SKU: AE80F1

Broan AE80F1 Flex Series 80 CFM Bathroom Exhaust Fan Finish Pack Energy Star White

Quick Specification More details

Width:
12"
Depth:
5.75"
Height:
9.25"
Type:
Other

About this product

80 CFM, Effective ventilation to remove moisture and reduce the risk of mold or mildew in most full baths
UL Listed for use over tubs and showers with a GFCI circuit
Powerful enough for rooms up to 75 sq. ft.
Corrosion resistant galvanized steel housing stands up to moisture

Summer Sale

Clearance

SKU: AE80F1

Broan AE80F1 Flex Series 80 CFM Bathroom Exhaust Fan Finish Pack Energy Star White

Active Rebates

We’ll confirm fit, specs & delivery before you order.

• Chat • Email • Call Us

Quick Specification More details

Width:
12"
Depth:
5.75"
Height:
9.25"
Type:
Other

About this product

80 CFM, Effective ventilation to remove moisture and reduce the risk of mold or mildew in most full baths
UL Listed for use over tubs and showers with a GFCI circuit
Powerful enough for rooms up to 75 sq. ft.
Corrosion resistant galvanized steel housing stands up to moisture

Product Details
Manuals & Guides
From The Manufacturer
Reviews

Contact us for Pricing

Product Details for Broan AE80F1

Technical Details

Product details

CFM	80
Duct Size	4
ENERGY STAR® certified	Yes
Grille Length	11.5
Grille Width	12
Housing Dimensions	9-1/4" x 10" x 5-3/4"
Sound Level (Sones)	0.7
UL Listed	Yes
Grille Finish	White
Humidity Sensing	No
Motion Sensing	No
Motor Engineered For Continuous Operation	Yes
Night Light	No
Radiation Damper Available	Yes
Room Side Installation	Yes
UL Listed for use over bathtubs or showers when connected to a GFCI circuit	Yes
Heater Wattage	0
Recommended Room Size (Sq Ft)	75
Rated Amps	0.3
Voltage	120
Can Be Used To Comply With Title 24	No
Minimum Construction Space Required	2" x 6"
Manufacturer Warranty	3 Years
High Efficiency Luminaire	No
Minimum Recommended Flow	0

Dimensions & weight

Width	12 in.
Height	9.25 in.
Length	5.75 in.
Housing Dimensions	9-1/4" x 10" x 5-3/4"

Number of boxes, shipping dimensions, & shipping weight

Number of Boxes	1
Shipping Width	17 in.
Shipping Height	14.25 in.
Shipping Length	10.75 in.
Source	Calculation

Cubic feet measurement & dimensional weight

Cubic Feet Measurement	0.37 ft³
Dimensional Weight	3.84 lbs.
Total of Cubes	0.37 ft³
Total of Dimensional Weight	3.84 lbs.

Description

Broan Flex(TM) Series 80 CFM Bathroom Exhaust Fan Finish Pack Energy Star(R)

Product Features

80 CFM, Effective ventilation to remove moisture and reduce the risk of mold or mildew in most full baths
UL Listed for use over tubs and showers with a GFCI circuit
Powerful enough for rooms up to 75 sq. ft.
Corrosion resistant galvanized steel housing stands up to moisture
Permanently lubricated AC motor engineered for continuous operation
*Testing reflects total fan housing airtightness.
0.7 Sones for Ultra quiet performance, you might not notice it's on
TrueSeal™ Damper technology reduces air leakage up to 50%
EzDuct™ connector can be installed from the room side, with no attic access required
ENERGY STAR® Certified Product
