SKU: BCSD130BC | UPC: 026715240678

Broan BCSD130BC Glacier 30-Inch 300 Max Blower CFM 5 Sones Range Hood Bisque

Quick Specification More details

Width:
30"
Depth:
19.63"
Height:
6"
Type:
Under Cabinet Hoods

About this product

HVI Certified
UL Listed
Clean lines and contemporary style in an under-cabinet convertible range hood that will complement nearly any kitchen
Hidden rocker switches adjust fan speed and lighting levels

SKU: BCSD130BC | UPC: 026715240678

Broan BCSD130BC Glacier 30-Inch 300 Max Blower CFM 5 Sones Range Hood Bisque

Active Rebates

We’ll confirm fit, specs & delivery before you order.

• Chat • Email • Call Us

Quick Specification More details

Width:
30"
Depth:
19.63"
Height:
6"
Type:
Under Cabinet Hoods

About this product

HVI Certified
UL Listed
Clean lines and contemporary style in an under-cabinet convertible range hood that will complement nearly any kitchen
Hidden rocker switches adjust fan speed and lighting levels

Product Details
Manuals & Guides
Key Features
From The Manufacturer
Reviews

Product Details for Broan BCSD130BC

Technical Details

Warranty

Parts	1 Year
Labor	1 Year

Other

Filter Type	Open Mesh
Heat Sentry™	No
HVI Certified	Yes
Lighting Type	Halogen
Sound Level (Sones)	1.5
Light Bulb Wattage	50
Light Levels	2
Material	Steel
Switch Control Type	Rocker
Rated Voltage	120
Country of Origin	Mexico
Rated Amps	1.4
Capture Efficiency	97.4
CFM	300 Max
Diameter	7" Round
Vent Type	Convertible Built-In
Duct Direction	Horizontal/Vertical
Bulb (Recommended Type)	GU10 MR16
Manufacturer Warranty	1 Year
Wattage	168

Dimensions & weight

Width	30 in.
Height	6 in.
Length	19.63 in.

Cubic feet measurement & dimensional weight

Cubic Feet Measurement	2.04 ft³
Dimensional Weight	25.41 lbs.
Total of Cubes	2.04 ft³
Total of Dimensional Weight	25.41 lbs.

Number of boxes, shipping dimensions, & shipping weight

Shipping Width	24 in.
Shipping Depth	35 in.
Shipping Height	8 in.
Shipping Weight	21 lb.

Description

This under-cabinet convertible range hood features a clean, contemporary shape to complement nearly any kitchen design. Equipped with the exclusive Broan Captur™ system, which combines advanced blower design with new filter technology, this 300 Max Blower CFM-rated hood provides 97.4% removal of smoke and odor to protect your home and family from airborne pollutants caused from cooking. The quiet-running Glacier is also designed with smooth flow technology, which streamlines the path of air for improved efficiency and noise reduction. Easy-flip rocker switches control the 2 fan speeds and LED lighting system. Using the included EZ1® system, Glacier can easily be installed by one person in up to half the time of a standard install.

Product Features

Clean lines and contemporary style in an under-cabinet convertible range hood that will complement nearly any kitchen
Hidden rocker switches adjust fan speed and lighting levels
Captur system and 300 Max Blower CFM is 97.4% efficient in removal of smoke and odor from cooking
Convertible to accommodate either top or rear venting applications or non-ducted operation using charcoal filters, which are sold separately (Filter Model HPF30)
2 dishwasher-safe open mesh filters feature advanced high-flow technology to grab more airborne grease
2-halogen bulbs (purchase separately) provide warm light over the cooking surface, adjustable to high or low levels
1-year limited manufacturer’s warranty
EZ1 system enables easy single-person installation in up to half the time of traditional methods
Range hood is installed as hardwired or with an optional power cord kit (SHCK44; sold separately)
