Name: SUMMIT SWC6GBLBIHVADA 24" Wide Built-in Wine Cellar, ADA Compliant
Brand: SUMMIT
SKU: SWC6GBLBIHVADA-KT
Price: 1559.88 USD
Availability: InStock

SUMMIT SWC6GBLBIHVADA 24" Wide Built-in Wine Cellar, ADA Compliant

Key Specs

Type: Wine fridges
Width: 23.63 Inch
Depth: 23.5 Inch
Height: 32.25 Inch

More details

Translation missing: en.products.product.product_variants

$1,559.88

Check Delivery Options

More on the way

Quantity:

Extended Protection

5 Year Major Appliance True Extended under $2,500.00
$195.99
3 Year Major Appliance True Extended under $2,500.00
$131.99
Decline Protection

Product Information
Technical Details
Manuals & Guides
Features
Reviews

General
Model: SWC6GBLBIHVADA
Brand: Summit
Height: 32.25
Width: 23.63
Length: 23.5
Advanced Features
Wi-Fi Connectivity: No

32" height fits under lower ADA compliant counters
(BULL)European built wine cellar designed for safe storage with elegant display
(BULL)Commercially approved to NSF-7 standards
(BULL)Flexible design allows built-in or freestanding use under counters in 24 inch spaces
(BULL)Factory-installed lock for security you can count on

SUMMIT SWC6GBIADA series features European designed, commercially approved wine cellars capable of built-in use under lower ADA compliant counters. The SWC6GBLBIHVADA is conveniently sized at just 24" wide, with a front-breathing design for built-in installation under counters. The fully finished jet black cabinet also allows freestanding use. This unit features a double pane tempered glass door for reliable storage. We include a professional style handle in brushed stainless steel to complete the professional look. The lock is located towards the top of the door for easier access. Inside, the SWC6GBLBIHVADA includes adjustable scalloped shelves perfectly designed to hold bottles in place. The white interior helps to improve visibility, letting your collection stand out clearly. This unit includes an interior light with an on/off rocker switch located behind the adjustable dial thermostat. The SWC6GBLBIHVADA is made in Europe and is ETL-S listed to NSF-7 standards for commercial use. Additional handle styles and door tint options are available. NOTE: These models are designed primarily for white wine storage but can be upgraded with a digital thermostat to accommodate red wine temperatures.

Overview
Height of Cabinet	32.0" (81 cm)
Height to Hinge Cap	32.25" (82 cm)
Width	23.63" (60 cm)
Depth	23.5" (60 cm)
Capacity	5.5 cu.ft. (156 L)
Defrost Type	Automatic
Door	Glass
Cabinet	Black
US Electrical Safety	UL
Canadian Electrical Safety	ULC
Sanitation	ETL-S
Amps	1.3
Voltage/Frequency	115 V AC/60 Hz
Weight	115.0 lbs. (52 kg)
Shipping Weight	120.0 lbs. (54 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
UPC	761101040486
Wine Cellar
Number of Zones	1
Door Swing	RHD
Reversible	Factory Reversible
Shelf Type	Scalloped
Shelf Qty	4
Thermostat Type	Dial
Interior Light	Yes
Fan Type	Interior and Exterior
Refrigerant Type	R600a
Refrigerant Amount	0.67 oz.
High Side PSI	124.0
Low Side PSI	30.0
Interior Height 1	26.0" (66 cm)
Interior Width 1	20.75" (53 cm)
Interior Depth 1	17.5" (44 cm)
Compressor Step Height	6.0" (15 cm)
Compressor Step Width	20.75" (53 cm)
Compressor Step Depth	5.0" (13 cm)
Condensor Location	Rear of Unit
Exterior
SSK	Latch for door
LHD - Left hand door swing	SCD - Self-closing door
SS Hinges	Extra key
Alarm	DT - Digital thermostat
Door
T1 Door Tint	T1S Door Tint
T2 Door Tint	T3 Door Tint
T4 Door Tint	-
Handle
SH	-
Overview
Height of Cabinet	32.0" (81 cm)
Height to Hinge Cap	32.25" (82 cm)
Width	23.63" (60 cm)
Depth	23.5" (60 cm)
Capacity	5.5 cu.ft. (156 L)
Defrost Type	Automatic
Door	Glass
Cabinet	Black
US Electrical Safety	UL
Canadian Electrical Safety	ULC
Sanitation	ETL-S
Amps	1.3
Voltage/Frequency	115 V AC/60 Hz
Weight	115.0 lbs. (52 kg)
Shipping Weight	120.0 lbs. (54 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
UPC	761101040486
Wine Cellar
Number of Zones	1
Door Swing	RHD
Reversible	Factory Reversible
Shelf Type	Scalloped
Shelf Qty	4
Thermostat Type	Dial
Interior Light	Yes
Fan Type	Interior and Exterior
Refrigerant Type	R600a
Refrigerant Amount	0.67 oz.
High Side PSI	124.0
Low Side PSI	30.0
Interior Height 1	26.0" (66 cm)
Interior Width 1	20.75" (53 cm)
Interior Depth 1	17.5" (44 cm)
Compressor Step Height	6.0" (15 cm)
Compressor Step Width	20.75" (53 cm)
Compressor Step Depth	5.0" (13 cm)
Condensor Location	Rear of Unit
Exterior
SSK	Latch for door
LHD - Left hand door swing	SCD - Self-closing door
SS Hinges	Extra key
Alarm	DT - Digital thermostat
Door
T1 Door Tint	T1S Door Tint
T2 Door Tint	T3 Door Tint
T4 Door Tint	-
Handle
SH	-

Commercially approved : ETL-S listed to NSF-7 for use in foodservice establishments
Automatic defrost : Reduced maintenance with auto defrost system
ADA compliant : 32" high to fit under lower ADA compliant counters
Built-in capable : Make the best use of space by installing your appliance under the counter and flush with other cabinets
Fully finished black cabinet : Allows the unit to be used freestanding
Double pane tempered glass door : Display your collection behind a solid glass door trimmed in elegant brushed aluminum for a refined touch
Professional handle : Vertically mounted thin handle (14mm) in brushed stainless steel matches many popular styles of cabinetry
Factory installed lock : Keyed lock for secure interior, conveniently located at the top of the door
Scalloped steel shelving : Curved shelves designed for the ideal storage of wine bottles
Half-sized wire shelf : Sits on top of the compressor and features wire slots ideal for holding bottles on their sides
