Sale price $15,799.00 Regular price $22,551.97 Save $6,752.97 / 29% OFF

Product Details for Fisher Paykel RDV3488L

Technical Details

Accessories (included)

Adjustable feet covers Yes
Branded coin end cap Yes

Burner ratings

Maximum burner power 19000 BTU
Power back centre 13000BTU
Power back centre (2) 13000BTU
Power back left 13000BTU
Power back right 13000BTU
Power front centre 15000BTU
Power front centre (2) 15000BTU
Power front left 19000BTU
Power front right 19000BTU
Total cooktop power 120000 BTU

Cleaning

Dishwasher proof grates Yes
Easy clean porcelain basepan Yes
Pyrolytic self-clean Yes

Controls

Dial with illuminated halo Yes
Dual control oven dials Yes
Electric circuit 4 wire wire
High resolution display Yes
Metal illuminated dials Yes
Multi-language interface Yes
Precise cooking with food probe Yes
Recipe and food based functions Yes
Sabbath mode Yes
Smart Appliance Yes
Tilting touch screen interface Yes

Gas requirements

Fitting and pipe ½ NPT, min. ⅝" ∅ flex line
Supply Pressure (LPG) 11" to 14" W.C

Oven features

Auto re-ignition system Yes
Concealed element Yes
Electronic oven control Yes
Food probe Yes
Full extension telescopic sliding shelves Yes
Large broil pan Yes
Self-clean proof side racks Yes
True convection Yes

Oven functions

Air fry Yes
Bake Yes
Classic bake Yes
Clean Yes
Convection bake Yes
Convection broil Yes
Maxi Broil Yes
Number of functions 15
Pizza bake Yes
Rapid proof Yes
Roast Yes
Slow cook Yes
True convection Yes
Warm Yes

Oven performance

Broil 3600W
Main oven - True convection power 2500W

Power requirements

Rated current 50A
Supply frequency 60Hz

Rangetop features

Sealed range top Yes
Vent trim included Yes

Recommended back guards ventilation

Combustible situation BGRV3-3048H
Non combustible situation BGRV2-3048 / BGRV2-1248
Recommended hood HCB48-12_N (48" Professional Range Hood, Dual Blower)

Safety

ADA compliant Yes

Secondary oven features

3/4 Extension racks 2
Concealed element Yes
Electronic oven control Yes
Food probe Yes
Internal light Yes

Secondary oven functions

Air fry Yes
Bake Yes
Classic bake Yes
Convection bake Yes
Convection broil Yes
Maxi broil Yes
Number of secondary oven functions 11
Pastry bake Yes
Pizza bake Yes
Rapid proof Yes
Roast Yes
Warm Yes

Warranty

Parts and labor Limited 2 years

Dimensions & weight

Width 47 in.
Height 35 in.
Length 29 in.
Depth (excluding handles) 29 1⁄8"

Number of boxes, shipping dimensions, & shipping weight

Number of Boxes 1
Shipping Width 52 in.
Shipping Height 40 in.
Shipping Length 34 in.
Source Calculation

Cubic feet measurement & dimensional weight

Cubic Feet Measurement 27.61 ft³
Dimensional Weight 343.2 lbs.
Total of Cubes 27.61 ft³
Total of Dimensional Weight 343.2 lbs.

Description

With intuitive touchscreen and specialized cooking functions across two ovens, this range is a stand-out addition to your kitchen.


Product Features

  • Cook With Confidence
  • Generous Capacity
  • Cooking Flexibility
  • Cooktop Power
  • Design Quality
  • Easy To Clean
