HCB30-6_N (Professional Range Hood)

Safety

ADA compliant Yes
Full extension telescopic sliding shelves Yes

Dimensions & weight

Width 29 in.
Height 35 in.
Length 29 in.

Number of boxes, shipping dimensions, & shipping weight

Number of Boxes 1
Shipping Width 34 in.
Shipping Height 40 in.
Shipping Length 34 in.
Source Calculation

Cubic feet measurement & dimensional weight

Cubic Feet Measurement 17.03 ft³
Dimensional Weight 211.76 lbs.
Total of Cubes 17.03 ft³
Total of Dimensional Weight 211.76 lbs.

Description

Professional style and performance, with high power burners delivering high heat or the most gentle simmer.


Product Features

  • Cooktop Power
  • Cooking Flexibility
  • Design Quality
  • Easy To Clean
  • Total Control
