SKU: ALT136SS

Broan ALT136SS Elite 36-Inch Convertible Under-Cabinet Range Hood Stainless Steel

Quick Specification More details

Width:
36"
Depth:
22"
Height:
5"
Type:
Under Cabinet Hoods

About this product

UL Listed
HVI Certified
Model replaced BQSJ136SS
The Captur system"s advanced blower/wheel design features a centric inlet to remove smoke and odor faster. Two-speed blower control exhausts at 300 MAX Blower CFM

Summer Sale

Clearance

SKU: ALT136SS

Broan ALT136SS Elite 36-Inch Convertible Under-Cabinet Range Hood Stainless Steel

Active Rebates

We’ll confirm fit, specs & delivery before you order.

• Chat • Email • Call Us

Quick Specification More details

Width:
36"
Depth:
22"
Height:
5"
Type:
Under Cabinet Hoods

About this product

UL Listed
HVI Certified
Model replaced BQSJ136SS
The Captur system"s advanced blower/wheel design features a centric inlet to remove smoke and odor faster. Two-speed blower control exhausts at 300 MAX Blower CFM

Product Details
Manuals & Guides
Key Features
From The Manufacturer
Reviews

Contact us for Pricing

Product Details for Broan ALT136SS

Technical Details

Other

Filter Type	Micro Mesh
Heat Sentry™	No
HVI Certified	Yes
Lighting Type	LED
Sound Level (Sones)	1.5
Light Levels	2
Material	Steel
Switch Control Type	Rocker
Rated Voltage	120
Country of Origin	Mexico
Rated Amps	1.4
Capture Efficiency	97.4
CFM	300 Max
Diameter	7" Round
Duct Direction	Horizontal/Vertical
Bulb (Recommended Type)	Integrated LED Module
Manufacturer Warranty	1 Year
Wattage	168

Dimensions & weight

Width	36 in.
Height	5 in.
Length	22 in.

Cubic feet measurement & dimensional weight

Cubic Feet Measurement	2.29 ft³
Dimensional Weight	28.49 lbs.
Total of Cubes	2.29 ft³
Total of Dimensional Weight	28.49 lbs.

Number of boxes, shipping dimensions, & shipping weight

Shipping Width	40 in.
Shipping Depth	7.2 in.
Shipping Height	28 in.
Shipping Weight	29 lb.

Description

Broan(R) Elite 36-Inch Convertible Under-Cabinet Range Hood, Stainless Steel

Product Features

Model replaced BQSJ136SS
The Captur system"s advanced blower/wheel design features a centric inlet to remove smoke and odor faster. Two-speed blower control exhausts at 300 MAX Blower CFM
Forward placement and smooth-flow blower wheel design ensure quiet, 1.5 sones operation at normal speed
Hidden on/off rocker switches control blower speeds and light levels
Dishwasher-safe, micro-mesh filters provide efficient grease removal
EZ1 brackets enable single-person installation in less than half the time of traditional methods
ADA compliant, remote operation is possible using a standard UL approved wall switch.
Two-level, LED bulbs flood the cooktop and surrounding area with generous illumination.
Non-duct capable with use of charcoal filters, sold separately. Hidden louvers on top of hood exhaust away from cabinetry
Range hood is installed as hardwired or with an optional power cord kit (sold separately)
