Product Details for Fisher Paykel RDV3366L
Technical Details
Accessories (included)
| Adjustable feet covers | Yes |
| Branded coin end cap | Yes |
Burner ratings
| Maximum burner power | 19000 BTU |
| Power back centre | 13000BTU |
| Power back left | 13000BTU |
| Power back right | 13000BTU |
| Power front centre | 15000BTU |
| Power front left | 19000BTU |
| Power front right | 19000BTU |
| Total cooktop power | 92000 BTU |
Capacity
| Shelf positions | 5 |
| Total capacity | 4.8cu ft |
| Usable capacity | 3.8cu ft |
Cleaning
| Easy clean porcelain basepan | Yes |
| Pyrolytic self-clean | Yes |
Controls
| Dial with illuminated halo | Yes |
| Electric circuit | 4 wire |
| High resolution display | Yes |
| Metal illuminated dials | Yes |
| Multi-language interface | Yes |
| Precise cooking with food probe | Yes |
| Recipe and food based functions | Yes |
| Sabbath mode | Yes |
| Smart Appliance | Yes |
| Tilting touch screen interface | Yes |
| Wi-Fi connectivity | Yes |
Gas requirements
| Fitting and pipe | ½ NPT, min. ⅝" ∅ flex line |
| Supply Pressure (LPG) | 11" to 14" W.C |
Oven features
| Auto re-ignition system | Yes |
| Concealed element | Yes |
| Electronic oven control | Yes |
| Food probe | Yes |
| Full extension telescopic sliding shelves | Yes |
| Large broil pan | Yes |
| Self-clean proof side racks | Yes |
| True convection | Yes |
Oven functions
| Air fry | Yes |
| Bake | Yes |
| Classic bake | Yes |
| Clean | Yes |
| Convection bake | Yes |
| Convection broil | Yes |
| Maxi Broil | Yes |
| Number of functions | 15 |
| Pastry bake | Yes |
| Pizza bake | Yes |
| Rapid proof | Yes |
| Roast | Yes |
| Slow cook | Yes |
| True convection | Yes |
| Warm | Yes |
Oven performance
| Main oven - True convection power | 2500W |
Power requirements
| Connection | 4-prong grounding type [NEMA 14-50 plug] |
| Power supply | 120 / 240 V, 60 Hz |
| Service | 30 A |
Rangetop features
| Vent trim included | Yes |
Recommended back guards ventilation
| Combustible situation | BGRV3-3036H |
| Non combustible situation | BGRV2-3036 / BGRV2-1236 |
| Recommended hood | HCB36-6_N (36" Professional Range Hood) / HCB36-12_N (36" Professional Range Hood, Dual Blower) |
Safety
| ADA compliant | Yes |
| Full extension telescopic sliding shelves | Yes |
Secondary oven features
| Food probe | Yes |
Warranty
| Parts and labor | Limited 2 years |
Dimensions & weight
| Width | 35 in. |
| Height | 35 in. |
| Length | 29 in. |
| Depth (excluding handles) | 29 1⁄8" |
Number of boxes, shipping dimensions, & shipping weight
| Number of Boxes | 1 |
| Shipping Width | 40 in. |
| Shipping Height | 40 in. |
| Shipping Length | 34 in. |
| Source | Calculation |
Cubic feet measurement & dimensional weight
| Cubic Feet Measurement | 20.56 ft³ |
| Dimensional Weight | 255.58 lbs. |
| Total of Cubes | 20.56 ft³ |
| Total of Dimensional Weight | 255.58 lbs. |
Description
Get the best of gas and convection technology in this striking range with intuitive touchscreen and specialized cooking functions.
Product Features
- Cook With Confidence
- Generous Capacity
- Cooking Flexibility
- Cooktop Power
- Design Quality
- Easy To Clean
Manuals & Guides
- User Guide Dual Fuel Cooker
- Specification Guide Dual Fuel Range
- Data Sheet Dual Fuel Range with Backguard BGRV2-1236
- Data Sheet Dual Fuel Range with Backguard BGRV2-3036
- Data Sheet Dual Fuel Range with Backguard BGRV2-3036H and Angled Trim
- Data Sheet Dual Fuel Range
- Planning Guide Dual Fuel Range
- Quick Reference guide
- Service & Warranty
- User Guide Professional Range
- Installation Guide
