SKU: RDV3485GDN | UPC: 822843818945

Fisher Paykel RDV3485GDN 48" Series 9 Professional Dual Fuel 5 Burner with Griddle Self-Cleaning Range, Natural Gas Stainless Steel

Quick Specification More details

Width:
47"
Depth:
29"
Height:
35"
Type:
Professional Ranges

About this product

Guided cooking using your touchscreen makes it simple to cook by food, function or recipe.
Gas cooktop with griddle and a top burner heat up to 23,500 BTU, for seriously fast boiling
6.9 cu ft total oven capacity across two oven cavities
Ensure perfect results with the food probe, included

More on the way

On Sale

SKU: RDV3485GDN | UPC: 822843818945

Fisher Paykel RDV3485GDN 48" Series 9 Professional Dual Fuel 5 Burner with Griddle Self-Cleaning Range, Natural Gas Stainless Steel

$17,099.00 ~~$24,154.97~~ Save $7,055.97 / 29% OFF

Quantity:

More on the way

Active Rebates

Extended Protection

1-Year Extended Protection
$197.99
2-Year Extended Protection
$354.99
3-Year Extended Protection
$659.99
5-Year Extended Protection
$959.99
Manufacturer Warranty Only

Gas Pro Range Install — Direct Replacement, No Modifications
$350.00
Old Appliance Pro Removal (Unit Must be Disconnected by Owner if Installation was Not Added)
$249.99

We’ll confirm fit, specs & delivery before you order.

• Chat • Email • Call Us

Related Accessories

Fisher Paykel AHP3R48BA Professional Round Flush Handles for Ranges, 48" Other

More on the way

On Sale

Fisher Paykel AHP3R48DC Professional Round Flush Handles for Ranges, 48" Other

More on the way

On Sale

Fisher Paykel GPRG12 Cast Iron Flat Griddle, 12" Other

More on the way

On Sale

Quick Specification More details

Width:
47"
Depth:
29"
Height:
35"
Type:
Professional Ranges

About this product

Guided cooking using your touchscreen makes it simple to cook by food, function or recipe.
Gas cooktop with griddle and a top burner heat up to 23,500 BTU, for seriously fast boiling
6.9 cu ft total oven capacity across two oven cavities
Ensure perfect results with the food probe, included

Product Details for Fisher Paykel RDV3485GDN

Technical Details

Other

Fitting and pipe	½ NPT, min. â…" Ø flex line
Supply Pressure (LPG)	11" to 14" W.C
Capacity total (AHAM)	4.8 cu ft
Capacity usable (AHAM)	3.8 cu ft
Full extension telescopic racks	2
Shelf positions	5
Number of main oven functions	15
Main oven - Bake power	4600W
Main oven - Broil power	4000W
Main oven - True convection power	2500W
Secondary oven - Bake power	2450W
Secondary oven - Broil power	3600W
Amperage	50A
Supply frequency	60Hz
Supply voltage	120 - 240V
Simmer on all burners	140°F
Vent trim included	Flat vent trim
Max burner power	19,000 BTU
Power back left	11,500 BTU
Power front left	15,000 BTU
Power griddle	24,000 BTU
Total cooktop power	96,000 BTU
Combustible situation	BGRV3-3048H
Non combustible situation	BGRV2-3048 / BGRV2-1248
Recommended hood	HCB48-12_N (48" Professional Range Hood, Dual Blower)
Capacity total (AHAM)	2.1 cu ft
Capacity usable (AHAM)	1.8 cu ft
Number of secondary oven functions	11
Parts and labor	2 years

Accessories (included)

Adjustable feet covers	Yes
Branded coin end cap	Yes

Burner ratings

Maximum burner power	23500 BTU
Power back centre	23500BTU
Power back left	18500BTU
Power back right	18500BTU
Power front left	18500BTU
Power front right	18500BTU
Power griddle	24000BTU
Total cooktop power	121500 BTU

Capacity

Shelf positions (main oven)	5
Shelf positions (second oven)	5
Total capacity (main oven)	4.8cu ft
Total capacity second oven	2.1cu ft
Usable capacity (main oven)	3.8cu ft

Cleaning

Easy clean porcelain basepan	Yes
Pyrolytic self-clean	Yes

Controls

Dial with illuminated halo	Yes
Dual control oven dials	Yes
Electric circuit	4 wire
High resolution display	Yes
Metal illuminated dials	Yes
Multi-language interface	Yes
Precise cooking with food probe	Yes
Recipe and food based functions	Yes
Sabbath mode	Yes
Smart Appliance	Yes
Tilting touch screen interface	Yes
Wi-Fi connectivity	Yes

Gas requirements

Fitting and pipe	½ NPT, min. ⅝" ∅ flex line
Supply Pressure (natural gas)	6" to 9" W.C

Oven features

Auto re-ignition system	Yes
Concealed element	Yes
Electronic oven control	Yes
Full extension telescopic sliding shelves	Yes
Titanium coated, illuminated metal dials	Yes

Oven functions

Air fry	Yes
Bake	Yes
Classic bake	Yes
Clean	Yes
Convection bake	Yes
Convection broil	Yes
Maxi Broil	Yes
Number of functions	15
Pastry bake	Yes
Pizza bake	Yes
Rapid proof	Yes
Roast	Yes
Slow cook	Yes
True convection	Yes
Warm	Yes

Oven performance

Bake power	4600
Broil	3600W
Main oven - True convection power	2500W

Power requirements

Connection	4-prong grounding type [NEMA 14-50 plug]
Power supply	120 / 240 V, 60 Hz
Service	50 A

Rangetop features

Sealed range top	Yes
Vent trim included	Yes

Recommended back guards ventilation

Combustible situation	BGRV3-3048H
Non combustible situation	BGRV2-3048 / BGRV2-1248
Recommended hood	HCB48-12_N (48"" Professional Range Hood, Dual Blower)

Safety

ADA compliant

Yes

Secondary oven features

3/4 Extension racks	2
Concealed element	Yes
Electronic oven control	Yes
Food probe	Yes
Internal light	Yes

Secondary oven functions

Air fry	Yes
Bake	Yes
Classic bake	Yes
Convection bake	Yes
Convection broil	Yes
Maxi broil	Yes
Number of secondary oven functions	11
Pastry bake	Yes
Pizza bake	Yes
Rapid proof	Yes
Roast	Yes
Warm	Yes

Dimensions & weight

Width	47 in.
Height	35 in.
Length	29 in.

Number of boxes, shipping dimensions, & shipping weight

Number of Boxes	1
Shipping Width	52 in.
Shipping Height	40 in.
Shipping Length	34 in.
Source	Calculation

Cubic feet measurement & dimensional weight

Cubic Feet Measurement	27.61 ft³
Dimensional Weight	343.2 lbs.
Total of Cubes	27.61 ft³
Total of Dimensional Weight	343.2 lbs.

Description

With intuitive touchscreen and specialized cooking functions across two ovens, this range is a stand-out addition to your kitchen.

Product Features

Guided cooking using your touchscreen makes it simple to cook by food, function or recipe.
Gas cooktop with griddle and a top burner heat up to 23,500 BTU, for seriously fast boiling
6.9 cu ft total oven capacity across two oven cavities
Ensure perfect results with the food probe, included
