SKU: BUF403WW

Broan BUF403WW 30Inch Convertible UnderCabinet Range Hood, 230 Max Blower CFM, White Black

Quick Specification More details

Width:
30"
Depth:
17.5"
Height:
6"
Type:
Under Cabinet Hoods

SKU: BUF403WW

Broan BUF403WW 30Inch Convertible UnderCabinet Range Hood, 230 Max Blower CFM, White Black

Active Rebates

We’ll confirm fit, specs & delivery before you order.

• Chat • Email • Call Us

Quick Specification More details

Width:
30"
Depth:
17.5"
Height:
6"
Type:
Under Cabinet Hoods

Product Details
Manuals & Guides
From The Manufacturer
Reviews

Product Details for Broan BUF403WW

Technical Details

Product details

Filter Type	Aluminum Mesh
Heat Sentry™	No
HVI Certified	Yes
Lighting Type	LED
UL Listed	Yes
ADA Compliance	Yes
Damper Included	No
ENERGY STAR® certified	No
Light Bulb Wattage	75
Light Bulbs Included	No
Light Levels	1
Material	Stainless Steel
Nightlight Or Nighlight Setting	No
Ductless Recirculation Capable	Yes
Ductless Filter Or Kit Included	No
Speed Levels	2
Switch Control Type	Rocker
Rated Voltage	120
Boost Mode	No
Rated Amps	2.5
Product Depth	17.5"
Product Height	6"
Product Width	30"
Built-In Timer	No
CFM	230 Max
Diameter	7" Round
Vent Type	Convertible Built-In
Duct Direction	Horizontal/Vertical
Bulb (Recommended Type)	A19
Manufacturer Warranty	1 Year Limited
Sound Level (Sones)	3.5
Remote Operation Capable	Yes
Wattage	240

Dimensions & weight

Width	30 in.
Height	6 in.
Length	17.5 in.

Number of boxes, shipping dimensions, & shipping weight

Number of Boxes	1
Shipping Width	35 in.
Shipping Height	11 in.
Shipping Length	22.5 in.
Source	Calculation

Cubic feet measurement & dimensional weight

Cubic Feet Measurement	1.82 ft³
Dimensional Weight	22.66 lbs.
Total of Cubes	1.82 ft³
Total of Dimensional Weight	22.66 lbs.

Description

The BUF4 series provides installation flexibility with 4-way convertibility to fit virtually all applications. The hood is designed for under cabinet use and installs as 3-1/4 in. x 10 in. ducted opening with vertical or horizontal ducting; or 7 in. round vertical ducting or as non-ducted with air recirculation. The hood is equipped with a 230 MAX Blower CFM designed for years of trouble-free service, an easy to clean grease filter, and control switches for fan speed and light activation
