Product Details for MIELE DA2588
Technical Details
Design
| Color | Stainless steel |
| Insert ventilation extractor | Yes |
Operating modes
| Recirculated mode | Can be retrofitted |
| Recirculation conversion kit (order separately) | DUU 151 |
| OdorFree charcoal filter (order separately) | DKF15-900 |
User convenience
| Miele@home | Yes |
| Automatic function Con@ctivity | Yes |
| Electronic controls | Yes |
| Operation | Light-touch switches with LEDs |
| Power levels (number excl. Intensive) | 3 |
| Booster levels | 1 |
| Delayed shutdown for 5 or 15 minutes | Yes |
| Grease filter saturation indicator | Yes |
| Active charcoal filter saturation indicator | Yes |
| CleanCover | Yes |
Lighting
| Number x W | 2 |
| Light intensity in Lx | 300 |
| Color temperature in K | 3000 |
Exhaust air
| Air throughput in CFM in Booster | 500 |
| Air throughput | Values upon request |
| Air throughput with Booster level 1 (m /h) according to EN 61591 | 500.29 |
Technical data
| Canopy width in in. (mm) | 31 5/8 (802) |
| Canopy height in in. (mm) | 2 |
| Depth of hood canopy in in. (mm) | 15 7/8 (402) |
| Minimum height above electric cooktops in mm | 24 1/8 (610) |
| Minimum safety distance above gas cooktops (max. 12.6 kW total power, burner 4.5 kW) in mm | 26 |
| Net weight in lbs. (kg) | 27 |
| Length of electrical wire in ft. (m) | 2 |
| Standard plug fitted | Yes |
| Plug type | NEMA plug: 5-15 |
| Total connected load in kW | 0.356 |
| Voltage in V | 120 |
| Fuse rating in A | 15 |
| Frequency in Hz | 60 |
| Number of phases | 1 |
Installation note
| Vent connection at top | Yes |
| Diameter of vent connection in in. (mm) | 6 |
Standard accessories
| Non-return flap | Yes |
| Communication module for Con@ctivity XKM 2000 DA | XKS 3000 Z |
Features
- Customized kitchen design - fully integrated in 31 5/8 (802) in (mm) width
- Con@ctivity
Innovative convenience: the ventilation hood reacts automatically to settings on the cooktop. - Unique user convenience - Con@ctivity
- Delayed shutdown
Odor-free room air: "after cooking, the blower can be set to switch off automatically after 5 or 15 minutes." - Powerful - 500.29 (850) ft /min (m3/h) in Booster level
- filter saturation indicator
Easy filter replacement: a red light lets you know when the grease and/or charcoal filter is saturated. - Efficient filtration- 10-ply stainless steel grease filters
- Safety turn off
Sensible, even in case of operating errors: The ventilation hood switches off automatically after 10 hours. - Safe and easy to clean - Miele CleanCover
- Stainless-steel grease filters (10-layer)
Looks great and does a good job: Effective grease filtering and easy cleaning inside the dishwasher. - Manufactured with great care by Miele & Cie. KG
- Miele CleanCover
Protection and easy cleaning: The sealed, smooth surface prevents contact with cables and the motor. - View manufacturer details: Miele & Cie. KG
- Safety information
Description
The brand + SKU: The Miele DA2588 built-in ventilation hood combines elegant design with high-performance functionality to enhance your kitchen’s air quality and aesthetics. Designed to fit flush beneath cabinetry, this 30" stainless steel unit offers discreet yet effective ventilation. It features energy-efficient LED lighting to brightly illuminate your cooktop, while the backlit controls ensure intuitive use even in low-light environments. The unit includes multi-speed fan settings to efficiently extract steam, smoke, and odors, maintaining a fresh cooking space. Equipped with dishwasher-safe stainless steel grease filters and built with Miele’s signature craftsmanship, the DA2588 offers quiet performance, lasting durability, and timeless style—all in a compact and integrated package.
Manuals & Guides
Key Features
Con@ctivity
Innovative convenience: the ventilation hood reacts automatically to settings on the cooktop.
Delayed shutdown
Odor-free room air: "after cooking, the blower can be set to switch off automatically after 5 or 15 minutes."
filter saturation indicator
Easy filter replacement: a red light lets you know when the grease and/or charcoal filter is saturated.
Safety turn off
Sensible, even in case of operating errors: The ventilation hood switches off automatically after 10 hours.
Stainless-steel grease filters (10-layer)
Looks great and does a good job: Effective grease filtering and easy cleaning inside the dishwasher.
Miele CleanCover
Protection and easy cleaning: The sealed, smooth surface prevents contact with cables and the motor.
